Ecom Instruments XP3410 IS Installation instructions
1
XP3410 IS (SONIM XP STRIKE IS)
Safety instructions · Indicaciones de seguridad
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 1 30.07.13 14:22
2
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 2 30.07.13 14:22
3
Note:
The current safety instructions, operating instructions, EC Declaration of Conformity and the Certificate of
Conformity can be downloaded from the relevant product page at www.ecom-ex.com, or alternatively they
can be requested directly from the manufacturer.
Content
1.Application .................................................................................................................................................................................................................4
2. Safety precautions ..................................................................................................................................................................................................4
3. Faults and damage...................................................................................................................................................................................................4
4. Safety regulations ....................................................................................................................................................................................................5
5. Ex-Data ........................................................................................................................................................................................................................7
6. Specifications ............................................................................................................................................................................................................7
7. Changing the battery.............................................................................................................................................................................................8
8. Safety precautions for the battery..............................................................................................................................................................10
9. Repair .........................................................................................................................................................................................................................11
10. Cleaning, maintenance and storage.........................................................................................................................................................11
11. Disposal...................................................................................................................................................................................................................12
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 3 30.07.13 14:22
4
1.Application
1.1 NEC
The XP3410 IS (SONIM XP STRIKE IS) is an intrinsically safe water-, dust- and impact resistant mobile phone
for industrial application in areas with an increased risk of explosion.Approved for Division 1 and 2 Class I, II, III
2. Safety precautions
These safety instructions contain information and safety regulations which are to be observed without fail for
safe operation in the described conditions. Non-observance of this information and these instructions can have
serious consequences or it may violate regulations.
Please read these safety instructions carefully before starting to use the device! In the event of conflicting
information the details specified in the safety precautions shall apply.
In case of any doubt (in the form of translation or printing errors) the English version shall apply.
3. Faults and damage
If there is any reason to suspect that the safety of the device has been impaired, it must be withdrawn from use
and removed immediately from the hazardous-area. Measures must be taken to prevent it from being restarted
accidentally.
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 4 30.07.13 14:22
5
The safety of the device may be compromised, if, for example:
-There is visible damage to the housing.
-The device has been subjected to excessive loads.
-The device has been improperly stored.
-The device has been damaged in transit.
- Device markings or inscriptions are illegible.
- Malfunctions occur.
- Permitted limit values have been exceeded.
4. Safety regulations
Use of the XP3410 IS (SONIM XP STRIKE IS) intrinsically safe mobile phone assumes that the operator
observes the conventional safety regulations and has read the certificate of conformity in order to eliminate
faulty operation of the device.
The following points are to be observed:
-The device has to be protected against strong impacts.
-The device must be protected against permanent UV-radiation.
-The unit should not be used in close proximity to processes generating high charges.
- Friction of the housing should be avoided as far as possible for electrostatic reasons.
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 5 30.07.13 14:22
6
- Do not disassemble the device.
- Use only the original battery module “Ex-BPC 41“.
- Do not dismount the battery pack inside hazardous-area.
- It is not allowed to carry dismounted battery packs into the hazardous-area.
-
The battery module may only be charged outside the hazardous-area and only by using the Safety box “SBH 07”.
-The battery module may only be charged in a temperature range of 0 - 45 °C.
-
The data connection is only allowed outside the hazardous area and only allowed by using the Safety box “SBH 07”.
- For charging or data transfer first connect the Safety box “SBH 07” to the phone, then connect the the Safety
box “SBH 07” to an USB-A socket. If done differently, the Safety box “SBH 07” may get harmed.
- When changing the battery (outside hazardous-area), ensure that both the device and the battery module
are clean of dust and dirt.
- Only accessories approved by ecom instruments GmbH may be used. See relevant product page at www.
ecom-ex.com.
-The wired headset may not be used inside potentially explosive areas.
- Only accessories specifically certified for use with this equipment inside potentially explosive areas may be
connected, such as the C-C550 IS Remote Speakter Microphone certified under Intertek Authorization to
mark no. 3153168.
- It must be ensured that the device is not taken into zones 0 or 20.
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 6 30.07.13 14:22
7
5. Ex-Data
5.1 NEC
Ex-Marking: IS Class I, Division 1, Groups A-D T4
IS Class II, Division 1, Groups E-G T4
IS Class III, Division 1
Ambient temperature :Ta -20 °C ... +55 °C
Approved for Division 1 and 2 Class I, II, III.
6. Specifications
Networks: CDMA 850/1900 MHz
Bluetooth: 2.1 +EDR (AVRCP,A2DP, GAVDP, HFP1.5, HSP, GOEP, OPP)
Display: 5 cm (2 inch), 240 x 320 pixels
Power supply: Ex-BPC 41, Li-Ion 3.7V
Dimensions (without battery): 126 x 60 x 25 mm
Weight (including battery SC): approx. 210 g
Protection class: IP68
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 7 30.07.13 14:22
8
7. Changing the battery
Changing the battery is allowed only outside hazardous-area!
Please also observe section 4. Safety regulations.
1. If the battery is mounted, switch off the phone and turn the battery module’s screws anti-clockwise with a
suitable screwdriver.
2. Lift the battery module at the top side between the screws.
3. Insert a MicroSD card (max. 16 GB) if needed.
4. Insert the battery module by first placing the noses on the bottom side of the battery module into the
respective holes in the phone’s housing at its bottom. Press the battery module down at the top side and
tighten the screws of the battery compartment clockwise with a suitable screwdriver.
Do not overtighten the screw!They need to be fastened hand-tight!
5. Charge the mobile phone:The battery supplied with the phone is not fully charged. It is recommended to
charge the phone for five hours before using it for the first time.The full capacity of the battery is reached
after 3-4 complete charge/discharge cycles.
Note:
-There is a risk of explosion if the battery is not exchanged properly or if it is exposed to a flame.
- Do not short-circuit the battery.
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 8 30.07.13 14:22
9
-The battery does not contain any parts that can be exchanged.
-The casing of the battery should not be opened under any circumstances.
- Only accessories certified Intrinsically Safe may be used for charging (see point 4).
-The use of other chargers or batteries is not permitted.
Ex-protection cannot be guaranteed in this case.
- Used batteries are to be disposed of properly.
- If the phone is not going to be used for a prolonged period, the battery should be removed.
-The battery module should only be stored within a range of -20 °C
to +35°C (for up to 6 months) or within a range of -20 °C to +45 °C (for up to 1 month).
-The charge level of the battery module should be checked after 6 months at the latest in order to prevent
deep discharge.
-The phone should not be connected to the charger if the battery is not inserted.
- If the battery is completely discharged, the phone will not switch on and the display will not show a charging
process. Connect the phone to the charger. After charging for a few minutes the display will appear again and
you can then switch on the phone.
- Battery usage by children should be supervised.
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 9 30.07.13 14:22
10
8. Safety precautions for the battery
Damaged batteries and chargers should be removed from use and sent to ecom instruments GmbH for
inspection.
Note:
- Extreme temperatures can have an adverse effect on charging the battery module.
- Do not dispose of the battery module in a fire.
- Do not short-circuit the battery module.
- Dispose of the battery module in accordance with local regulations.
- Do not dispose of the battery module with normal household waste.
High quality lithium-ion batteries are used in your XP3410 IS (SONIM XP STRIKE IS).These batteries have
numerous advantages in everyday use, such as a low weight and high capacity in a nevertheless compact
construction. In addition these batteries also exhibit practically no memory effect. However, these batteries are
susceptible to a natural ageing process which impairs their functionality.
Modern batteries today have a lifespan of around 500 charge cycles, which, when used daily, corresponds to a
service life of approximately 2 years.The ageing process increases rapidly after this period, which means that
the batteries are deemed technically defective after 500 charge cycles. Moreover, the batteries could blow up
and cause irreparable damage to your device in a worst case scenario.
SHW_SONIM_XP_STRIKE_PA000457_EN_ES.indd 10 30.07.13 14:22
