Eaton HALO Home User manual

HALO Home Twin LED Floodlight

Quick Start Guide

Smart Outdoor Security - Flood

1Install the Smart Outdoor Security Flood in your desired location. (See enclosed instructions sheet.)

1. Light blinks once and then dims down to 5% at 3000K to indicate being unclaimed. It blinks twice on subsequent

power cycles.

Notes:

• Light blinks twice on power up after a factory reset or if it is unclaimed.

• Light blinks once to indicate it has just been claimed. It restores the saved dimming and CCT levels on

subsequent power cycles.

• Light retains state on power cycle for factory reset, unclaimed and ON state.

If light was OFF (using App or schedule), after one power cycle, it restores ON

state prior to OFF. Dimming and CCT will be restored.

Do not use with existing dimmers.

2Download the HALO Home app to your smart mobile device.

5www.eaton.com/HaloHome

3Create a user account and validate via email

Note: Skip to Step 4 if you already have the app.

•Enter your email address as your user account name.

•Select a password of at least 8 characters from the mobile

application “register” screen.

4Adding a ﬂoodlight to the app

1. Press “+” on the HALO Home App screen to add the ﬂoodlight.*

* At least one HALO Home ﬂoodlight (or compatible device) will need to be installed

and powered in order to add it to the HALO Home App device list.

FLOODLIGHT

Tap to add

FLOODLIGHT

Tap to add

Setting up a schedule

1. To set up a new schedule, follow these steps:

2. Once you have claimed a device, tap the “ ” icon to the right of your device’s name.

3. Tap the calendar icon on the slider. And tap the “+” button.

4. Using the dial, set your desired time.

5. Tap the days of the week that you want the schedule applied to.

6. Tap “Save” and give your schedule a unique name.

5Adding a ﬂoodlight to the app continued

1. The app will search for your installed lights.

2. Select the light and click “Done” to complete the pairing process.

3. The light blinks once to indicate it has been claimed. It restores the saved dimming and

CCT levels on subsequent power cycles.

* The app works only when your HALO Home compatible device is powered and within about

100 feet of your smart mobile device.

6www.eaton.com/HaloHome

cálido fresco

Reset to Factory Setting

•Using the wall switch repeat the process 4 times (OFF for 3 seconds + ON for 6 seconds).

•The LED ﬂoodlight will ﬂash twice after a successful reset.

Dimming

•The LED ﬂoodlight will dim from to 5% using the mobile app.

Color Tuning

•Use the mobile app to adjust Color Temperture (CCT) of the

bluetooth LED ﬂoodlights.

Creating a group

1. At the top left, press the “ ” menu icon and click on Groups to access the new grouping page.

2. Tap the large plus sign in the center of the screen, or in the top right corner, to make your ﬁrst

group. Then enter a unique name for your group and tap “Done.”

3. Touch and drag devices from the bottom of the screen towards the top of the screen to add them

to your Group repeat to add more and press next.

4. That’s it! After your group is saved, you will be brought to the “Group Settings” menu.

HALO Home Quick Start Guide - Smart Outdoor Security Flood
