Dynojet Power commander 3 User manual

2002-2003 Honda CBR954RR - PCIII USB - 1i110-411

2000-2001 Honda CBR954RR

Installation Instructions

Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 (800) 992-4993 www.powercommander.com

Parts List

1 Power Commander

1 USB Cable

1 CD-ROM

1 Installation Guide

1 Power Adapter

2 Power Commander Decals

2 Dynojet Decals

1 Velcro®Strip

1 Alcohol Swab

You can also download the Power

Commander software and latest maps

from our web site at:

www.powercommander.com

The ignition MUST be turned

OFF before installation!

PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

Button Adjustment Display

Faceplate Buttons

Expansion Port USB Port

1) Remove the main seat.

2) Open the passenger seat hatch.

3) Remove the fuel tank mounting bolts.

NOTE: The fuel tank does not need to be

removed in order to install the PCIII.

If you choose to remove the fuel tank

to aid in the installation, then all fuel

must be drained prior to disconnect-

ing the fuel lines.

4) Locate the main injector harness con-

nector. It is on the right side of the

chassis near the fuel hose fitting on

the throttle bodies.

5) Disconnect the injector harness

connector.

6) Plug the male connector from the

PCIII into the female connector on the

main harness (Fig. A).

7) Plug the female connector from the

PCIII into the male connector from

the stock injector harness (Fig. B).

8) Route the harness from the PCIII

under the fuel tank towards the tail

section.

9) Reinstall the fuel tank making sure

not to pinch the PCIII harness.

10) Attach ground wire from PCIII to

negative terminal of the battery.

(Fig. C)

Fig. AFig. B

Fig. C

2002-2003 Honda CBR954RR - PCIII USB - 2i110-411 www.powercommander.com

Connector from stock

injector harness

Connect ground wire from

PCIIIUSB to battery ground

Connector from

main harness

Connector from Power

Commander III USB

Connector from Power

Commander III USB

11) Route the PCIII and wiring under the

rear seat subframe. Attach to inner

fender below passenger seat using

supplied velcro (Fig. D).

12) Reinstall main seat.

Fig. D

2002-2003 Honda CBR954RR - PCIII USB - 3i110-411 www.powercommander.com
