Duronic PS391 User manual
PS391 - Paper Micro Cut Shredder
3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
3
8
13
18
23
Contents
Instrukcja obsługi. Polski 28
3
English Manual
4
Caution
Setup
1. Never allow children to shred or to play with the
paper shredder, or else, serious injury could occur.
2. Do not place hands or fingers into the shredde ,
as it could result in serious injury.
3. Never spray canned air or any type of lubricant
into the shredder, while the shredder is plugged in.
4. Never place any lubricants or cleaning solutions
into the paper shredder, as it could result in serious injury.
5. Keep all loose articles of clothing;
ties, jewelry, hair or other items away from
the feed opening, in order to prevent injury.
6. Remove all paper clips and staples from paper before shredding.
The shredder will cut staples and small paper clips,
however, discretion is recommended.
7. Keep the shredder turned off or unplugged,
when not in use for prolonged periods of time.
8. When manually changing feed direction, pause long enough
for the motor to stop, to avoid possible damage to the motor.
9. Turn off and unplug the shredder prior to moving,
cleaning or emptying the wastebasket.
10. Empty the wastebasket frequently to avoid possible paper jams
caused by shredded material being pulled back into the cutter assembly.
1. After removing all of the packing material from the shredder,
place the wastebasket on a flat surface
The shredder head can now be placed on top of the wastebasket.
The wastebasket is designed to accept the shredder head, in either
direction. Ensure the shredder head fits flush on top of the wastebaske
2. Plug the power cord into a standard 230-240V AC outlet,
which is installed near the shredder.
3. To open and power on the shredder, place thumbs in
the recess areas on the top cover and slide the cover towards
the read until the feed opening and switch selector is accessible.
4. Place the switch in the auto position.
The Power LED will light up, which means, the shredder is ready to use.
5
Operation
Shredder Capacity
Note
With the electrical cord plugged in, the switch in the auto position and the
shredder assembled, the power LED will light up.
This means the the shredder is now set for operation.
When paper is inserted into the feed opening,
the shredding process will start, and stop when
the paper has completed its travel through the feed opening.
The main switch is located on the top of the shredder,
the main switch has four settings.
1. When the auto switch is selected, the shredding process
will start when paper is inserted into the feed opening
and will continue until it has passed through the opening.
2. The reverse switch is used to assist in the removal of a paper jam,
which reverses the shredding process, prior to a completed forward cycle.
When switching from auto to reverse, always stop in the off position,
in order to prevent possible damage to the motor.
3. The off Position is also used to terminate the AC power
to the shredder. It is recommended to slide to the off position,
while emptying the wastebasket or when the shredder
is not in use for a prolonged period of time.
4. The forward switch is used to assist in clearing any
excess paper from the cutter after the completion of a shred cycle.
The PS391 will shred up to 3 sheets of A6 paper,
and will accept paper widths up to 115mm.
When shredding small materials like envelopes or receipts,
insert them into the middle of the paper feed opening.
The Power LED will not light up if the unit is in the off position,
or if the shredder head is not positioned on top of the wastebasket.
6
Paper Jams and Motor Overload Protection Circuit
The PS391 is equipped with an automatic motor overload protection
circuit. The manufacturer’s suggested running time at maximum capacity
is 3 sheets of A4 / 6 sheets of A6 paper. The continuous running time is 2
minutes on and 30 minutes off. The PS391 will automatically terminate
power in case of the following abnormal situations:
1. Operating the shredder at the maximum 3-sheet A4 paper
capacity continuously for a prolonged period of time.
2. Exceeding the shredding capacity, eg, inserting more than 3 sheets of A4
paper in one pass, or if the paper is not fed squarely into the feed opening.
Both abnormal operations might result in the activation
of the automatic thermal motor overload protection circuit,
which terminates the power to the shredder.
A paper jam could cause the thermal motor overload protection to terminate
AC Power to the motor. Never allow the shredder to remain in a jammed con-
dition with the AC power turned on.
In case of a minor paper jam:
1. Place the slide switch into the reverse position and pull
the remaining sheets of paper out of the feed opening.
Remove the un-shredded portion of paper from the top
and clear any excess paper shreds from the feed opening.
Be sure to keep fingers and personal e fects from the throat
of the feed opening, while the shredder cutters are in motion.
In case of a major paper jam:
1. Place the main switch into the off position or unplug the
power cord from the AC outlet and wait at least 30 minutes
for the thermal overload protection to reset.
2. Plug in the AC power cord and place the switch into the auto position.
If paper was left inside the feed opening prior to the overload,
place the switch into the reverse position and grasp the excess paper
from the top and pull it out.
Be careful not to place fingers near the feed opening, or it could result i
serious harm. Clear excess paper shreds from the feed opening.
3. The paper shredder is now ready to be used.
7
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions
contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect,
inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work,
under the guarantee
7. Valid in the UK only
This product is tted with CE:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.
8
Manuel d’utilisation en français
9
Avertissements de sécurité
Installation
1. Ne laissez pas les enfants jouer avec cet appareil, de sérieuses blessures
physiques pourraient autrement s’ensuivre.
2. Ne placez pas vos mains ou doigts à l’intérieur de l’appareil, de sérieuses
blessures physiques pourraient autrement s’ensuivre.
3. N’utilisez pas de vaporisateurs pour nettoyer ou lubrifier l’appareil tant que
l’appareil est branché.
4. N’insérez pas de lubrifiants ou de détergents non prévu pour ce type
d’appareil.
5. Gardez vos vêtements, bijoux, cheveux et autres objets hors de portée de
l’ouverture du destructeur de documents, de sérieuses blessures physiques
pourraient s’ensuivre.
6. Retirez les épingles de sureté et autres trombones avant de détruire vos
documents. L’appareil peut détruire ces éléments mais ce n’est pas
recommandé pour prolonger la durée de vie des lames et du moteur.
7. Gardez l’appareil éteint ou débranché lorsqu’il n’est pas utilisé pour une
période prolongée.
8. Lorsque vous changer la direction de l’appareil (marche avant / marche
arrière), veuillez patienter que l’appareil s’arrête afin d’éviter d’éventuels
dommages moteurs.
9. Eteignez et débranchez l’appareil avant de le déplacer, de vider ou de
nettoyer le réservoir.
10. Videz le réservoir fréquemment pour éviter tout bourrage de papier, ce qui
pourrait autrement provoquer le retour du papier.
1. Après avoir retiré tous les emballages, veuillez placer le réservoir sur une
surface plate puis placez la tête au-dessus du réservoir. Le réservoir est conçu
pour accepter la tête dans les deux sens. Assurez-vous que la tête soit
soigneusement insérée.
2. Branchez l’appareil en vous assurant de respecter le voltage de l’appareil.
3. Pour allumer l’appareil, faites coulisser le couvercle jusqu’à ce que l’ouverture
et l’interrupteur soit accessible.
4. Appuyez sur l’interrupteur en position « auto ». La lumière s’allumera ce qui
signifie que l’appareil est prêt à l’utilisation.
10
Utilisation
Capacité
Note
Lorsque l’appareil est branché et que l’interrupteur est en position
automatique, la lumière s’allumera. L’appareil est prêt à l’utilisation.
Lorsqu’un document est inséré, le processus de destruction démarrera
et s’arrêtera une fois la destruction des documents achevée.
L’interrupteur dispose de 4 paramètres :
1. Lorsque la position « auto » est sélectionnée, l’appareil s’allumera lorsque du
papier est inséré.
2. La fonction « reverse » permet de lancer la marche arrière en cas de bourrage de
papier. Lorsque vous passer du mode automatique à la marche arrière, veuillez
toujours patienter que l’appareil se soit arrêté afin d’éviter d’endommager le moteur.
3. L’interrupteur « OFF » permet d’éteindre l’appareil. Il est recommandé d’éteindre
l’appareil lorsqu’il n’est pas utilisé fréquemment.
4. La fonction « forward » permet de forcer la marche avant de l’appareil. Ceci a
pour intérêt d’aider l’appareil à se débarrasser d’éventuels débris qui seraient restés
coincé.
L’appareil permet de détruire jusqu’à 3 feuilles A4 / 6 feuilles A6 et
acceptera du papier de 115 mm d’épaisseur. Pour détruire des
documents plus compacts, tels que des enveloppes ou des reçus par
exemple, insérez-les au milieu de l’ouverture.
L’indicateur lumineux ne s’allumera pas si l’appareil est éteint
(position « OFF ») ou si la tête n’est pas correctement insérée sur le
réservoir.
Table of contents
Languages:
Other Duronic Paper Shredder manuals
Duronic
Duronic PS591 User manual
Duronic
Duronic PS410 User manual
Duronic
Duronic PS285 User manual
Duronic
Duronic PS815 User manual
Duronic
Duronic PS991 User manual
Duronic
Duronic PS609 User manual
Duronic
Duronic PS132 User manual
Duronic
Duronic PS571 User manual
Duronic
Duronic PS712 User manual
Duronic
Duronic PS657 User manual
Popular Paper Shredder manuals by other brands
Swingline
Swingline STACK-AND-SHRED200X&200XL 60X Start here
GBC
GBC ShredMaster CC055 instruction manual
UNITED OFFICE
UNITED OFFICE UAV 190 A1 operating instructions
UNITED OFFICE
UNITED OFFICE UAV 190 A1 operating instructions
Rexel
Rexel Optimum AutoFeed+ 45X instruction manual
Martin Yale
Martin Yale 227284S1 instruction manual
