Dji MAVIC PRO User manual

Using this manual

Legends

Warning Important Hints and Tips Reference

Read Before the First Flight

Read the following documents before using the MAVICTM Pro:

1. In the Box

2. Mavic Pro User Manual

3. Mavic Pro Quick Start Guide

4. Mavic Pro Disclaimer and Safety Guidelines

5. Mavic Pro Intelligent Flight Battery Safety Guidelines

TM website and read the Disclaimer



User Manual for more details.

Video Tutorials

Please watch the tutorial videos at the link below, which demonstrates how to use Mavic Pro safely:

http://www.dji.com/mavic

Download the DJI GO App

Download and install the DJI GOTM app before using the aircraft. Scan the QR code to

the right to download the latest version.

The Android version of the DJI GO app is compatible with Android 4.1.2 or later.

The iOS version of the DJI GO app is compatible with iOS 8.0 or later.

Download the DJI Assistant 2

Download the DJI Assistant 2 at http://www.dji.com/mavic/download

Searching for Keywords



Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that section.

Printing this Document

This document supports high resolution printing.

Contents

Using this manual 2

Legends 2

Read Before the First Flight 2

Video Tutorials 2

Download the DJI GO App 2

Download the DJI Assistant 2 2

Product Proile 6

Introduction 6

Features Highlights 6

Preparing the Mavic Pro 6

Aircraft Diagram 8

Remote Controller Diagram 8

Aircraft 11

 11

Flight Mode 11

Flight Status Indicator 12

Return-to-Home (RTH) 13

TapFly 17

ActiveTrack 19

Gesture Mode 21

Forward and Downward Vision System 22

Flight Recorder 25

Attaching and Detaching the Propellers 25

Intelligent Flight Battery 26

Remote Controller 31

 31

Using the Remote Controller 31

Linking the Remote Controller 36

Camera and Gimbal 38

 38

Gimbal 39

DJI GO App 41

Equipment 41

Editor 46

SkyPixel 46

Me 46

Flight 48

Flight Environment Requirements 48

Flight Limits and No-Fly Zones 48

 49

Calibrating the Compass 50

Auto Takeoff and Auto Landing 51

Starting/Stopping the Motors 52

Flight Test 52

Appendix 55

 55

Firmwares Update 56

Intelligent Flight Mode 57

Remote Controller LCD Screen Menu Information 58

After-Sales Information 59

Compliance Information 59

Product Proile

This section introduces the Mavic Pro

and lists the components of the aircraft

and remote controller.





Product Profile

Mavic Pro User Manual

Aircraft Diagram

Remote Controller Diagram

1.Propeller

2.Motor

3.Front LED Indicator

4.Forward Vision System

5.Landing Gear



6.Gimbal and Camera

.Intelligent Flight Battery

8.Link Button

9.Linking Status Indicator

10.Camera Micro SD Card Slot

11.Control Mode Switch

12.Micro USB Port

13.Aircraft Status Indicator

14.Downward Vision System

1. Antennas

Relays aircraft control and video

signal.

2. Return to Home (RTH) Button

Press and hold the button to initiate



again to cancel RTH.

3. Power Button

Used to turn the remote controller on

and off.

4. Control Stick

Controls the orientation and

movement of the aircraft.

1413

Product Profile

1716

10. C1 Button



Set these values based on your preference

in the DJI GO app.

Press once to focus on the center or add a

waypoint when using Waypoints.

11. C2 Button



Set these values based on your preference

in the DJI GO app.

Press once to playback / or delete a

waypoint when using Waypoints.

12. Gimbal Dial

Control the camera's tilt.

13. Camera Settings Dial

Turn the dial to adjust camera settings.



is connected to a mobile device running



14. Record Button

Press to start recording video. Press again

to stop recording.

5. LCD Screen

Displays the aircraft and Remote Controller's

system status.

6. Flight Pause Button

Press once for emergency breaking.

7. 5D Button



these values based on your preference in

the DJI GO app.

Left: Zoom In

Right: Zoom Out

Up: Camera Forward

Down: Gimbal Downward

Press inward: Call out Intelligent Flight menu

in DJI GO app.

8. Mobile Device Clamp

Securely mounts your mobile device onto

the remote controller.

9. USB Port

Connect to mobile device for running the DJI

GO app.

15. Shutter Button

Press to take a photo. If burst mode is

selected, the set number of photos will be

taken with one press.

16. Power Port

Connect to the Charger to charge the

battery of the remote controller. Connect

this port to your mobile device using the RC

cable.

17. Flight Mode Switch

Switch between P-mode, S-mode.

Aircraft

This section introduces the features of

the Flight Controller, Forward and Down-

ward Vision System, and the Intelligent

Flight Battery.
