Digitax M1 mdt Assembly instructions
Technical Manual
Installation and Programming
ver.1
16/12/2014
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
3
Introduction ............................................................................................................ 4
About this Manual .................................................................................................. 4
Appearance............................................................................................................. 5
How to Seal the Taximeter ...................................................................................... 6
Regular Way of Sealing the Taximeter ..................................................................... 6
Measures ................................................................................................................ 7
M1 MDT Navigator Taximeter Display ..................................................................... 8
Display Composition and Inscriptions...................................................................... 8
M1 MDT Navigator MID Taximeter Display Area...................................................... 9
Functional area for Developer’s Applications........................................................... 9
Electrical Connection Table...................................................................................... 10
Specifications .......................................................................................................... 11
Mechanical Movement Sensor ................................................................................ 12
How to assemble the sensor box............................................................................. 12
Test Connector ........................................................................................................ 13
“E-Seal”- Electronic Sealing:.................................................................................... 14
1st Section: Last 100 Reading Changes Done ........................................................... 14
“E-Seal”- Electronic Sealing:.................................................................................... 15
2nd Section ............................................................................................................. 15
For Hire - Hired - Stopped........................................................................................ 16
The Operative Mode ............................................................................................... 16
Pre-Selection of the Tariff........................................................................................ 17
The K-Constant........................................................................................................ 18
(Car Transmission Ratio).......................................................................................... 18
Time Synchro........................................................................................................... 19
Time and Date setting ............................................................................................. 20
How to set the taximeter’s time and date ............................................................... 20
Diagnostic Tariff Test (Check Sum) ........................................................................... 21
Statistical Memory .................................................................................................. 22
How to Read the Locations Memory Content .......................................................... 22
Statistical Memory .................................................................................................. 23
How to Print Locations Memory Content................................................................. 23
Statistical Memory .................................................................................................. 24
How to Erase the Locations Memory Content.......................................................... 24
“Trip by Trip”........................................................................................................... 25
Events Memory Buffer............................................................................................. 25
“Trip by Trip”........................................................................................................... 26
Print Out Format ..................................................................................................... 26
Ticket Print Out: Settings......................................................................................... 27
The Tariff................................................................................................................. 28
General Description................................................................................................. 28
The Tariff................................................................................................................. 29
How to Program the Tariff ....................................................................................... 29
Tariff Show .............................................................................................................. 30
Tariff Show .............................................................................................................. 31
The “ProgDate” ....................................................................................................... 32
Programming Keys................................................................................................... 33
Programming Parameters ........................................................................................ 34
Connectors and Cables ............................................................................................ 53
Windows RS232/USB............................................................................................... 54
User and Demo Software ........................................................................................ 55
Software Developing - Getting Started .................................................................... 72
Communications - Getting Started........................................................................... 73
Connection Service.................................................................................................. 75
Digitax AITP-Taximeter Service ................................................................................ 78
Notes: ..................................................................................................................... 79
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
4
The is designed to be, at the same me, easy to use and extremely powerful.
This manual is conceived to be user friendly, more graphical and easy to understand.
In the first secon are described the electrical connecons, the ways to fix and lead the taximeter,
how to assemble the sensor box.
The second secon explain the meter’s operave modes, the funcons and the programming
phase (Autotest, Stascal Memory, “Trip by Trip” buffer and the Tariffprogramming).
The third secons contains the descripon of all the tariffprogramming parameters.
Introducon
About this Manual
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
5
Main Connectors Panel
Appearance
Main Connectors Panel
1Microphone
2Command Taximeter Keys
3Cover Wires
4Label
5SIM Card
6Wires Connecon
7MDT ON / OFF
8Label
9Label
10 TariffSeal
11 Micro SD
12 Manufacturer Seal
13 Speaker
13
12
7 8 9 10 11
5
3
4
6
2
1
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
6
How to Seal the Taximeter
Regular Way of Sealing the Taximeter
2
13
4
5
6
4
Taximeter’s Seals
1TariffProgramming Seal Cover
2Taximeter Manufacturer Seal
3MICRO SD Seal
4Car Fixing Seal
5SIM Seal
6Wires Seal
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
7
Top
Front
Dimensions (in millimeters)
Width
289
Height
88,3
Depth
28
Weight (in grams)
M1 mdt
500
Measures
289 mm
88,3 mm 28 mm
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
8
M1 mdt Taximeter Display
Display Composion and Inscripons
6
Metrological Inscripons Plate
Fare Display
Day / Night Indicaon
Status (For Hire, Hired, Stopped)
Movement detecon status (when it-s blinking)
Secondary Display
TariffIndex
Descripon (extras / me)
Currency depending on the Country indicaon
1
2
3
4
5
6
7
E-Mark Number
Approval E-Mark Number
EC. Type examinaon
cerficate number
Nofied Body Number
CE Mark
Verificaon Year
Temperature range
Voltage range
K-Constant range
1
2
3
4
5
*
*
7
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
9
M1 mdt MID Taximeter Display Area
Funconal area for Developer’s Applicaons
MID Taximeter Area:
This area is used only by the taximeter
Developer’s Functional Area:
This area is a functional area for developer’s applications
Note:
The MID Taximeter Area cannot be overwrien by user’s applicaons
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
10
Electrical Connecon Table
MECHANICAL TRANSDUCER
or
CAR ODOMETER INPUT
PRINTER
GREY
VIOLET
GREEN
YELLOW
Passenger Sensor
PINK
RED
RED
BLACK
fuse 2 A
fuse 2 A
fuse 2 A
fuse 2 A
fuse 2 A
fuse 2 A
CAR LIGHT SWITCH
+12 V
BROWN
WHITE
fuse 2 A
* For Detailed pin-out connecon go to the “Connector and Cable” Chapter (page 15)
GREEN
YELLOW
Detailed pin-out on
“Windows RS232 / USB”
Chapter - page 54
