DFI GH960 User manual

SPI Flash BIOS

CPU Fan

Standby Power LED

Ryzen

V1000/

R1000

AMD

DDR4_2

DDR4_1

1 3

14 8

132

128

3 4

1 3

E B

B E

613

6 1

A C

AC AC

A C

C A

A C

D110

C110

A110

B110

REV.A

GH960

LC8700

LC8200

U30

VR8401

VR8400

VR1

U8902

U8901 U8900

U8202

U8201

U8700

U8200

U31

U28

U29

U48

U16

U18

U17

U32

U34

SC9000

Q8201

Q8001

Q8600

Q8601

Q8003

Q8000

Q8002

Q8100

Q21

Q19

Q17

Q8901

Q8203

Q8202

Q8200

Q25

D8900

D14

U39

SC9212

SC9216

SC9213

SC9201 SC9200 SC9203 SC9205

SC9215

SC9202

SC9204

SC9214

SC9210

SC9209

SC9208

SC9207

SC8901

SC8900

Q8900

LC8901 CN2

COM Express B2B

D110

C110

B110

A110

Bottom View

Top View

www.dfi.com

Quick Reference

GH960

Board Layout

933-GH9601-000G A-580-Q-2003

Pin Assignments

Assembly

CPU Fan

Pin Assignment

1Ground

2Power

3Sense

Carrier Board

COM Express module

CPU Cooler

A CPU cooler is included in the standard package. The CPU cooler contains six spring screws

and shall be installed after the COM Express module is securely mounted onto the carrier

board. Please make sure the cooler, the module, and the carrier board are oriented correctly by

inspecting whether the screws, screw holes, and stand-offs all align.

2Quick Reference | GH960

2. Place the module on the carrier board while making sure the mounting holes and connec-

tors all align. At the long edge of the module closer to the connector, apply rm pressure onto

the module and press it onto the the carrier board until the three stand-offs and the edge of

the module close up. The other edge of the module away from the connector may still remain

slightly aloft from the stand-offs at this moment.

3. At the long edge away from the connector, apply rm pressure with another hand onto the

module and press it onto the carrier board until the module is against the remaining three

stand-offs. Please also maintain the pressure described in the previous step the whole time.

1. Locate the COM Express board-to-board connec-

tors on the bottom side of the module and the carrier

board. Locate the mounting holes (A-F) on the mod-

ule and the corresponding stand-offs on the carrier

board.

1 3

14 8

132

128

3 4

1 3

E B

B E

613

6 1

A C

AC AC

A C

C A

A C

D110

C110

A110

B110

AB C

Bottom View

3Quick Reference | GH960

DFI reserves the right to change the specifications at any time prior to the

product's release. This QR may be based on editions that do not resemble your

actual products. For more documentation and drivers, please visit the download

page at go.dfi.com/GH960, or via the QR code to the right.

4. Inspect whether the gaps between the module and the stand-offs all close up. It is highly

recommended that the module be removed and installed again following the previous steps

when there is discernable gap.

5. Place the CPU cooler, i.e. heatsink and fan, onto the module while making sure the screws

on the cooler align with the screw holes on the module. The thermal interface metals under-

neath the cooler should also sit directly on top of the CPU and PCH chipsets on the module.

Use a screw driver to fasten the screws in the order as numbered below. By following the or-

der, the risk of damaging the component is signicantly reduced.

4Quick Reference | GH960
