Dexter Laundry C Series User manual

USE THE BLUE TABS LOCATED ON THE

RIGHT AND LEFT SIDES OF THE FOLLOWING

DOCUMENT TO ADVANCE TO EACH SECTION.

8533-115-001 3/22

C-Series Accessories

WC0350XB-12EC4X 208-240 volts 60hz. Single Phase or Three Phase

WC0450XB-12EC4X 208-240 volts 60hz Single Phase or Three Phase

Key Description T-350 T-450 QTY

* Kit, Door Gasket Expander (large) 9732-139-002 9732-139-002

* Kit, Door Gasket Expander (small) 9732-139-001 9732-139-001

* Hose, Water Supply 3/8” I.D. x 48” 9990-027-011 9990-027-011 2

*Washer, Inlet Hose (furnished) 8641-242-000 8641-242-000 2

*Strainer, Inlet Hose (furnished) 9565-003-001 9565-003-001 2

* Bevel Washer for 5/8” bolt used in installations using angle iron bases 8641-586-002 8641-586-002

* Bevel Washer for 3/4” bolt used in installations using angle iron bases 8641-586-003 8641-586-003

*Sealing compound 8538-151-001 8538-151-001

*TOR X#20 8545-051-002 8545-051-002

* Flow Restrictors (in dispenser ) 9475-002-002 9475-002-002 2

* Battery (used on Control PCB) 8612-001-001 8612-001-001

* Coin Bearing & Seal Kit 9732-219-008 9732-219-005

* Coin Box Assy, Blue Large 9807-099-002 9807-099-002 1

Coin Box Assy, Black Large 9807-099-004 9807-099-004 1

USB, Thumb Drive (Blank) 9150-045-001 9150-045-001 1

USB, Thumb Drive, W/File 9150-045-002 9150-045-002 1

* Mode Light Backing Window 9635-022-001 9635-022-001 1

2 3

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

Kits, Assemblies, & Common Parts

Coin Acceptor Components Part Number

Optical Coin Acceptor 9021-092-002

Optical Coin Switch Replacement 9801-099-001

Coin Drop Screws 9545-053-002

Retainer, Coin Acceptor 9486-149-001

Loading Door & Door Lock Components Part Number

Door Glass Gasket (Standard Door) 9206-419-001

Door Glass Gasket (Small Door) 9206-411-002

Door Handle Only (Large) 9244-091-001

Door Close Switch 9539-492-001

Door Lock Gear Motor Assembly 9922-015-001

Kit - Door Latching Assy. & Cam (replaces original Door Latching Assembly) 9732-347-001

Kit - Door Cam Replacement 9732-346-002

Kit - Locking Pawl Replacement 9732-346-001

Kit - Door Gasket Expander Kit (Small) 9732-139-001

Kit - Door Gasket Expander Kit (Large) 9732-139-002

Electrical Components Part Number

Transformer, Main 8711-004-001

Transformer, Control 8711-009-004

Main Control Board 9473-010-001

Kit-Replacement, Pressure Sensor (Only) 9732-315-001

VFD & Breaking Resistors Components Part Number

Breaking Resistor 200 Ohms 9483-004-002

Breaking Resistor 160 Ohms 9483-004-003

Delta E Drive Display 9150-044-001

MS 300 VFD Display 9150-058-001

Data Cable (56”) 9806-015-003

Drain & Water Valve Components Part Number

Kit - 3” Drain Valve Seal Replacement 9732-327-001

Drain Valve 3” 9379-202-001

Drain Valve 2” 9379-199-001

Water Valve (Dual) 9379-183-012

Diaphragm (Dual) 9118-049-003

Cabinet Components Part Number

Front Panel Screw 9545-008-014

Front Panel Finisher Washer 8641-585-001

Front Panel Spring Nut 8640-399-008

Top Soap Box Screw (Regular Chassis Only) 9545-008-012

Top Soap Box Spring Nut (Regular Chassis Only) 8640-399-007

5/16 Hex Screw, Common 9545-008-026

Top Lock Key #6324 9306-025-001

Cylinder Plug (1.5” Plastic) 9456-041-007

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Wiring Harness Part # by Model

Key Description T350 T450 QTY

Control Panel Wiring Harnesses

* Wiring Harness, Door Lock 9627-791-003 9627-791-003 1

*Wiring Harness, Drain/Thermo/DoorSol 9627-796-001 9627-796-001 1

* Wiring Harness, Relay Board to Control Board (P20/P21) 9627-793- 001 9627-793- 001 1

* Wiring Harness LED PCB Board to Control Board 9627-797-001 9627-797-001 1

Control Trough Wiring Harnesses

* Wiring Harness, Control Board to Relay Board (P8/P16) 9627-794- 001 9627-794- 001 1

* Wiring Harness, Water Valve to Relay Board (P19) 9627-795-003 9627-795-003 1

*Harness, Control Board (P5) to Pressure Switch 9627-908-003 9627-908-005 1

* Wiring Assembly, Fuse (Red 7”) 9631-381-001 9631-381-001 3

* Wiring Assembly, Terminal Block to Control Transformer (Blk/Red) 8220-001-230 8220-001-230 1

* Wiring Assembly, Terminal Block to Control Transformer (Blk/Blu) 8220-001-231 8220-001-231 1

*Harness, Power Terminal Block 9627-747-003 9627-747-003 1

Rear Channel Wiring Harnesses

* Wiring Assembly Jumper Yel (Water Valve) 8220-123-001 8220-123-001 1

* Wiring Assembly, Relay Board to VFD (Yel. 32”) 8220-064-023 8220-064-023 2

*Data Communication Cable 9806-015-001 9806-015-001 1

4 5

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

Section 8:

Parts Data

C-Series Vended

Regular Chassis

WC0350XA-12EC4X After Serial # W1.19225.020

WC0450XA-12EC4X After Serial # W1.19213.001

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Cabinet and Front Panel Group Part # by Model

Key Description T-350 T-450 QTY

Key Description T350 T450 QTY

1 Panel, Side (Left or Right) - stainless 9732-359-007 2

1Panel, Right Side-stainless 9989-640-001 1

1 Panel, Left Side - stainless 9989-640-002 1

2 Screw, (Side Panel to Base) 9545-018-018 9545-018-013 6

* Nut, Hex 1/4-20 UNC 8640-414-006 8640-414-006 6

*Pad-Foam, Side Panel 0904-904-001 0904-904-001 2

3 Vault Assembly, Coin 9942-040-002 9942-040-002 1

4Back-Coin Vault 9050-066-001 9050-066-001 1

* Screw, #10B x 1/2 9545-008-026 9545-008-026 8

5Chute-Coin 9119-032-001 9119-032-001 1

* Screw, 10B x 1/4 9545-008-001 9545-008-001 1

* Bracket, Side Panel under front panel 9029-263-001 9029-263-001 1

* Nut, Hex (to tub front) 8640-413-002 8640-413-002 2

* Screw, #10B x 1/2 9545-008-026 9545-008-026 2

6 Panel, Control (Mounts Nameplate) 9989-557-001 9989-558-001 1

* Screw, Control Panel to Sides 9545-008-026 9545-008-026 4

7 Nameplate Decal, Control Panel (Blue) 9412-209-002 9412-211-002 1

7 Nameplate Decal, Control Panel (Black) 9412-209-001 9412-211-001 1

8 Label-Nameplate, RH (Blue) 8502-744-002 1

8Label-Nameplate, RH (Black) 8502-744-001 1

*Stop Button Mounting Plate 9452-725-001 9452-725-001 1

9 Kit-Stop button with harness & Switch 9732-223-001 9732-223-001 1

10 Acceptor, Coin-Optical switch w/harness 9021-092-002 9021-092-002 1

*Retainer-Dual coin Acceptor 9486-149-001 9486-149-001 2

* Screws, Coin Acceptor 9545-053-002 9545-053-002 4

11 Panel Assy, Front 9454-893-001 9454-894-001 1

* Trim Edge Protector 9578-092-005 9578-092-005 1

* Screw, Hex- To Control Panel 9545-008-026 9545-008-026 2

* Nut, Spring- To Control Panel 10/32 8640-442-001 8640-442-001 4

12 Screw, Flat Head- Front to Sides 9545-008-014 9545-008-014 2

13 Washer, Finish 8641-585-001 8641-585-001 2

* Nut, Spring-To Front Panel 8640-442-001 8640-442-001 2

14 Label, Door Opening-Blue 8502-757-002 8502-757-002 1

14 Label, Door Opening-Black 8502-757-001 8502-757- 001 1

15 Label, Warning Risk of Injury-Blue 8502-759-002 8502-759-002 1

15 Label, Warning Risk of Injury-Black 8502-759-001 8502-759- 001 1

Key Description T350 T450 QTY

16 Bumper-Loading door 9051-055-001 9051-055-001 1

* Nut, 1/4-20 UNC, 2B 8640-414-003 8640-414-003 1

17 Door, Lower Service (includes handle & Rivits) 9960-286-001 9960-286-002 1

18 Handle (bumper guard) 9244-086-001 9244-086-002 1

*Rivet 9491-009-003 9491-009-003 4

19 Screw Mtg., Flat Head 9545-008-030 9545-008-030 2

20 Washer, Finish 8641-585-001 8641-585-001 2

*Nut, Spring 8640-399-008 8640-399-008 2

21 Coin Box Assy, Blue 9807-099-002 9807-099-002 1

21 Coin Box Assy, Black 9807-099-004 9807-099-004 1

6 7

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

6 7

12, 13

19, 20

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Cabinet and Front Panel Group Part # by Model Continued

Key Description T350 T450 QTY

22 Panel Top, Assembly (includes catch) 9989-498-002 9989-563-004 1

* Catch, Top Panel 9086-017-001 9086-017-001 2

*Rivit-Catch, Top Panel 8638-190-009 8638-190-009 4

23 Lock, Top (w/Key) 8650-012-003 8650-012-003 1

* Lock Spacer 9538-189-001 9538-189-001 *

* Key, Top- # 6324 6292-006-007 6292-006-007 1

*Cam, Loc k-Top 9095-049-001 9095-049-001 1

* Nut, 9/32 - 28 Hex 8640-426-001 8640-426-001 1

*Washer Flat 5/16 8641-581-008 8641-581-008 1

24 Screw, Locator 9545-008-023 9545-008-023 2

25 Plastic Sleeve, Locator 9355-001-001 9355-001-001 2

26 Locator Post 9467-024-001 9467-024-001 2

*Nut, Locator Post 8640-411-003 8640-411-003 2

27 Door, Dispenser 9108-095-005 9108-095-005 1

28 Post, Door Mounting 9467-025-001 9467-025-001 2

*Pin, Plain-SS 9451-191-001 9451-191-001 2

*Screw, Disp.Post Mtg 9545-045-002 9545-045-002 4

29 Dispenser, Soap 9122-005-004 9122-005-004 1

30 Gasket, Dispenser 9206-416-001 9206-416-001 1

*Nut,Spring-SS 8640-399-007 8640-399-007 4

31 Screw, Disp. Mtg 9545-008-012 9545-008-012 4

*Flow Restrictor 9475-002-002 9475-002-002 2

* Plastic Plug 1 1/2”-(inside cylinder) 9456-041-007 9456-041-007 1

*Hose-Dispenser outlet 9242-450-002 9242-450-002 1

32 Bracket, Side Panel under front panel 9029-263-001 9029-263-001 1

33 Nut, Hex (to tub front) 8640-413-002 8640-413-002 2

8 9

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

Notes

24, 25

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Rear View Access Part # by Model

Key Description T350 T450 QTY

1 Drive Motor, 3 Phase (Inverter duty) 9376-307-001 9376-319-001 1

2 Pulley, Motor 9453-180-001 9453-181-001 1

* Set Screw,Sq.Hd(motor pulley) 9545-028-015 9545-028-015 2

3 Rod, Motor Mtg 9497-222-002 9497-222-002 1

4 Screw (end of motor rod) 9545-029-005 9545-029-005 1

* Lockwasher (end of motor rod) 8641-582-014 8641-582-014 1

5Motor Bushing (Rubber) 9053-082-001 9053-082-001 2

6 Clamp-Worm, 316SS, 1.5" (for Rubber bushing) 8654 -117-019 8654-117-019 2

7Strap Bracket, Motor Tension 9029-206-001 9029-206-002 1

8 Nut, Strap to Motor 10/32 UNF 8640-413-002 8640-413-002 1

*Washer #10 8641-581-006 8641-581-006 1

9 Spring, Belt Tension 9534-319-002 9534-319-002 1

10 Pulley, Driven 9453-168-005 9453-168-006 1

* Tolerance Ring driven pulley 9487-234-001 9487-234-003 1

11 Screw 1/2-13x1 1/4” 9545-017-009 1

11 Screw 5/8-11x1/1/2” Driven pulley 9545-060-001 1

12 Lockwasher 1/2” 8641-582-016 1

12 Lockwasher 5/8” 8641-582-018 1

13 Washer, Flat 1/2” 8641-581-026 1

13 Washer, Flat 5/8x2 1/4” 8641-581-032 1

14 Drive Belt 9040-079-004 9040-079-005 1

15 Channel, Rear 9947-025-001 9947-026-001 1

16 Screw Mtg rear channel 9545-008-026 9545-008-026 4

* Nut, Spring Rear Channel MTG 8640-399-008 8640-399-008 4

17 Cover, Power Terminal Block 9074-267-001 9074-267-001 1

18 Screw, 9545-008-026 9545-008-026 1

19 Hose, Overow Vent Top 9242-463-002 9242-463-003 1

20 Clamp, Hose Vent 8654-117-008 8654-117-008 2

21 Hose, Overow to drain 9242-449-002 9242-449-002 1

22 Clamp, Hose overow to drain 8654-117-018 8654-117- 018 2

23 Hose, Pressure Switch 9242-175-000 9242-175-007 1

*Clamp, Pressure Switch Hose 8654-117-015 8654-117- 015 1

* Vaccuum Breaker Mtg Bracket 9029-266-001 9029-077-001 1

* Vaccum Breaker ALL 9610-001-001 9610-001-001 1

*Clamp, Hose to Vacuum Breaker 8654 -117-008 8654-117-014 1

24 Hose, Vacuum Breaker to tub 9242-458-001 9242-458-002 1

25 Plastic Plug 7/8” Electrical Connection 9456-041-006 9456-041-006 2

26 Bushing, 7/8 9053-067-002 9053-067-002 1

* Panel Assy., Back 9454-632-001 1

* Panel Assy., Back, Upper 9444-014-001 1

* Panel Assy., Back, Lower 9444-013-001 1

*Screw Panel Mtg.#10Bx1/2” 9545-008-026 9545-008-026 10

*Nut, Spring 8640-399-004 8640-399-004 6

* Screw, To Base-1/4x3/4 9545-030-002 9545-030-002 3

10 11

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

10 11

5, 6

11, 12, 13

114

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Cylinder, Seals & Bearings Part # by Model

Key Description T350 T450 QTY

* Bearings and Seal Kit 9732-219-008 9732-219-005 1

*Housing, Bearing- Assembly (items #2-#6) 9803-179-003 9803-186-001 1

2Housing, Bearing 9241-169-002 9241-180-002 1

3 Bearing, Front (LARGE) 9036-159-009 9036-159-005 1

4Bearing, Rear (SMALL) 9036-159-008 9036-159-004 1

5Spacer, Bearing 9538-158-001 9538-167- 001 1

6Ring, Bearing Retainer 9487-238-001 9487-238-003 1

7Tub Back Mating Ring 9487-261-002 9487-261-003 1

8Seal, Large 9532-140-009 9532-140-009 1

9 Seal, Small 9532-140-003 9532-140-006 1

10 Ring, Seal Mounting 9950-042-001 9950-048-001 1

11 Back Assy, Tub 2 piece 9732-016-001 9962-013-002 1

12 Bolt, Tub End of Bearing Housing (1/2” x 1 1/4”) 9545-017-009 6

12 Nut 1/2’ 8640-417-005 6

12 Flat washer 1/2” (ext. tooth) 8641-581-034 6

12 Bolt 5/8-11x1 1/2” Tub end of bearing housing 9545-060-001 6

12 Washer-Flat, 5/8” 8641-581-040 6

12 Lockwasher 5/8” 8641-582-018 6

12 Nut 5/8” 8640-425-001 6

13 Support Arm Assy, Bearing Housing 9991-057-002 9991-056-002 6

* Tub Alignment Spacer 9552-038-003 9552-038-003

14 Bolt Pulley End of Bearing Housing (3/8” x 1 1/2”) 9545-029-003 6

14 Nut, Flange Locking 3/8” 8640-415-004 6

14 Bolt Pulley end of bearing housing (7/16-14x2”) 9545-059-002 6

14 Nut, Flange Locking 7/16” 8640-416-005 6

15 Pulley, Driven 9453-168-005 9453-168-006 1

* Ring, Tolerance 9487-234-001 9487-234-003 1

16 Washer 1/2” 8641-581-026 1

16 Washer 5/8” 8641-581-032 1

17 Bolt 1/2-13 x 1 1/4” 9545-017-009 1

17 Bolt 5/8-11x11/2” 9545-060-001 1

18 Lockwasher 1/2” Ext. tooth 8641-582-016 1

18 Lockwasher 5/8 Ext. tooth 8641-582-018 1

* Cylinder Assy Before Serial # W1.20190.XXX 9732-354-002 9732-354-004 1

* Cylinder Assy After Serial # W1.20190.XXX 9848-164-001 9848-166- 001 1

* Tub and Cylinder Assy. 9869-029-001 9869-031-001 1

16, 17, 18

12 13

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

12 13

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Door Latching Assembly Part # by Model

Key Description T350 T450 QTY

33 Latching Assy, Complete (#1-22) (includes #1 thru #22) 9885-031-001 9885-031-001 1

1 Plate Assy, Door Lock 9982-346-001 9982-346-001 1

2Washer, Flat 8641-581-030 8641-581-030 1

3Actuator, Latching Switch 9008-005-001 9008-005-001 1

4Pawl, Locking 9732-346-002 9732-346-002 1

5Washer, Spring 8641-569-003 8641-569-003 1

6Ring, Retaining 9487-200-004 9487-200-004 1

7Bracket Switch 9029-163-001 9029 -163-001 1

8 Nut, Hex 10-32 UNF 8640-413-002 8640-413-002 2

9Spring, Actuating 9534-364-002 9534-364-002 1

* Door Stud Pin, 3/16” x 3/4” 9451-181-004 9451-181-004 1

8 6

Key Description T350 T450 QTY

10 Screw, Hx. 10-32 x 1” 9545-012-020 9545-012-020 1

11 Nut, Elastic Stop 10-32 8640-413-004 8640-413-004 2

12 Spring, Return 9534-364-001 9534-364-001 2

13 Pin, Guide 9451-193-001 9451-193-001 1

14 Ring, Retaining 9487-200-005 9487-200-005 1

15 Washer 8641-581-031 8641-581-031 1

16 Switch, Latching Sensing 9539-461-008 9539-461-008 1

17 Shield, Switch 9550-169-003 9550-169-003 3

18 Screw 4-40 x 5/8” 9545-020-001 9545-020-001 2

18 Nut, Twin 4-40 8640-401-001 8640-401-001 1

19 Switch, Locking Sensing 9539-461-007 9539-461-007 2

20 Actuator, Switch Locking 9008-006-003 9008-006-003 1

21 Screw 4-40 x 1 1/8” 9545-020-003 9545-020-003 2

21 Nut, Twin 4-40 8640-401-001 8640-401-001 1

*Spacer Sensor 9538-182-0 01 9538-182- 001 *

22 Pin, Dowel 9451-181-004 9451-181-004 1

* Shim, Door Lock, Thin 9552-037-001 9552-037-001 AR

* Screw, Lock mtg 1/4”-20 x 3/4” 9545-018-004 9545-018-004 3

* Lockwasher 1/4” Ext tooth 8641-582-007 8641-582-007 3

*Harness Door-Switches, P4 9627-791-003 9627-791-003 1

Switch, Door Hinge 9539-492-001 9539-492-001 1

Wire Assy, Red 8220-063-025 8220-063-025 1

Door Latching Assembly Part # by Model Contuied

14 15

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

14 15

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Gear Motor Door Lock Assembly

Key Description T350 T450 QTY

* Actuator Assembly (Includes 1-12, Rod NOT included) 9892-015-001 9892-015-001 1

1 Bracket Assy, Slide Lock Actuator 9985-190-001 9985-190-001 1

2 Bracket Assy, Slide - Unlock 9985-189-001 9985-189-001 1

3 Bracket Slide Lock 9029-204-001 9029-204-001 1

4Spacer, Plastic 9538-157-021 9538-157-021 4

5 Arm - Door Lock 9001-063-001 9001-063-001 1

6 Thermoactuator - Door Lock Relay 120v 9586-001-001 9586-001-001 2

7Spring - Extension 9534-350-001 9534-350-001 1

8 Motor & Gear Assembly 120v 9914-137-015 9914-137-015 1

9Screw -Hxwshrhdslsems, 6-32 x 3/16 9545-044-003 9545-044-003 6

10 Cross Recessed PAn Hd Tapping screw 9545-031-011 9545-031-011 4

11 Screw - hxwshdsl, 10-24 - 1.25f, ctd 9545-046-007 9545-046-007 4

12 Stando-Wire 9527-007-001 9527-007-001 1

* Rod, Door Lock 9497-225-011 9497-225-012 1

* Harness, Door Lock/Drain, P17 9627-796-001 9627-796-001 1

16 17

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

Notes

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

5 4

Loading Door Part # by Model

Key Description T350 T450 QTY

* Loading Door, Complete #1-10 9960-308-001 9960-309-001 1

1 Loading Door, Ring 9487-264-002 9487-265-002 1

2Gasket, Loading Door 9206-411-002 9206-419-001 1

3Window, Loading Door 9635-018-001 9635-016-001 1

* Shaft Assy, Locking (includes 4 thru 7) 9913-136-001 9913-136-001 1

4 Shaft, Door Locking 9537-195-002 9537-195-002 1

5Cam, Locking 9095-051-001 9095-051-001 1

6 Pin, Groove (1 1/4) 9451-181-005 9451-181-005 1

7 Pin, Groove (3/4) 9451-181-004 9451-181-004 1

8 Spring, Lock Cam 9534-360-002 9534-360-002 1

9 Handle, Door 9244-091-001 9244-091-001 1

10 Pin, Door Handle (groove) 9451-181-005 9451-181-005 1

11 Door Hinge Assembly Mounts to Tub Front 9955-030-001 9955-030-001

* Shim, Loading Door Hinge (Thin) 9552-036-001 9552-036-001 2

*Screw, 5/16-18x3/4 9545-014-009 9545-014-009 3

*Lock Washer, 5/16 8641-582-009 8641-582-009 3

12 Leaf Assembly-Hinge, Top 9845-008-001 9845-008-001 1

13 Leaf Assembly-Hinge, Bottom 9845-005-002 9845-005-002 1

*Screw, 5/16x5/8 9545-056-002 9545-056-002 3

14 Bumper-Loading Door 9051-055-001 9051-055-001 1

* Nut, 1/4, 20UNC, 2B 8640-414-003 8640-414-003 1

18 19

Part # 8533-115-001 3/22 Part # 8533-115-001 3/22

18 19

Parts

Data

Coin

Handling

50Hz

Parts

Accessories

Kits &

Assemblies

Wiring

Harnesses

Cabinet &

Front Panel

Rear

View

Cylinder, Seals,

& Bearings

Door

Lock

Door

Chassis

& Drain

Water Inlet &

Rear Channel

Electrical

Components

Control

Panel

Other manuals for C Series

This manual suits for next models

Table of contents

Other Dexter Laundry Washer manuals

Dexter Laundry

Dexter Laundry T-300 VENDED User manual

Dexter Laundry

Dexter Laundry WCVD-WN Series User manual

Dexter Laundry

Dexter Laundry 400 EXPRESS User manual

Dexter Laundry

Dexter Laundry T-300 VENDED User manual

Dexter Laundry

Dexter Laundry T-1450 Installation manual

Dexter Laundry

Dexter Laundry WCVD-WN Series Quick start guide

Dexter Laundry

Dexter Laundry T-675 EXPRESS PLUS User manual

Dexter Laundry

Dexter Laundry T-300 VENDED Quick start guide

Dexter Laundry

Dexter Laundry T1200 Installation instructions

Dexter Laundry

Dexter Laundry T-900 Quick start guide

Dexter Laundry

Dexter Laundry WN0675 Quick start guide

Dexter Laundry

Dexter Laundry T-350SWD User manual

Dexter Laundry

Dexter Laundry T350 User manual

Dexter Laundry

Dexter Laundry WCAD Series Quick start guide

Dexter Laundry

Dexter Laundry T-450SWD User manual

Dexter Laundry

Dexter Laundry T-300 VENDED Manual

Dexter Laundry

Dexter Laundry Wn0600xa-12en2x-sskcs-usx Quick start guide

Dexter Laundry

Dexter Laundry WC0300XA-10EC4X User manual

Dexter Laundry

Dexter Laundry V-Series User manual

Dexter Laundry

Dexter Laundry T-300 VENDED User manual

Dexter Laundry

Dexter Laundry T-1800 User manual

Dexter Laundry

Dexter Laundry HIGH SPEED 25LB WASHER Installation instructions

Dexter Laundry

Dexter Laundry WCVD Series Administrator guide

Dexter Laundry

Dexter Laundry OPL 30 Cycle 200G Express Quick start guide

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
