DEVI devireg 132 User manual
Table of Contents
1 Introduction ............... 3
1.1 Technical Specifications ..... 4
1.2 Safety Instructions ........ 5
2Mounting Instructions ......... 6
3Settings ................. 10
4 Warranty ................. 12
5 Disposal Instruction .......... 13
1 Introduction
DEVIreg™ 132 is an electronic thermostat to be installed di-
rectly on the wall. It is provided with a room sensor to con-
trol the room temperature and an additional floor sensor to
limit the maximum floor temperature.
The thermostat has a button for adjusting the temperature,
with a scale from ( ) 5-45°C, and an LED indicator showing
standby (green light) and heating periods (red light).
More information on this product can also be found at:
devireg.devi.com
DEVIreg™ 132
Installation Guide 3
1.1 Technical Specifications
Operation voltage 220-240V~, 50Hz
Standby power consump-
tion Max 5W
Relay:
Resistive load Max 16A / 3680W @ 230V
Inductive load cos φ= 0.3 max 1A
Sensing units NTC 15 kOhm at 25°C
Sensing values:
0°C 42 kOhm
25°C 15 kOhm
50°C 6 kOhm
Hysteresis ± 0.2°C
Ambient temperature 0 to +30°C
Frost protection tempera-
ture 5°C -
Temperature range 5-35°C room temperature
20-50°C floor temperature
limiter - default 35°C
Cable specification max 1x4mm2or 2x2,5mm2
Ball pressure temperature 75°C
Pollution degree Degree 2 (domestic use)
DEVIreg™ 132
4 Installation Guide
Type 1C
Storage temperature -20 to +65°C
IP class 30
Protection class Class II -
Dimensions 82 x 82 x 36mm
Weight 90g
The product complies with the EN/IEC Standard "Automatic
electrical controls for household and similar use":
▪EN/IEC 60730-1 (general)
▪EN/IEC 60730-2-9 (thermostat)
1.2 Safety Instructions
Make sure the mains supply to the thermostat is turned off
before installation.
IMPORTANT: When the thermostat is used to control a
floor heating element in connection with a wooden floor or
similar material, always use a floor sensor and never set the
maximum floor temperature to more than 35°C.
DEVIreg™ 132
Installation Guide 5
Please also note the following:
▪The installation of the thermostat must be done by an
authorized and qualified installer according to local
regulations.
▪The thermostat must be connected to a power supply
via an all-pole disconnection switch.
▪The sensor is to be considered as live voltage. Have
this in mind if the sensor must be extended.
▪Always connect the thermostat to continuous power
supply.
▪Do not expose the thermostat to moisture, water, dust,
and excessive heat.
2 Mounting Instructions
Please observe the following placement guidelines:
Place the thermostat at a suitable height on the
wall (typically 80-170 cm.).
In wet rooms, place the thermostat according to
local regulation on IP classes.
DEVIreg™ 132
6 Installation Guide
Do not place the thermostat on the inner side of
an exterior wall.
Always install the thermostat at least 50 cm from
windows and doors.
Do not place the thermostat in a way that it will be
exposed to direct sunlight.
Note: A floor sensor enables a more accurate tem-
perature control and is recommended in all floor
heating applications and mandatory under wood-
en floors to reduce the risk of over-heating the
floor.
▪Place the floor sensor in a conduit in an appropriate
place where it is not exposed to sunlight or draft from
door openings.
▪Equally distant and >2cm from two heating cables.
DEVIreg™ 132
Installation Guide 7
▪The conduit should be flush with the floor surface -
countersink the conduit if necessary.
▪Route the conduit to the connection box.
▪The bending radius of the conduit must be min 50mm.
Follow the steps below to mount the thermostat:
1. Open the thermostat:
▪Remove the button to get access to the screw which
holds the front.
▪Loosen the screw.
▪Push down the release tab at the top of the thermo-
stat using a flat object while slowly pulling off the
front cover.
DEVIreg™ 132
8 Installation Guide
2. Fasten the thermostat directly to the wall by driving
the screws through the holes in each side of the ther-
mostat.
= Screw holes for fastening the thermostat.
3. Connect the thermostat according to the connection
diagram.
IP30
0T30
D132
NTC
LN
1234
Sensor
Max.Load
16 (1) A
Mains
220-240V~
N
LOAD
L
LOAD
The screen of the heating cable must be connected
via a connector together with the earth conductor of
the power supply cable.
Note: Always install the floor sensor in a conduit in the
floor.
DEVIreg™ 132
Installation Guide 9
4. Set the maximum floor temperature between 20˚ and
50˚C by using a thin screwdriver on the black elec-
tronic component with temperature indications in the
upper right corner.
5. Install the front cover and button in the reverse order
of disassembly.
6. Turn on the power supply.
3 Settings
How to change the minimum and maximum floor tem-
peratures
1. Lift off the adjustment
button using a thin
screwdriver. (1)
2. Move the pins to the
desired positions. (2
and 3)
3. Put the adjustment
button back in place.
DEVIreg™ 132
10 Installation Guide
