Denver MT-983NB User manual

PORTABLE DVD

Before connecting, operating or adjusting this product,

please read this user's manual carefully and completely.

www.facebook.com/denverelectronics

USER'S MANUAL

MT-983 NB

Identification of Controls

Main Unit

ENG-1

1. / Up / Prev

/ Down / Next

/ VOL- Left / VOL-

/ VOL+ Right / VOL+

Remarks:

Short press / / / is Up/Down/Left/Right;

Long press / is Prev/Next

Long press / is VOL- / VOL+

2. PLAY/PAUSE;RETURN

Short press PLAY/PAUSE;

Long press RETURN

3.SETUP

4. SOURCE

5. USB

6. Earphone Socket

7. AV OUT

8. ON/OFF

9. DC IN 9-12V

2 3 4 5 6 7 8 9

1 2 34

5678

9 0 10+

VOL -

VOL+

REPEAT

TITLE

ENTER

RETURN

STEP

SUBTITLE

ANG LE AUDIO MENU

SETUP

DISPLAY

ZOOM MUTE SOURCE

113

214

Remote control unit

Identification of Controls

ENG-2

1. ZOOM

2. SEARCH

Goto time point , title or chapter you want in DVD Mode.

3. SUBTITLE

Press SUBTITLE repeatedly during playback to hear a different

subtitle languages.

4. ANGLE

Press ANGLE will change the view angle, on DVDs that support this

feature.

Each press of the ZOOM button changes the TV screen in the following

sequence:2X size 3X size 4X size 1/2 1/3 1/4.

5. TITLE

Return to DVD title menu.

6. ENTER

Confirms menu selection.

7. SETUP

Accesses or removes setup menu.

8. VOL -

Adjust VOLUME.

9. REPEAT

Press REPEAT during playback to select a desired repeat mode.

DVD: you can play a chapter/title/all on a disc.

VCD/CD: you can play a track/all on a disc.

WMA: you can select Repeat one/Repeat folder/ALL

play mode on a disc.

10.A B

To repeat a segment: press AB once to set the starting point for

repeat segment, press it again to set an end point, and the player

will repeat the segment from the start to the end point.

11.PROGRAM

DVD/VCD/CD: The program function enables you to

store your favourite tracks from the disc. Press PROGRAM

button,then PROGRAM MENU will appear on screen, now you

can use the number or direction keys input the titles, chapters or

tracks number and select PLAY option to resume normal

playback, press PROGRAM and select CLEAR option on the

program menu.

JPEG:You can press PROGRAM repeatly to select the slide show

mode, the are 16 types slide show.

12. DISPLAY

To display the playtime and status information.

13. SOURCE

DVD/USB.

Identification of Controls

Remote control unit

ENG-3

14. MUTE

Disable Audio output.

15. 0-9 NUMBER BUTTON

Selects numbered items in a menu.

16.10+ BUTTON

In order to select a track 10 or greater, first press 10+, For example;

select track 12, first press 10+, and then press number 2 button.

17.STEP

Press STEP once to pause playback, Form this station, press STEP

to advance one video frame.

18. MENU

Accesses menu on a DVD disc, PBC on/off switch for VCD.

19. AUDIO

DVD: Press AUDIO repeatedly during playback to hear a different

audio language or audio track, if avilable.

CD VCD: Press AUDIO repeatedly during playback to hear a

different audio channel (Stereo, Left, or Right).

20. PLAY/PAUSE

Press PLAY/PAUSE once to pause playback, pressing PLAY/

PAUSE second time will resume the playback.

21. STOP

When this buttom is pressed once, the unit records the stopped

point,from where playback will resume if ENTER is pressed after

wards. But if STOP button is pressd again instead of ENTER

button, there will be no resume function.

22. RETURN

Return to upper page.

23. VOL +

Adjust VOLUME.

24. Reverse Skip

Go to previous chapter/ track to the beginning.

25. Forward Skip

Go to next chapter/ track.

26. BUTTON

Press BUTTON allow skipping ahead at 5-level speed(X2->

X4->X8->X20), press ENTER button return to normal playback.

27. BUTTON

Press BUTTON allow skipping back at 5-level speed(X2->

X4->X8->X20), press ENTER button return to normal playback.

Parameters and specifications

Item Standard requirement

Electronical parameters

Power requirements : AC 100-240 V , 50/60 Hz

Output

VIDEO OUT

AUDIO OUT :1.2 Vrms (1 KHz, 0 dB)

Power consumption

Operating humidity

: <10W

: 5 % to 90 %

System

Laser :Semiconductor laser, wavelength 650 nm

Signal system : NTSC / PAL

Frequency

response

Signal-to-noise ratio :More than 80 dB (ANALOG OUT connectors only)

Dynamic range :More than 85 dB (DVD/CD)

Note: Design and specifications are subject to change prior notice.

: 20Hz to 20 kHz(1dB)

Battery Parameters

Battery Specifications：

Output：7.4V

Charge / Discharge Time：

Standard charge time：3h ~ 4h

Storage and work circumstances：

1. Storage circumstances Temperature Humidity

2.Work circumstances Temperature Humidity

6 months -20 C +45 C~

-20 C +65 C~

65+20%

Standard charge

Standard discharge

0 C +45 C~

-20 C +65 C~

65+20%

1 week

ENG-4

Electric and electronic equipment and included batteries contains materials,

environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen below. This symbol signifies that electric and

electronic equipment and batteries should not be disposed of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the approriate and designated facility. In this manner you make sure that the batteries

are recycled in accordance with legislature and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and batteries can either be submitted free of charge at recycling

stations and other collection sites, or be collected from the households. Additional information is available at the technical department of your city.

Please fill the blank with the model number of this player for future reference

Importer:

DENVER ELECTRONICS A/S

Stavneagervej 22

DK-8250 EGAA

DENMARK

www.facebook.com/denverelectronics

components and substances that can be hazardous to your health and the
