DELTA DORE PACK TYBOX 5000 User manual

Installation instructions

Installationsanleitung

Installatie-instructies

TYBOX 5000

Hard-wired room thermostat for boiler

Drahtgebundenes Raumthermostat

Kamerthermostaat met draad

CONTENT

1/ Location 4

2/ Connection 5

2.1 Circulator control 5

2.2 Control of the thermostat input of

the boiler or heat pump (HP) no-reversible 6

3/ Mounting 8

4/ Conguration 9

5/ Compatible options 14

6/ Troubleshooting 15

• Contact output 2A (230V) - 1.C (brownout)

• Ball test: 125 ° C

• Rated surge voltage: 4000V

• Powered by 2 lithium batteries 1.5V, LR03/AAA

(supplied), 5-year life under normal use

• Class II insulation

• Radio frequency 868.7 MHz to 869.2 MHz

• Maximum wireless power: <10 mW

• Receiver category: 2

• Wireless remote control device

• Wireless range: 100 to 300 metres outside,

variable depending on the associated equipment

(the range can vary depending on the installation

conditions and the electromagnetic environment)

• Dimensions: 80 x 84 x 21 mm

• Degree of protection: IP 20

• Wall mounting

• Installation in an environment

with normal pollution levels

• Storage temperature:

-10 to +70°C

• Operating temperature:

0 to +55°C

TECHNICAL CHARACTERISTICS

Boiler Plus

Compliant

2A max. / 230V~

Circulator

Since the temperature measurement sensor is

inside the box, you must install the thermostat

 ush-mounting box:

- on an accessible wall at a height of 1.50 m

- away from heat sources ( replaces, sunlight) and

draughts (windows, doors)

IMPORTANT: Do not install the thermostat on

a wall in contact with the outdoors or with an

unheated room (e.g. garage, etc.) The sleeve output

in the  ush-mounting box must be blanked off (with

mastic) in order to avoid unwanted air movements

that could bias the sensor reading.

1/ LOCATION 2/ CONNECTION

The diagrams provided are simpli ed for greater

clarity. Protections and other accessories required

by standards are not illustrated. - Standard NF

C15-100 and good practice must be complied

with. Connected or nearby units must not

generate excessive interference

(directive 89/336/EEC).

2.1 Circulator control

Thermostat

input

Thermostat

input

2A max. / 230V~ 2A max. / 230V~

2A max. / 230V~

2/ CONNECTION

Boiler

2.2 Control of the thermostat input of the boiler

or heat pump (HP) no-reversible

❶ Remove the terminal, on

the back of the device, using a

screwdriver.

❷Connecttheterminaltothe

control wire (circulator, boiler

or heat pump thermostat

input).

❸ Fit the terminal back into its

position.

4/ CONFIGURATION

This menu is used to determine all the settings

adapted to your installation.

❶To enter conguration mode, press the MODE

button for 10 seconds until the screen displays

CF01.

❷Press +or -to set.

❸Briey press MODE to go to the next menu.

Press MODE or wait 5 seconds to exit.

CF01 - Correcting the temperature measured

Setting from -5°C to +5°C

Example: If the temperature displayed by the unit is

15°C and the actual temperature (thermometer) is

16°C, set +1°C.

❶Remove the thermostat cover by pushing the pin

using a screwdriver.

❷ Attach the base by using suitable xings for

mounting. Fit the cover back onto the thermostat.

❸ Insert the batteries, with the right polarity

3/ MOUNTING

2 x 1,5V - AAA LR03

Click

1110

0No locking (default setting)

1Total locking

2Partial locking. Modication of the

temperature setting at +/-2°C

The screen will display '____' if it is locked

To unlock (selection 1 and 2), simultaneously press

+ or - the buttons for 10 seconds.

CF04 - Frost protection mode temperature setting

Setting of 5°C to 15°C. Default value: 10°C.

4/ CONFIGURATION

CF06 - Regulation time base

15 15 minutes (default settings)

30 30 minutes

45 45 minutes

60 60 minutes

On/Off On/Off

CF05 - Type of temperature displayed in AUTO

mode

0Temperature setting permanent display

(default selection)

1Permanent display of the measured room

temperature.

1: Pressing the + or - button once displays and sets

the temperature setting (in ON mode).

CF02 - Settings lock

1312

4/ CONFIGURATION

CF07 - Modication of the on/off regulation

hysteresis

Only displayed if menu CF06 = on/off

Setting of 0.2°C to 2°C. Default value: 0.4°C

CF08 - Anti-seize function

The Anti-seize function activates the circulator 1

minute per day to prevent any seizing up during a

non-heating period.

0 Anti-seize disabled

1 Anti-seize enabled (default settings)

CF09 - Reversal of relay direction

The relay contact is normally open. It closes during

a heating request. You can reverse the direction of

operation.

0 Normally open (default selection)

1 Normally closed

CF10 - Return to initial settings

This menu resets all the CF01 to CF09 settings to

their default value.

By default CF10 = 0.

To reset, press + to display 1 and conrm by

pressing MODE.

1514

When you press a button, the screen displays: _ _ _ _

Access to the settings is locked.

To unlock, press and hold the + and - buttons for 10

seconds.

Important: if you want to lock the device again,

refer to the con guration menu (CF02).

The screen displays the low battery symbol. Replace

the batteries The batteries are spent.

mode

>10s

5/ COMPATIBLE OPTIONS 6/ TROUBLESHOOTING

Association with a TYDOM home automation box

Your TYBOX 5000 can be used as a connected

thermostat, if it is associated with a TYDOM home

automation thermostat. Remote control and programming

from a tables or smartphone with the TYDOM application.

Association with a door/window magnetic contact

(DO / MDO / DOI TYXAL+)

If a door/window magnetic contact (e.g. window) is

associated with the TYBOX 5000, the heating switches to

Frost Protection mode when an open window is detected.

❶Press the +and MODE buttons simultaneously

until the screen shows for example rF00.

❷ On the door/window magnetic contact, press the

button.

❸ Check that the screen evolved and shows rF01 on

TYBOX 5000.

mode

> 3s

1 2 3

mode / +mode / +

2 x 1,5V - AAA LR03

www.deltadore.com

DELTA DORE - 08/18
