Defiant K40425002 User manual
USE AND CARE GUIDE
Questions, problems, missing parts?
Before returning to the store,
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-866-308-3976
HOMEDEPOT.COM
MOTION-ACTIVATED FLOOD LIGHT
THANK YOU
your home. Visit us online to see our full line of products available for your home improvement needs.
Item #1009 525 257
Model #K40425002
Table of Contents
Table of Contents
Safety Information
Warranty
3-Year Limited Warranty
Pre-Installation
Planning Installation
Initial Battery Charge
2
2
2
2
3
3
3
3
ToolsRequired
Hardware Included
Package Contents
Installation
Operation
Care and Cleaning
Troubleshooting
FCC Statement
4
4
5
6
7
7
8
9
Safety Information
Warranty
Please read and understand this entire manual before attempting to assemble, install,
Do not immerse components in liquid.
Do not use any other charging device other than thesinglesolar charging panel
provided with this light. Doing so may result in injury or damage to the light and
voids any warranty.
2
PRECAUTIONS
3-YEAR LIMITED WARRANTY
WHAT IS COVERED
This product is guaranteed to be free of factory defective parts and workmanship for a
period of 3 years from date of purchase. Purchase receipt is required for all warranty
claims.
WHAT IS NOT COVERED
This guarantee does not include repair service, adjustment and calibration due to
the use of chemicals or a pressure washer machine are not covered by this warranty.
void this warranty in its entirety.
NOTE: To extend the life of the batteries, this light only works in the dark (night time).
Warranty (continued)
This warranty does not include reimbursement for inconvenience, installation, setup
time, loss of use, unauthorized service, or return shipping charges. This warranty is not
extended to other equipment and components that a customer uses in conjunction with
this product. The manufacturer reserves the right to discontinue products and to change
in products previously sold.
the Hardware Included and Package Contents sections. If any part is missing or
Pre-Installation
PLANNING INSTALLATION
INITIAL BATTERY CHARGE
SPECIFICATIONS
3
HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
IMPORTANT: The solar panel requires full, direct sunlight to charge the battery. Clouds,
rain, snow, and other weather conditions may not allow the solar panel to completely recharge
the battery. Other obstructions such as buildings or trees may block the sun as well.
Range Up to 30 ft. (9 m) (Varies with surrounding temperature)
Up to 120°
Solar Power: 320 LM
4000K (bright white)
Off, Dusk to dawn (Two modes)
20 seconds
1200 mAh, 3.7 V Li-Ion Rechargeable Battery
(non-replaceable)
Sensing angle
Lumens
LED color temperature
Power requirements
Operating modes
Time delay
Estimated installation time: 30 minutes
No service parts available for this product.
Contact the Customer Service Team at 1-866-308-3976 or visit www.homedepot.com.
Pre-Installation (continued)
TOOLS REQUIRED
HARDWARE INCLUDED
4
Phillips
screwdriver
Drill bits (3/32 in.
and 7/32 in.)
Drill
Ladder
LevelSafety goggles
NOTE: Hardware shown to actual size.
AA
AA Mounting screw 2
BB Wall anchor 2
Part Description Quantity
BB
5
HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
Pre-Installation (continued)
E
D
C
A
B
1A
B Solar panel
C Button
D Motion sensor
E Lamp head 1
1
1
1
Part Description Quantity
PACKAGE CONTENTS
6
2Mounting the light fixture
Place the (A) against the mounting surface
and mark the mounting holes.
Rotate the lamp head (E) to the desired angle.
If mounting to a wooden surface, drill two 3/32 in.
holes into the mounting surface. Install the two
mounting screws (AA) through the base of the light
If mounting to wallboard or brick, drill two 7/32 in.
holes into the mounting surface. Insert the wall
two mounting screws (AA).
A
E
BB
AA
IMPORTANT: The solar panel must receive as much direct sunlight over the course of
the day as possible. Keep in mind that shadows may block the sunlight from reaching the
solar panel during the day.
Installation
1Determining the mounting
location
Wall Mount
NOTE:
mounted approximately 8 ft. (2.4 m)
above the ground.
Mounting location must be on the wall.
Position the lamp head (E) in the general
direction of the desired light coverage.
Eave Mount
E
7
HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
will not be covered by the warranty.
Periodically clean the solar panel with a soft cloth and warm water. Do not spray
with a hose. Keep the panel clear of snow and leaves. Make sure trees and other
objects do not block sunlight from the panel.
Care and Cleaning
soft, damp cloth only.
Operation
1Adjusting the light modes
Press the power button (C) once, and the light
detected during daylight. When motion is detected,
light turns to full brightness. After 20 seconds of no
motion, light turns off.
Press the power button
If no motion are detected, the light is on low brightness constantly. When motion is
detected, light turns to full brightness. After 20 seconds of no motion, light turns to
low brightness.
Press the power button (C) a third time to turn the light off.
C
IMPORTANT: The light will work from dusk
to dawn. The mode can be changed by pressing
the button.
HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
8
Troubleshooting
installed in a relatively dark
location.
The motion sensor may be
sensing small animals or
The motion sensor may
sense the shadows. from shadows.
that receives more light.
The light will not
come on.
The light comes on
during the day.
The light comes on
for no apparent
reason.
on and off.
Problem Possible Cause Solution
The rechargeable battery is
dead.
The solar panel is positioned
wrong.
The motion sensor is aimed in
the wrong direction.
The surrounding air tempera-
ture is greater than 104° F
(40° C) or less than -4° F
(-20° C).
battery to charge with 1 day of full
sunshine before testing.
Position and angle the solar panel so that
it gets plenty of direct sunlight for most
of the day.
desired area.
The light must be operated within the
(104° F to -4° F / 40° C to -20° C) .
HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
9
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Plug the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Questions, problems, missing parts?
Before returning to the store,
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
MOTION-ACTIVATED FLOOD LIGHT
Model #K40425002
FCC RESPONSIBLE PARTY
THE HOME DEPOT
2455 PACES FERRY ROAD
ATLANTA, GA 30339
1-866-308-3976
HOMEDEPOT.COM
Retain this manual for future use.
