Data Video DAC-9P User manual

HDMI to HD/SD-SDI Converter

DAC-9P

Quick Start Guide

www.datavideo-tek.com

Table of Contents

Warnings and Precautions ...............................................................2

What's in the Box .............................................................................4

Introduction......................................................................................4

Features.......................................................................................... 5

Function...........................................................................................6

Front Panel ......................................................................................6

Rear Panel.......................................................................................7

Specification.....................................................................................8

Service & Support ............................................................................9

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use

liquid or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit

may fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are

provided for ventilation. To ensure safe and reliable operation of

this unit, and to protect it from overheating, do not block or cover

these openings. Do not place this unit on a bed, sofa, rug, or

similar surface, as the ventilation openings on the bottom of the

cabinet will be blocked. This unit should never be placed near or

over a heat register or radiator. This unit should not be placed in a

built-in installation unless proper ventilation is provided.

7. This product should only be operated from the type of power

source indicated on the marking label of the AC adapter. If you

are not sure of the type of power available, consult your

Datavideo dealer or your local power company.

8. Do not allow anything to rest on the power cord. Do not locate this

unit where the power cord will be walked on, rolled over, or

otherwise stressed.

9. If an extension cord must be used with this unit, make sure that

the total of the ampere ratings on the products plugged into the

extension cord do not exceed the extension cord’s rating.

10. Make sure that the total amperes of all the units that are plugged

into a single wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet

ventilation slots, as they may touch dangerous voltage points or

short out parts that could result in risk of fire or electric shock.

Never spill liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not

attempt to service this product yourself. Opening or removing

covers that are marked “Do Not Remove” may expose you to

dangerous voltage points or other risks, and will void your

warranty. Refer all service issues to qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified

service personnel under the following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under normal

operating conditions. Adjust only those controls that are

covered by the operating instructions in this manual;

improper adjustment of other controls may result in damage

to the unit and may often require extensive work by a

qualified technician to restore the unit to normal operation;

e. When the product has been dropped or the cabinet has been

damaged;

f. When the product exhibits a distinct change in performance,

indicating a need for service.

14. Due to the general consumer usage behavior, efficient power

distribution on the field, corporate environment responsibility by

eliminating harmful substances such as carbon dioxide, sulphur

dioxide, etc, and other unexpected risks, this product does not

provide standby power option.

What’s in the box?

Items Description Q’ty

DAC-9P

Switching Adaptor DC 12V 500mA

Instruction Manual

Introduction

Many new High Definition camcorders and devices provide HDMI as the

only High Definition output option. Datavideo’s DAC-9P allows users to

connect HDMI devices to professional SDI equipment, like video

switchers or recorders up to 200 meters away.

HDMI is not suitable for long cable runs, but using a Datavideo DAC-9P,

users can convert HDMI to High Definition & Standard Definition SDI and

take advantage of the high quality and affordable connectivity that SDI

cables offer.

The DAC-9P even embeds the audio from HDMI into the SDI signal so

only one SDI cable is needed.

Features

Input

1 X HDMI

Output

2 X SDI (HD / SD SDI)

Enables long cable runs

Rugged case design

Audio can be embedded within SDI output signal

PAL / NTSC Compatible

Tripod Mount via Velcro straps (Supplied)

DC 12V Operation

• 480i/576i

• 720_50p/720_59.94p/720_60p

• 1080_50i/1080_59.94i/1080_60i

• 1080_24p/1080_25p/1080_30p

• 1080_23.98p/1080_24p/1080_25p/1080_29.97p/1080_30p

Functions

Front Panel

HD/SD - SDI Output

SDI transfers professional level video signals and

it’s

can connect to long distance transmission

systems.

Rear Panel

DC In Socket

Connect the supplied 12V 500mA PSU to this

socket. The connection can be secured by

screwing the outer fastening ring of the DC In plug

to the socket.

Power Switch

Switches the power On / Off.

HDMI In interface

HDMI digital signal input connecter

Specification

Input Interface • 1x HDMI input

Outputs Interface

• 2x 3G/HD/SD-SDI output

Video Support Format

(HDMI Input)

• 720x480 Interlace

• 720x576 Interlace

• 1280x720 / 50Hz Progressive

• 1280x720 / 59.94Hz Progressive

• 1280x720 / 60Hz Progressive

• 1920x1080 / 50Hz Interlace

• 1920x1080 / 59.94Hz Interlace

• 1920x1080 / 60Hz Interlace

• 1920x1080 / 50Hz Progressive

• 1920x1080 / 59.94Hz Progressive

• 1920x1080 / 60Hz Progressive

3G SDI

Signal

SMPTE 292 standard complied with

• Output return loss : More than 4.5 dB (3GHz)

• Output level : 0.8 Vpp ± 10%

• Rise time : Less than 130 ps

• Fall time : Less than 130 ps

• Difference between rise time and fall time within 50 ps

• Alignment jitter : Less than 0.3 UI

• Timing jitter : Less than 2.0 UI

• Rise over shot：10%

• Fall over shot：10%

• Equalizer use 5C-FB cable support 100 meters

SD SDI signal

SMPTE 292M standard complied with

• Output return loss : More than 15 dB (5MHz to 750MHz)

More than 10 dB (750MHz to 1.5 GHz)

• Output level : 0.8 Vpp ± 10%

• Transition time : 0.4 ~ 1.5ns

• Difference between rise time and fall time within 100 ps

• Alignment jitter : Less than 0.2 UI

• Timing jitter : Less than 0.2 UI

• Eye aperture ratio : More than 90%

• DC offset : 0 ± 0.5V

• Equalizer use 5C-FB cable support 200 meters

Operating Temperature

• 0°C to 40°C (32°F to 102°F)

Humidity

• 10% to 90% (non condensing)

Dimension & Weight

• 145mm (W) x 85mm (D) x 30mm (H) / lbs/ 0.33Kgs

Power

• DC 12V / 500mA (5W)
