Daewoo RC-350 User manual
CONTENTS
•Description and operation ...2,3
•Cleaning the filter and
•Changing the dustbag .............4
•Precautions for safe use...........5
•Specifications..........................6
•Before asking for service.........6
VACUUM CLEANER
RC-350
READ AND KEEP THIS
¡ÆThank you for purchasing this vacuum cleaner.
¡ÆFor proper operation, please read this manual before use.
OWNER’S MANUAL
M
I
N
M
A
X
RC-350(¿ -DESUK) 99.9.23 8:11 PM ˘`1
2
DESCRIPTION AND OPERATION
• The suction power control at
the hand grib enables you to
control suction power.
SUCTION POWER CONTROL
• To Connect the nozzle, hold
the tubes and the
handle:insert the narrowed
section into the wide section.
PIPE CONNECTION
• Use this nozzle for cleaning
both carpeted and
uncarpeted floors.
WIDE SUCTION NOZZLE
UPHOLSTERY NOZZLE
CREVICE NOZZLE DUS
HOSE CONNECTION
M
I
N
M
A
X
M
I
N
M
A
X
• Connecting the hose :
insert the hose firmly into
the hose inlet. (“Click”)
• Disconnecting the hose:
press the button and pull the
hose out of the vacuum
cleaner.
• This part can be separated
from the tube when taking a
nozzle out of it.
RC-350(¿ -DESUK) 99.9.23 8:11 PM ˘`2
M
I
N
M
A
X
3
• If you want to stop vacuum
cleaning for a while, you can
place the brush clip into the
rest.
PRACTICAL PARKING
• If you want to store the
cleaner, hitch the brush clip
onto the vacuum cleaner.
STORAGE
• When the color of the dust
meter is changed to RED for
long time, change the dust
bag.
DUST METER
•
Rewind the power cord by
pressing the cord rewind button.
CORD REWIND BUTTON
M
I
N
M
A
X
• Press the on/off switch.
ON/OFF SWITCH
M
I
N
M
A
X
DUSTING BRUSH
rest
• Power control
KNOB
M
I
N
M
A
X
brush clip
DUST METER
RC-350(¿ -DESUK) 99.9.23 8:11 PM ˘`3
4
• If you cannot purchase the RC-300/RC-350 dust bag, Please note you may use the dust bag
for the Philips Model No HR6938 OSH.
CHANGING THE DUSTBAG
CLEANING THE FILTER
N
I
M
X
A
M
N
I
M
X
A
M
• Switch off and open the
cover.
• Switch off and lift the
handle. • Pull the filter case
upwards from the cleaner.
• Hold the cover while taking
the filter out of the cleaner. • Shake the dust out of the
filter.
• Separate the filter from the
filter case and shake the
dust out of the filter.
N
I
M
X
A
M
N
I
M
X
A
M
• Hold the cover while
separating the dustbag
from the dustbag holder.
• Insert the new dustbag in the
dust bag holder properly as
shown in picture.
Note: If no dustbag has been placed
into the dustbag holder, the cover
cannot be closed.
• Switch off and open the
cover.
EXHAUST FILTER
MOTOR PROTECTION FILTER
RC-350(¿ -DESUK) 99.9.23 8:11 PM ˘`4
5
PRECAUTIONS FOR SAFE USE
This vacuum cleaner should only be used for normal dry household dust and dirt.
The manufacturer cannot be responsible for any damage caused by use or operation of the cleaner
contrary to these instructions.
If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can
be accepted for any possible damage.
• Do not vacuum areas which contain
moisture or water and inflammable matter,
needles, pins, razor blades, matches,
cigarette-ends, etc., since they may
damage the cleaner or dust bag or make
a fire.
• Make sure a dust bag and a motor
protection filter are always inserted.
• When rewinding the power cord, hold the
plug body before pressing the cord rewind
button to prevent whipping.
• Do not pull the power cord out beyond the
specified length.
• This product provided with a cable which,
if damaged, must be replaced by a repair
shop authorized by the manufacturer since
special tools are required.
M
I
N
M
A
X
M
I
N
M
A
X
M
I
N
M
A
X
RC-350(¿ -DESUK) 99.9.23 8:11 PM ˘`5
6
BEFORE ASKING FOR SERVICE
■ Before Asking for Service, please check each item below if you have trouble with your cleaner.
• Specifications can be changed for improvement without notice.
Problem Check Point Measure
If dust bag is dirty, replace it.
If clogged or blocked, remove the object.
Check if power cord is plugged.
Check if the power switch is turned on.
Pull the power cord out a little and press the cord
rewind button.
Suction power is weak.
The cleaner does not work.
Power cord does not
rewind.
• Dust bag
• Pipe or hose
• Power cord
•
ON/OFF
switch
• Power cord
SPECIFICATIONS
Model
Rating
Watts
Weights(Net)
Dimension (L X H X D)
Cord Length
RC-350
230V/50Hz
MAX. 1300W(CEE 1100W)
5.1kg
354 X 240 X 262mm
6m
RC-350(¿ -DESUK) 99.9.23 8:11 PM ˘`6
