Daewoo RC-300 User manual

CONTENTS

•Description and operation .....2,3

•Cleaning the filter and

•Changing the dustbag ...............4

•Precautions for safe use.............5

•Specifications............................6

•Before asking for service...........6

,,,,,,,







VACUUM CLEANER

RC-300

READ AND KEEP THIS

¡ÆThank you for purchasing this vacuum cleaner.

¡ÆFor proper operation, please read this manual before use.

OWNER’S MANUAL

RC-300(¿ -DESUK) 99.9.23 8:28 PM ˘`1

DESCRIPTION AND OPERATION

• The suction power control at

the hand grib enables you to

control suction power.

SUCTION POWER CONTROL

• To Connect the nozzle, hold

the tubes and the

handle:insert the narrowed

section into the wide section.

PIPE CONNECTION

• Use this nozzle for cleaning

both carpeted and

uncarpeted floors.

WIDE SUCTION NOZZLE

UPHOLSTERY NOZZLE

CREVICE NOZZLE DUS

HOSE CONNECTION

• Connecting the hose :

insert the hose firmly into

the hose inlet. (“Click”)

• Disconnecting the hose:

press the button and pull

hose out of the vacuum

cleaner.

• This part can be separated

from the tube when taking a

nozzle out of it.

RC-300(¿ -DESUK) 99.9.23 8:29 PM ˘`2

• If you want to stop vacuum

cleaning for a while, you can

place the brush clip into the

rest.

PRACTICAL PARKING

• If you want to store the

cleaner, hitch the brush clip

onto the vacuum cleaner.

STORAGE

• When the color of the dust

meter is changed to RED for

long time, change the dust

bag.

DUST METER

•

Rewind the power cord by

pressing the cord rewind button.

CORD REWIND BUTTON

• Press the on/off switch.

ON/OFF SWITCH

DUSTING BRUSH

hose:

and pull the

cuum

rest

brush clip

DUST METER

RC-300(¿ -DESUK) 99.9.23 8:29 PM ˘`3

• If you cannot purchase the RC-300/RC-350 dust bag, Please note you may use the dust bag

for the Philips Model No HR6938 OSH.

CHANGING THE DUSTBAG

CLEANING THE FILTER

• Switch off and open the

cover.

• Switch off and lift the

handle. • Pull the filter case

upwards from the cleaner.

• Hold the cover while taking

the filter out of the cleaner. • Shake the dust out of the

filter.

• Separate the filter from the

filter case and shake the

dust out of the filter.

• Hold the cover while

separating the dustbag

from the dustbag holder.

• Insert the new dustbag in the

dust bag holder properly as

shown in picture.

Note: If no dustbag has been placed

into the dustbag holder, the cover

cannot be closed.

• Switch off and open the

cover.

EXHAUST FILTER

MOTOR PROTECTION FILTER

RC-300(¿ -DESUK) 99.9.23 8:29 PM ˘`4

PRECAUTIONS FOR SAFE USE

This vacuum cleaner should only be used for normal dry household dust and dirt.

The manufacturer cannot be responsible for any damage caused by use or operation of the cleaner

contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can

be accepted for any possible damage.

• Do not vacuum areas which contain

moisture or water and inflammable matter,

needles, pins, razor blades, matches,

cigarette-ends, etc., since they may

damage the cleaner or dust bag or make

a fire.

• Make sure a dust bag and a motor

protection filter are always inserted.

• When rewinding the power cord, hold the

plug body before pressing the cord rewind

button to prevent whipping.

• Do not pull the power cord out beyond the

specified length.

• This product provided with a cable which,

if damaged, must be replaced by a repair

shop authorized by the manufacturer since

special tools are required.

RC-300(¿ -DESUK) 99.9.23 8:29 PM ˘`5

BEFORE ASKING FOR SERVICE

■ Before Asking for Service, please check each item below if you have trouble with your cleaner.

• Specifications can be changed for improvement without notice.

Problem Check Point Measure

If dust bag is dirty, replace it.

If clogged or blocked, remove the object.

Check if power cord is plugged.

Check if the power switch is turned on.

Pull the power cord out a little and press the cord

rewind button.

Switch off and unplug the cleaner and check the

dust bag, accessories and blockages, then allow

the motor to cool down. The cleaner can be

switched on again after about 30 minutes.

Suction power is weak.

The cleaner does not work.

Power cord does not

rewind.

When the dust bag is full or

blocked or any of the

accessories is blocked, the

over-heating protection for

the motor is activated.

• Dust bag

• Pipe or hose

• Power cord

•

ON/OFF

switch

• Power cord

SPECIFICATIONS

Model

Rating

Watts

Weights(Net)

Dimension (L X H X D)

Cord Length

RC-300

230V/50Hz

1100W MAX.1200W

5.0kg

354 X 240 X 262mm

RC-300(¿ -DESUK) 99.9.23 8:29 PM ˘`6
