Daewoo RC-1O5 User manual
VACUUM CLEANER
RC-1O5
READ AND KEEP THIS
■Thank you for purchasing this vacuum cleaner.
■For proper operation, please read this manual carefully before using.
OWNER'S
MANUAL
2
CONTENTS
Description.....................................................................................3
Precautions for safe use................................................................4
How to use.....................................................................................5
Before asking for service...............................................................9
3
Description
Handle
Crevice nozzle
Power control
Dust Meter
Power cord
Wide suction nozzle
Pipe holder
Pipe
Hose
Cord rewind
Button
ON
OFF
4
Precautions for Safe Use
• Plug the power cord into a 120V AC 60Hz
receptalcle outlet. When pluging or
unpluging, hold the plug body, not flex.
• Do not vacuum without a dust bag.
If no dust bag, the dust cover would not be
closed completely.
• Do not step on the hose or pull it fecibly.
The hose may be flattened or torn.
• Do not vacuum dust which contains
moisture/water.
• Do not vacuum inflammable materials,
needles, pins, razor blades, etc.
• Keep the unit away from heat sources such
as a heater.
• This product is provided with a cable which,
if damaged, must be replaced by a repair
shop authorized by the manufacturer since
special tools are repuired.
• When rewinding the power cord, hold the
plug body before pressing the cord rewind
button. The cord moves quickly and might
hit you or other objects.
54
How to Use
1. How to operate
• Put together as shown on page 3. Description.
• Plug the power cord into a 120V AC 60Hz ; receptacle outlet.
• Set the remote control switch “ON”.
• O the vacuum cleaner will be vacuuming at this time.
• If you continue to push the remote control switch, the air hole opens and the suction power
decreases.
• O adjust the switch as needed for different cleaning jobs.
2. How to change the dust bag.
OFF
ON
OPEN
CLOSE
Remote control switch
Air Hole
(How to operate the remote control switch)
Bag Holder
• Open the cover. • Push the bag holder to the arrow mark, and
then take the dust bag out.
6
5. How to use the crevice nozzle
6. How to clean the filter.
• Cleaning window frames or narrow spaces between furnitures, walls, and floor.
• Cleaning curtains, sofa or semething like that.
• Open the cover.
• Please pull out the
plug before
cleaning.
• Pull the filter out
from the unit while
lifting the gasket.
• After washing the
filter with water, dry
it completely.
• Insert it again
originally.
77
7. How to store the vacuum cleaner
• Put the pipe holder on the groove of the cleaner dody.
• Wind the hose around the hose handle as shown below.
Pipehdder
Groove
Before Asking for Service
■Before Asking for Service, please check each item below if you have trouble with your cleaner.
8
Problem Check Point Measure
Suction power is weak.
The cleaner does not work.
Power cord does not rewind.
When the dust bag is full or
blocked or any of the
accessories is blocked, the
over-heating protection for the
motor is activated.
• Dust bag
• Pipe or hose
• Power cord
• Suction hose
• Power cord
If dust bag is dirty, clean it.
If clogged or blocked, remove the object.
Check if power cord is plugged.
Check if hose is attached fimly into suction hole.
Pull the power cord out a little and press the
cord rewind button.
Switch off and unplug the cleaner and check
the dust bag, accessories and blockages,
then allow the motor to cool down. The
cleaner can be switched on again about 30
minutes.
