D-Link DIR-615S User manual

Quick Installation Guide

DIR-615S

Wireless N300 Router

DIR-615S Quick Installation Guide

BEFORE YOU BEGIN

Delivery Package

•Router DIR-615S

•Power adapter DC 12V/0.5A

•Ethernet cab e

•“Quick Installation Guide” (brochure).

If any of the items are missing, p ease contact your rese er.

The “User Manual” and “Quick Installation Guide” documents are avai ab e

on D-Link website (see www.d ink.ru).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

DIR-615S Quick Installation Guide

Default Settings

Do ain na e of device dlinkrouter.local.

IP address of device 192.168.0.1

Userna e (login) admin

Password admin

Na e of wireless network (SSID) DIR-615S

Network key (PSK password)

see WPS PIN on the barcode

abe on the bottom pane of

the device

Router DIR-615S with defau t settings cannot connect to the Internet.

To get started, p ease set your own password for access to the web-

based interface and change the WLAN name (SSID); then, if needed,

configure other settings recommended by your ISP.

DIR-615S Quick Installation Guide

System Requirements and Equipment

•An Android or iPhone mobi e device (smartphone or tab et) or a computer

with any operating system that supports a web browser.

•A web browser to access the web-based interface of the router:

◦App e Safari 8 and ater

◦Goog e Chrome 48 and ater

◦Microsoft Internet Exp orer 10 and ater

◦Microsoft Edge 20.10240 and ater

◦Mozi a Firefox 44 and ater

◦Opera 35 and ater.

•A NIC (Ethernet or Wi-Fi adapter) to connect to the router.

•An 802.11b, g, or n Wi-Fi adapter to create a wire ess network.

DIR-615S Quick Installation Guide

CONNECTING TO PC

PC with Ethernet Adapter

1. Connect an Ethernet cab e between any of LAN ports ocated on the back

pane of the router and the Ethernet port of your PC.

2. Connect the power cord to the power connector port on the back pane of

the router, then p ug the power adapter into an e ectrica out et or power

strip.

3. Turn on the router by pressing the POWER button on its back pane .

Then make sure that your PC is configured to obtain an IP address

automatica y (as DHCP c ient).

DIR-615S Quick Installation Guide

Obtaining P Address Automatically

(OS Windows 7)

1. C ick the Start button and proceed to the Control Panel window.

2. Se ect the Network and Sharing Center section. (If the Contro Pane

has the category view (the Category va ue is se ected from the View by

drop-down ist in the top right corner of the window), choose the View

network status and tasks ine under the Network and Internet

section.)

3. In the menu ocated on the eft part of the window, se ect the Change

adapter settings ine.

4. In the opened window, right-c ick the re evant Local Area Connection

icon and se ect the Properties ine in the menu disp ayed.

5. In the Local Area Connection Properties window, on the

Networking tab, se ect the Internet Protocol Version 4 (TCP/IPv4)

ine. C ick the Properties button.

DIR-615S Quick Installation Guide

6. Make sure that the Obtain an IP address auto atically and Obtain

DNS server address auto atically choices of the radio buttons are

se ected. C ick the OK button.

7. C ick the OK button in the connection properties window.

DIR-615S Quick Installation Guide

Obtaining P Address Automatically

(OS Windows 10)

1. C ick the Start button and proceed to the Settings window.

2. Se ect the Network & Internet section.

3. In the Change your network settings section, se ect the Change

adapter options ine.

4. In the opened window, right-c ick the re evant Local Area Connection

icon and se ect the Properties ine in the menu disp ayed.

5. In the Local Area Connection Properties window, on the

Networking tab, se ect the Internet Protocol Version 4 (TCP/IPv4)

ine. C ick the Properties button.

DIR-615S Quick Installation Guide

6. Make sure that the Obtain an IP address auto atically and Obtain

DNS server address auto atically choices of the radio buttons are

se ected. C ick the OK button.

7. C ick the Close button in the connection properties window.

DIR-615S Quick Installation Guide

PC with Wi-Fi Adapter

1. Connect the power cord to the power connector port on the back pane of

the router, then p ug the power adapter into an e ectrica out et or power

strip.

2. Turn on the router by pressing the POWER button on its back pane .

3. Make sure that the Wi-Fi adapter of your PC is on. As a ru e, modern

notebooks with bui t-in wire ess NICs are equipped with a button or

switch that turns on/off the wire ess adapter (refer to your PC documents).

If your PC is equipped with a p uggab e wire ess NIC, insta the software

provided with your Wi-Fi adapter.

Then make sure that your Wi-Fi adapter is configured to obtain an IP address

automatica y (as DHCP c ient).
