550AT & 1100AT operation and maintenance instructions
SETTING OF MACHINE
(Refer to ozone application/usage instructions for more detailed instructions.)
1a. The 550AT features an on / off switch to power the unit, a one shot timer, a continuously
adjustable output level control to adjust the amount of ozone being produced. Ozone production
begins when the power switch or timer is turned on. (Refer to timer instructions below)
1b. The 1100AT controls feature a Low/Off/Hi switch to power the unit, a one shot timer, a
continuously adjustable output level control to adjust the amount of ozone being produced. Ozone
production begins when the power switch and timer is turned on. (Refer to timer instructions below)
2a. (Setting Ozone Level (occupied areas)) The right level is when all the generated ozone is being used up to
accomplish its job. However, this is difficult to obtain because it becomes a balancing act. Initially the unit should
be used for a shock treatment to get rid of the problem odor as quickly as possible. After a shock treatment, set the
unit at a very low setting, after several hours if there is a heavy smell of ozone, then there is more ozone present than
is required to do the job. A good indication that the generator is set right is when you come home after being away
for 6-8 hours and smell just a hint of the fresh sweet smell of ozone. Simply turn the output level control down. This
is a case where more is not considered better. The levels of ozone required to deodorize most environments are from
.03 ppm to .1 ppm.
2b. (Setting Ozone Level (shock treatments)) For most shock treatment applications the setting should be set to the
highest setting. If the area being treated is small, the setting can be reduced to a lower level.
Using the included timer(AT models)
The one shot timer is designed to allow the user to turn on the ozone generator and have it turn off
after a given amount of time. Depending on the ozone generator model purchased your timer may or
may not have the same settings as the one shown in the pictures, however the operation will be the
same.
550AT operation
1. The timer is wired in parallel with the on/off switch. This means that if you wish to use the timer
leave the power switch off. If you wish to use the switch for constant run simply turn the switch to on
and leave the timer off.
2. To turn the timer on to constant run (hold) simply press the button once, the top green LED will
light up and after about 2 seconds the machine will turn on.
3. To set the timer for a one shot timed operation press the button several times until the LED beside the desired
amount of time is lit up, after about 2 seconds the machine will start.
4. To stop the operation of the timer press and hold the button for 3 seconds until the LED goes out and the
machine stops.
1100AT operation
1. The timer is wired in series with the HI/off/Low switch. This means that if you wish to use the timer you must
also turn the power switch on. If you wish to use the HI/off/Low switch for constant run you will also need to turn
the timer to constant run. (Refer to next step)
2. To turn the timer on to constant run (hold) simply press the button once, the top green LED will light up and
after about 2 seconds the machine will turn on.
3. To set the timer for a one shot timed operation press the button several times until the LED beside the desired
amount of time is lit up, after about 2 seconds the machine will start.
4. To stop the operation of the timer press and hold the button for 3 seconds until the LED goes out and the
machine stops. 6 YEAR INTERNATIONAL WARRANTY STATEMENT FOR THE FOLLOWING MODELS
1. CAMIwarrants thatCAMIozone generators will be free fromdefectsin material and workmanship fora 6 year Period. The warranty
period begins on the date of purchase. The original invoice is required as proof of purchase.
2. If an ozone generator is found to be faulty, CAMI will either repair or replace the faulty ozone generator at no charge provided
that it is returned to our head office in BC, Canada, transportation charges prepaid and properly packaged as to ensure that the
equipment arrives safely.
3.To obtain warranty on your CAMI ozone generator contact CAMI prior to shipping the unit to obtain proper return procedures and
an RA (return authorization number) number, see bottom for contact info.
Exclusions
-Damage caused by misuse, neglect or lack of regular maintenance.
-Cost of installation or removal of the equipment.
-Mica plates and UV tubes are limited to 6 months warranty.
-Wall transformers for DC powered units are warranted for 1 year.
-Damage caused by improper packaging or shipping procedures.
-Extra charges incurred as a result of improper packaging or shipping procedures.
-Shipping to and from CAMI.
CAMI IS NOT RESPONSIBLE FOR ANY DAMAGES TO EQUIPMENT OR PROPERTY, LOST PROFITS, OR COSTS DUE TO
USE OR MISS USE OF ANY CAMI PRODUCT.
