Cozzia CZ-710V User manual
USER MANUAL CZ-710V/Qi SE
Hello.
1
Cozzia Qi SE.
At Cozzia we understand that every body is different and have carefully designed your massage chair with that in mind.
TABLE OF CONTENTS
2
INTRO
Dimensions
Contents
3
4
MASSAGE
Interface
Pre-Programed Massage
Demo
Custom Massage
Spot Massage
Settings
Voice Control
9-12
13-18
19-20
21-25
26-28
29-34
35-42
Safety
Grounding Instruction
Troubleshooting
Care and Storage
Warranty
CARE
43-45
46
46
47
47-48
CHAIR
Move & Clearance
Components
Massage Points
Specification
5
6
7
8
3
DIMENSIONS
First, let’s get your chair inside.
47.6”
62.2” 33.1”
Base & Backrest Side Panels Footrest
1
Box 2
Box 3
Box
30.3” 57.7”
39.4”
50.4”
15.0”
26.8”
22.8” 19.7”
24.4”
4
CONTENTS
CZ-710V
Warranty Postcard
CZ-710V Massage ChairWired Touch-PadPower Cord
Everything you need for a relaxing experience.
Installation Manual
CZ-710V/Qi SE
USER MANUAL CZ-710V/Qi SE
User Manual
5
Move & Clearance
Reserve space on left and right Reserve space on the front and back
8” 8”
31.5”
4.8”
CLEARANCE
HOW TO MOVE
Caution: If you roll the chair on wood floor, marks may be left
Two people are needed to lift the chair
A few simple steps to find the best place for your new chair.
Move with a slight pull or push
6
CHAIR COMPONENTS
Note: The speaker will only operate when the massage chair is in operation
Some of your chair’s most important features.
Speaker
Backrest Pad
Armrest Buttons
Side Panel
Slip Bar
Footrest
Pillow
Shoulder Panel
Wired Touch Pad
Armrest
Seat Pad
To play music using your massage chair’s speakers please connect your
smartphone, tablet, or other electronic device to your chair using bluetooth.
7
MASSAGE POINTS
18 air bags
Massage
roller with
heat
26 air bags
Headpat on knee
16 air bags
Double row
foot roller
Back Massage Mode Air Bag Roller
8
CHAIR SPECIFICATIONS
Model No.
CZ-710V/Qi SE
Power Consumption
150W
Max Massage Time
30 minutes
Shipping Weight
Gross weight: 324 lbs
Net Weight: 280.5 lbs
Safety Feature
Equipped with overheatingand power
surge detectors safety feature
Dimensions (L x W x H)
Chair Dimension: 62.2″ x 33.1″ x 47.6″
Reclined Dimension: 77.2″ x 33.1″ x 41.3″
A few important facts about your massage chair.
Rated Voltage
110 - 120V
Rated Frequency
60Hz
Power of Speakers
14W (2 sides)
Length of Wiring
Controller wiring: 27.6"
Power supply wiring: 70.9”
Usage Condition
Environment temperature: 10。
C-40。
C
Contrastinghumidity: 30-85RH
Storage Condition
Storage temperature: -20。
C-60。
C
Storage humidity level: 30-85RH
