CONSTRUCTA Built-in oven User manual

en Instructions for use

es Instrucciones de uso

sv Bruksanvisning

Built-in oven

Horno eléctrico

integrable

Inbyggnadsugn

en page 03–32

es página 33 – 62

sv sidan 63 – 92

Table of contents

Important information . . . . . . . . . . 4

Packaging and old appliances . . . . . 4

Before installation . . . . . . . . . . . . . . 5

Safety information . . . . . . . . . . . . . . 5

Reasons for damage . . . . . . . . . . . . 6

Your new cooker . . . . . . . . . . . . . . 7

The control panel . . . . . . . . . . . . . . . 7

Function selector . . . . . . . . . . . . . . . 7

Temperature selector . . . . . . . . . . . . 8

Press-down switches . . . . . . . . . . . 8

Slide-in levels . . . . . . . . . . . . . . . . . . 8

Accessories . . . . . . . . . . . . . . . . . . 9

Before using the appliance

for the first time . . . . . . . . . . . . . . . 10

Preliminary cleaning . . . . . . . . . . . . . 10

Initial burn-in . . . . . . . . . . . . . . . . . . 10

Cleaning out . . . . . . . . . . . . . . . . . . 10

Heating modes . . . . . . . . . . . . . . . 11

Oven control . . . . . . . . . . . . . . . . . 13

Baking . . . . . . . . . . . . . . . . . . . . . . 14

Baking table . . . . . . . . . . . . . . . . . . 15

Cooking tips and helpful hints . . . . . 17

Inhaltsverzeichnis

Roasting . . . . . . . . . . . . . . . . . . . . . 18

Roasting table . . . . . . . . . . . . . . . . . 20

Grilling . . . . . . . . . . . . . . . . . . . . . . 21

Circo-roasting . . . . . . . . . . . . . . . . . 22

Surface grilling . . . . . . . . . . . . . . . . . 23

Defrosting and slow cooking . . . . 24

Defrosting using the hot air system . 24

Cleaning and care . . . . . . . . . . . . . 26

Important notes . . . . . . . . . . . . . . . . 26

Removing/installing the oven door . 28

Inset rack . . . . . . . . . . . . . . . . . . . . 29

Service and repair information . . . 30

Trouble-shooting guide . . . . . . . . 31

Important information

Please read these instructions for use carefully. They

contain important information concerning your

personal safety as well as for the use and care of

your appliance.

The instructions for use apply to several versions.

Accordingly, you may find descriptions of individual

features which do not apply to your specific

appliance.

Please keep the operating and installation

instructions in a safe place; this important

documentation may also be of use to a subsequent

owner.

Packaging and Your new appliance was protected by suitable

old appliances packaging while it was on its way to you. All

materials used for this purpose are environmentally

friendly and can be recycled. Please make a

contribution to protecting the environment by

disposing of the packaging appropriately.

Old appliances are not worthless rubbish.

Environmentally-conscious recycling can reclaim

valuable raw materials. Before disposing of your old

appliance, please make sure that it is unusable or

label it with a sticker stating ‘Caution – Scrap’.

This appliance is labelled according to the European

Directive 2002/96/EC concerning waste electrical

and electronic equipment – WEEE. The Directive

creates the framework for withdrawal and

reclamation of old appliances applicable throughout

the EU.

Up-to-date information on how to dispose of your

old appliance and the packaging from the new one

can be obtained from your retailer or local authority.

Before installation

Transport damage Check the appliance after unpacking it.

Do not connect the appliance if it has been

damaged in transport.

Electrical connection The appliance may only be connected by an

approved specialist. Losses resulting from damage

caused by incorrect connection will invalidate

warranty claims.

Safety information This appliance is intended for domestic use only.

Only use the cooker for food preparation.

Hot oven Open the oven door carefully. Hot steam may

escape. Never touch the internal surfaces of the hot

oven or the heating elements. Risk of being burnt!

Children must be kept at a safe distance from the

appliance.

Never store combustible items in the oven. Never

place flammable objects onto the hobs. Fire hazard!

Never place cables of electronic devices onto the

hobs.

Never trap leads of electronic devices in the hot oven

door. The isolation on the leads could melt. There is

a risk of short-circuiting.

Remove all packaging remnants, e.g. polystyrene

parts, from the oven.

Repairs Incorrectly done repairs are dangerous.

There is a risk of electrocution!

Only an after-sales service technician trained by us

may carry out repairs.

If there is a fault, switch off the fuse in the fuse box.

Call the after-sales service.

Reasons for damage

Baking sheets, aluminium foil Do not place a baking sheet on the oven floor. Do

or crockery on the floor of not line the oven floor with aluminium foil. Do not

the oven place crockery on the base of the oven. This causes

heat to accumulate. Baking and roasting times will

no longer be correct and the enamel will be

damaged.

Slide-in parts In order to avoid damage, insert slide-in parts

carefully.

Baking paper If using hot air *, do not place greaseproof paper

loosely in the oven (e.g. when heating the oven). The

hot-air fan could draw in the paper which may

damage the heater and fan.

Water in the oven Never pour water directly into a hot oven. This could

damage the enamel.

Fruit juice When baking very moist cakes, do not put too much

on the baking sheet. Fruit juice dripping from the

baking sheet leaves stains that cannot be removed.

It is recommended that you use the deeper universal

pan.

Cooling with the door open Only leave the oven to cool with the door closed.

Do not allow anything to become trapped in the

oven door. Even if you only leave the oven door open

slightly, the fronts of adjacent units could be

damaged over time.

Very dirty oven seal If the oven door seal of is very dirty, the oven door

will no longer close correctly when the oven is in use.

The fronts of adjacent units could be damaged.

Keep the oven door seal clean.

Using the oven door

as a seat Do not stand or sit on the oven door.

Care and cleaning Do not use a high-pressure cleaners or steam jets.

Your new cooker

Here, you will learn more about your new oven. The

control panel and its switches and displays are

explained here. The operating modes and the

accessories included with new oven will be explained

here.

The control panel

Function

selector

Temperature selector

with indicator lamp

Function selector You can select the operating mode for the oven

using the function selector.

Settings

Hot air

Top/bottom heat

)

Large grill area

Circo-roasting

Bottom heat

Defrost setting

Oven light

Temperature selector

Settings:

50 –275

Temperature in °C.

Press-down switch To engage and disengage, depress the switch.

Slide-in levels Your oven features 4 slide-in levels.

The slide-in levels are numbered from bottom to

top.

The numbers are marked on the oven.

When using hot-air baking *, do not use slide-in

level ››2‹‹, in order not to block air circulation.

Accessories Your oven is supplied with the following

accessories:

Universal pan with a grille Aluminium baking sheet

The following accessories can be obtained from

a specialist dealer: Order Number

Notes:

The protective device prevents contact with the hot oven door.

This is especially important in the presence of young children.

The baking sheet or universal pan may distort when the oven is operating. This is

caused by major temperature differences on the utensil. These differences may occur

if only one part of the utensil was covered or if deep-frozen food e.g. pizza, was pla-

ced on the utensil.

The distortion subsides again during baking, roasting or grilling.

Steam cooker

Aluminium baking sheet

Enamel baking sheet

Baking / Roasting grille, bent at right angles

Baking / Roasting grille, fine meshed

Universal pan with an inlay grille CZ 1242 X0

CZ 1282 X0

CZ 1332 X0

CZ 1342 X0

CZ 1432 X0

CZ 1442 X0

Retrofit kit – telescopic pullout for two tiers CZ 1702 X0

Retrofit kit – telescopic pullout for three tiers CZ 1742 X0

Retrofit kit – full telescopic pullout for four tiers CZ 1752 X0

Protective device for the oven door 440651

Before using the appliance

for the first time

Preliminary cleaning Take the accessories out of the oven.

Remove all packaging remnants, e.g. polystyrene

pieces, from the oven.

1. Clean the appliance exterior with a soft

moistened cloth.

2. Remove the hanging grid from the oven.

3. Clean the oven and the accessories with a hot

detergent solution.

Observe the operating instructions enclosed with the

hob.

Initial burn-in Heat the empty oven for approx. 30 minutes.

Select top and bottom heat at a setting of 240 °C.

Cleaning out Clean the oven with a hot detergent solution.

Fit the hanging grid.
