Commax DP-LA01M User manual

DOOR PHONE DP-LA01M,LA01S

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

To prevent fire or shock hazard, do not expose

This symbol is intended to alert the use to the

“

“dangerous Voltage”

”

within the product’s enclose that

may be of sufficient magnitude to constitute a risk of

This symbol is intended to alert the use to the

accompanying the appliance

1. W arnings and Caution

the unit to rain or moisture.

presence of uninsulated

electric shock to persons.

presence of important operating and maintemance

(servicing) instructions in the literature

2. Overview

3. Operation

CAUTION : To reduce the risk of electric shock, do not

personnel.

caution

Risk of electric shock

do not open

part inside refer servicing to qualified service

remove cover(or back) no user-serviceable

DP-LA01M DP-LA01S

Handset

Call Volume

Door Open Button

Power Cord

Handset

Call Button

Switch

Door Open Button

Call Button

[Communication with the door station]

1. When a visitor press the calling button,

(Volume can be adjusted by the switch on

2. Pick up one handset between Master and

3. Check the visitor first and push the door

both handset Master and Slave ring.

the side of handset: only DP-LA01M)

Slave and start the communication.

open button to open the door.

3.

Operation

4. Wiring





DP-LA01S

1. Pick up the handset to call another handset.

2. When other party gets the phone, the conversation begins.

3. If a visitor presses the call button while the handset is

4. Hang up the phone to finish the conversation between

with the visitor.

(If you pick up the handset, it will be connected to the door

[Communication between handset]

DP-LA01M

(The handset will be called while the button is being pushed.)

being used, the handset will ring

handsets and pick it up again to begin the conversation

unit automatically.)

5. Specifications

Call : High 400mW

Low 100mW

Talk : 70mW

30m, 0.65ø(When talking to Master)

50m, 0.65ø(When talking to door station)

DP-LA01M :208(D) X 98(W) X 60(H)mm

DP-LA01S :208(D) X 98(W) X 65(H)mm

DP-LA01M : 510g

DP-LA01S : 675g

OUTPUT POWER

DISTANCE

DIMENSION

WEIGHT

POWER SOURCE AC 110/120/220/230/240V,50-60Hz

Printed In Korea / 2016.04.105

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea

Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133

Web site : www.commax.com
