Comica CVM-VS07 User manual

CVM-VS07

Mini Flexible Plug-In Omnidirectional Microphone

(For GOPRO,Camera,Phone,Stabilizer)

USER MANUAL

Foreword

Packing List

Thanks for purchasing COMICA CVM-VS07 Mini Flexible Plug-in Omnidirectional Microphone. This

item is universal for GoPro, DSLR Camera, Phone and Stabilizer , is a Omnidirectional Microphone with

3.5mm TRRS Plug, 90 Degree Adjustable Audio Recording Direction, Metal Housing Construction and

Excellent Shielding features, which is deﬁnetely the best assistant for your video recording;

To ensure bring you a good using experience, please read this manual book carefully before using

and correctly install and operate.

Microphone Windscreen User Manual Warranty Card

CVM-VS07

MiniFlexible Plug-In Omnidirectional Microphone

(ForGOPRO,Camera,Phone,Stabilizer)

USER MANUAL

1

Notice

For the Android system smartphone, the microphone works well in default audio mode,

but default video mode will happen with incompatibility trouble while working with some

smartphone;(Then we suggest you try the 3rd party’s video APP);

For the iOS system phone, the microphone works well in all default audio mode , video

mode, and 3rd party’s APP;

When used with a smartphone, please set it to ﬂight mode to avoid interference;

Do not use this equipment near heat source or interference source, such as radiator,

oven, refrigerator, air conditioner or next to the WIFI AP;

Please use the windscreen while the sound distance is too closed or in outdoor to avoid

sound broken or wind noise;

Do not use the equipment in rain or in a damp environment to avoid short-circuit danger;

Please keep the product in a dry environment;

2

Main Features

. Plug-In Omnidirectional Mic

. 90 Degree Adjustable Recording Direction Construction

. Metal Housing for Excellent Shielding

. Built-in Shock-mount and Gold Plated Capsule

. Mini、Light and Flexibly Universal for GoPro,Camera,Phone,Stabilizer

90 Degree

Adjustment

Shock Absorption

Omnidirectional Metal Housing

for Better Shielding

Mini&Compact

3

Components Instruction

Capsule

Rotary Axis

3.5mm TRRS Plug

①

③

②

①②③

4

Product Installation and Use

1.Windscreen Installation

First Step: Put on the Windscreen Second Step: Normal use

5

2.Work with GoPro

First Step:

Insert microphone into 3.5mm socket

Second Step:

Adjust to right direction

Third Step:

Nomal use

6

3.Work with Camera

First Step:

Insert microphone into 3.5mm socket

Second Step:

Adjust to right direction

Third Step:

Nomal use

7

4.Work with Phone

First Step:

Insert microphone into 3.5mm socket

Second Step:

Adjust to right direction

Third Step:

Nomal use

8

Speciﬁcation

1.Frequency Response 2.Polar Pattern

-2.0

-20.0

-10. 0

0.0

-2.0

-4.0

-6.0

-8.0

-10.0

-12.0

-14.0

-16.0

-18.0

-20.0

-22.0

-24.0 -25.0

dB rel. 1V/Pa

+5.0

Frequency:

500 Hz :

1000 Hz :

4000 Hz :

8000 Hz :

14000 Hz :

9
