Comfier CF-F25H User manual

Leg and Foot Massager

User Manual

CF-F25H

2• This items is NOT A TOY. Close supervision is necessary when this appliance is used by , on,

or near children or disabled persons. Do not allow children to play with product .

• Never use any power sources other than UL standard home adapter provided as original

equipment with this massage device.

• Please avoid contact of the device with water, high temperatures and direct sunlight.

• Do not damage ,process ,excessively bend ,pull hard ,twist or knot power cord.

• Do not use any damaged cables, plugs or loose sockets.

• Do not use the product when the power cord is damaged.

• Misuse or incorrect use excludes any liability for damage.

• Do not use while you sleep.

• Do not use this product for medical treatment.

this massage device.

• During use, if you feel abnormal, please stop using this product immediately, and then

consult your doctor.

and can cause serious injury or burns.

1.Those who are using electronic medical instrument imbedded in the body ,

such as cardiac, pacemaker etc.

2.Those who are being treated by doctors ,especially those who feel uncomfortable.

5.Those with osteoporosis or fracture spine.

6.Those with skin disease or those whose skins are injured.

7.Those whose body temperature is over 38 degrees(Febrile Phase).

3CONTENTS

TECHNICAL DATA

Control Panel

Carrying Handle

Measurements:

Weight:

Voltage:

Nominal Power:

23.4 x 22 x 21.4 inches

28.6lbs

Input: AC 100-240V ~50/60Hz

Output: 24VDC 2.5A

15 minutes

With normal care and proper treatment, it will provide years of reliable service.

FEATURES

- 4 new massage techniques: scrapping,squeezing,shiatsu and Heat

- 3 preprogrammed massage modes

- 2 levels of intensity

Cloth cover with zipper,

Removable and washable

24V home adapter

42. Connect the adapter cable to the corresponding port on the leg & foot massager.

3. Plug the home adapter into electrical outlet ( the adapter is safe to use with

both 110-120V & 220-240V )

Do not use the wet hand to plug in the adapter.

Before plug ,please check and make sure the power cord is undamaged.

Please don’t use the product by standing posture or put any heavy object

on the product to avoid any broken caused.

Please don’t stand or seat on the product .

When moving the product, please don’t pull the power cord or drag the product

directly to avoid any damaged caused.

happened.

Do not use the wet hand to pull out the power cord in order to avoid any

electric shock.

Do not use this product in damp environment to avoid electric shock.

•

• • Do not setup or use the device in a bathroom or similary wet / damp areas.

5Press to turn the massager,it starts to work in

Press to choose I / II level of intensity

Press to choose massage Mode III / I / II

Mode

Mode lll

Mode ll

Mode l

Status Sequence

Pause Once during each cycle,

Foot Massaging Mechanism

Leg Massaging Mechanism

Sole Heat

Leg Massaging Mechanism

No pause during each cycle

• Please choose a chair with desired height and be seated, then put your feet on

the product.

• Operate below control panel to get leg and foot massages.

The cloth cover is equipped with a zipper, detachable and washableNote:

6TROUBLESHOOTING GUIDE

noise in the movement

Fault Solutions

This is normal caused by the working of the motor

while in use.

Check if device has been used for more than 15mins.

environments.

Check if adapter is plugged into socket.

Check if adapter output is connected to device

power inlet.

suddenly

Device may have been in use for 15minutes.

15minutes.

The massage device fails to start

from the socket.

-Do not pull the power plug by damp hands.

-Do not use water washing product ,do not spray the water or other liquids to the interior of

the product.

-Do not use corrosive cleaning agents like benzene or thinner to clean the Massager ,

otherwise ,the color of upholstery will fade or the Massager will crack or be eroded.

-When product is wet ,let the product dry naturally and thoroughly.

• Detach the cover and wash in machine or by hand. Allow to air dry

-Store the massager in a cool, dry place out of reach of children.

-Avoid contact with sharp edges or pointed objects which might cut or puncture the cover

of massager.

Warranty

30 days uncondi onally Return

90 days refund/replace

12 months Warranty

A en on!

Tel:

Email:

Extend Warranty for Free 7

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protec�on against harmful interference in a residen�al

installa�on. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instruc�ons, may cause harmful

interference to radio communica�ons.However, there is no guarantee that

interference will not occur in a par�cular installa�on. If this equipment does cause

harmful interference to radio or television recep�on, which can be determined by

turning the equipment oﬀ and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separa�on between the equipment and receiver.

• Connect the equipment into an outlet on a circuit diﬀerent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

This device complies with Part 15 of the FCC Rules. Opera�on is subject to the following

two condi�ons: (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

opera�on.

WARNING: Changes or modiﬁca�ons to this unit is not expressly approved by the party

responsible for compliance could void the user's authority to operate the equipment.

FCC STATEMENT
