1. Table (list) of contents.
:
1. Tableofcontents sid. 2
2. General 3
3. Overviewofcomponents,membranswitch 4
3. Overviewofcomponents,front 5
3. Overviewofcomponentsmixingsystem 6
4. SERVICE;Installationandstart 7-8
Placethe brewer
Connectings:Electricity/Water
Startingupmachine
Fillcanisters
5. Operation
Brewingof coffeein cup, , 9
Brewingof jug 10
6. Cleaningprogram
Automaticcleaning of brewmechanism 11-12
Automaticcleaning of mixingbowl 13
AutomaticcleaningofIn/Outletvalves 14
Rotatebrewmechanism withoutwater or ingredients 15
7. Weeklycleaning
dismantlemixersystem 16
washtheseparts 16
assemblemixer system 17
8. Cleaningandmaintenance
dismantlingexchangeand cleaningof coffee filter 18
outsidecleaning 19
9. CupcounterandEasy access 20
10. Safetyfunctions 21
11. Failure messages 21
12. Storage/Transport. 21
13. Dimensionsketch 22
14. Circuit diagram. 23
2.
2. General. Future
We congratulate toyour choiceof aCQ Future automat.
Please read this manual before you take the machine into operation for the first time.
Themanualcontains importantinstructions for asafe andproperuse ofthe machine.
Alwayskeepthis manualwithin reach forthe user!
CQ Future Combi automat
- Makingcoffee cupby cup
- Jugfacilitywith key switch
- 8 choices of drinks,
- 3or 4 ingredients canisters,
- Brewingmechanismwith coffeefilter
- Electronicallytemperaturecontrolled
- Adjustablecoffeestrength
- Illuminatedcupwhilebrewing
- Clockfunctions
Facts: Future III / IV
Height 780mm base cabinet 800mm
Width 420 mm base cabinet 420mm
Depth 550 mm base cabinet 460mm
Weight 35kg(emballage cá 4kg)
Tankage 2.4 litre
Electricity 230V/2200W
Waterconnection ½”outsidethread
Capacity:Future III
Cups of coffee 200cups/filling
Ingredientscanisters 3st.(coffee, chocolate,topping).
Capacity: Future IV
Cups of coffee 200cups/filling
Ingredientscanisters 3st. (coffee, instantcoffee, chocolate,topping).
3.
3. Overview of components membranswitch. Future
4.
Drink 1 Drink 5
Drink 2 Drink 6
Drink 3 Drink 7
Drink 4 Drink 8
Membranswitch
Outlet drinks
Drip tray
Display
5.
3. Overview of components , front Future
Key switch
Membran switch
8 choices of
drinks
Door lock
Strength of
drinks ++ / - -
Drip tray insert
Chute
Mixerbowls
Ingredients-
canisters
Brewing
mechanism
3. Overview of components , mixer system Future
6.
Detail; Ingredients; Width; Height; Volume/litre; Amount/unit
Canister; coffee 160 250 5,3 ´ 1
Canister; choco 78 250 - 1
Canister; topping 78 250 - 1
Outlet
Detail; Ingredients; Width; Height; Volume/litre; Amount/unit
Canister; coffee 160 250 5,3 ´ 1
Canister; instant coffee 67 250 - ´ 1
Canister; choco 67 250 - 1
Canister; topping 67 250 - 1
FUTUREIII
FUTUREIV
FUTUREIV
2mixer bowls
FUSEholder
Mainswitch
4. Service. Installation and start Future
1. Placethe machine ona flatleveland waterproofsurface.
Connectthe electricalplug toa separate
grounded wall socket 230V 10A.
OBSERVE!
Make sure there is a space
behindthe machine for free flowof air.(minimum 10cm).
2. Connectattached watertube to coldwater withan R 1/2”.
Makesurethat thewater hose notare kinkedanywherewhen machineis
pushedinto place.
Please flush water tube before connecting it to machine, this to avoid any
particles to damage the inlet valve.
3. Openthewaterinlet.
4. Turnontheswitch insidethedoor.
Water is been filled into the tank
automatically with 2,4 litres of water.
Theheatingwill notstartbefore thewater
levelreachesthelevelsensor.
Set temperature is approx. 97ºC.
5. Close door.
7.
4.
8.
4. Service. Installation and start Future
6. Fill canisters with ingredients.
Takeout(thisto avoidunnecessery
spillagein the machine)ingredient
canistersandfill themwithingredients.
7. When placing the ingredient canisters;
Makesure that theoutlet pipeson the ingredientcanisters aretouching the
steamtraps (B)and that the coffee powderwill fallinto thecentre ofthe brew
mechanism(A).
Whenthe water isheated upto right temperature
the text ”Low temp” will disappear and ”Low temp”
the machine is ready to use.
(B).
(A).
Brewing of coffe etc. in a cup
1. Placea cupin thecentre ofthe cupholder.
2. The strength has a standard setting,
if you wish to increase or decrease it, do as
follows, ifnot continue to point 3.
Stronger drink;
Increase by pushing + or ++ for 5% or 10%
alternative
Weaker drink;
Decrease by pushing - or -- for 5% or 10%
(theindication lampwill goup ordown
dependingof choice).
3. Choosedrinkby pushingthe
buttonofeachmenu
Thedisplaywill show;”Pleasewait”,
andthelight on thecup will lightup.
4. Waituntilthelight oncupand the text
”Pleasewait” has beenturned off
beforeyoutake your cup.
5. Enjoyyourdrink.
9.
5. Operation; Brewing of coffee in cup Future
2.
1.
5. Operation; Brewing of coffee into jug. Future
Brewing of jug.
1. Placea jugin thecentre of drip tray. (For jug1,8L dismantledriptray).
Serving pot1, 8L: Serving pot 1,2L: art.nr. 1103091
art.nr.110001 Thermos pot 1L : art.nr. 1103251
10.
1.
2. Turnonthekey withjugsymboleclockwise.
3. 6cups of brewing is standardsettings,
Changeamountof cupsbypushing + or- button.
Optionalup to12 cups ordown to1 cup brewing.
4. Push button for drink 1.
5. Waituntil the lightand text”Please wait” hasbeen
turnedoffbefore you takeoutthe jug.
6. Servea jugwith goodcoffee.
2.
3.
4.
