OWNER’S GUIDE MODEL
4606X
©2013 Directed, All rights reserved.
The company behind Clifford®Auto Security
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
accessories available. The recipient of nearly 100 pat-
ents and Innovations Awards in the field of advanced
electronic technology.
Quality Directed products are sold and serviced
throughout North America and around the world.
Call (800) 876-0800 for more information about our
products and services.
Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
THE SCIENCE OF SECURITY™
QRG4606X 2013 06
Vista, CA 92081
www.clifford.com
Congratulations
Congratulations on the purchase of your state-of-the-art remote start
and keyless entry system. Reading this Owner’s Guide prior to using
your system will help maximize the use of your system and its many
features. For any additional questions please contact your authorized
Directed dealer or contact Directed at 1-800-753-0600. (U.S. only)
Additional Guide Information
Only basic commands, features and essential information are covered
in this compact guide. Your product has many advanced features
which are not discussed here, please consult the expanded online ver-
sion for these on the website listed on the back cover. Most sections in
this guide also contain additional information which can be found in
the expanded online version.
Important information
Government Regulations and Safety Information
Read the “Government Regulations”and “Warning! Safety
First”sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an autho-
rized Directed dealer.
Optional Remote Controls
A choice of two optional remote controls with additional features is
also available for use with your system. These remote control choices
are: LED 2-way (P/N 7856) and LCD 2-way (P/N 7756). See your
authorized dealer for purchasing details. Once purchased, please
go online to our website (listed on the back cover) and use system
model number 4806 or 4706 respectively to search for the appropri-
ate owner’s guide, which provides instructions on how to use these
remote controls.
Replacement remote controls
Please see your authorized dealer or visit us at www.directedstore.
com to order additional remote controls. Remote control part numbers
are found on the back of the device.
Contents
Important information ......................................................................................... 1
Remote Control ................................................................................................... 2
Control Center .................................................................................................... 2
Using your System............................................................................................... 3
Commanding the system....................................................................... 3
Performing Commands ......................................................................... 3
Remote Control Command table ............................................................ 4
Basic Commands (Direct Access) .......................................................................... 5
Lock ................................................................................................... 5
Unlock................................................................................................ 5
Remote Start........................................................................................ 5
AUX/Trunk.......................................................................................... 5
Battery Information.............................................................................................. 6
Battery Disposal .................................................................................. 6
Patent Information ............................................................................................... 6
Government Regulations ...................................................................................... 7
Warning! Safety First........................................................................................... 8
Installation .......................................................................................... 8
Remote Start Capable .......................................................................... 8
Manual Transmission Vehicles ............................................................... 9
Interference....................................................................................... 11
Upgrades ......................................................................................... 11
Water/Heat Resistance ...................................................................... 11
Limited lifetime consumer warranty ..................................................................... 12
Remote Control
Feature Description
Internal Antenna Used for transmitting information
Transmit LED Active when transmitting information
Command buttons (4)
A U X
A U X
A U X
AUX
Used to perform locking, unlocking, auxiliary channel and
remote start commands
Function button
A U X
Used to access function levels for commands, configuration
menus for programming and Car Selection
Control Center
Control CenterLED Button
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override operation.
* See online guide.
3
© 2013 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used keyless entry and remote start
features while Advanced commands control more specialized fea-
tures.
Confirmations for Basic or Advanced commands are indicated
by horn honks* and parking light flashes. A description of each fea-
ture confirmation is found in the following Basic command and Ad-
vanced command sections.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
AUX
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Lock
1. Press the
AUX
button once to access Function Level 1, The trans-
mit LED single flashes for 3 seconds.
2. Press the
AUX
AUX
button while the transmit LED is still flashing to
perform the Silent Lock command.
3. The system will lock the doors and flash the parking lights,
without horn honks.*
* The optional Horn Honk feature must be connected.
4© 2013 Directed. All rights reserved.
Remote Control Command table
Basic
Commands
Advanced Commands
Function
Level 1
Function
Level 2
Function
Level 3
Function
Level 4
Button
Level Direct Access
A U X
x 1
A U X
x 2
A U X
x 3
A U X
x 4
A U X
Lock Silent Lock
A U X
Unlock Silent Unlock Remote Valet Car Finder
A U X
Remote Start Reset Runtime Timer Start Smart Start Defogger
AUX AUX/Trunk AUX 1 AUX 2 AUX 3 AUX 4
A U X
Advance
Level, Change
Car (3 sec),
Enter program-
ming (8 sec)
5
© 2013 Directed. All rights reserved.
Basic Commands (Direct Access)
Lock
Press and release
AUX
AUX
Doors lock (if connected), the horn honks** once and the parking
lights flash one time.
To Lock and Panic
Press and hold
AUX
AUX
To lock the system, then activate Panic. For Panic to be effective,
the optional horn honk feature must be connected. Press the
AUX
AUX
or
AUX
AUX
button to stop Panic output.
Unlock
Press and release
AUX
AUX
The doors unlock (if connected), the horn honks** twice and the park-
ing lights flash.
Remote Start*
Press and release
AUX
AUX
Activates (or if On, deactivates) the remote starter. The engine turns
On, or the engine turns Off accordingly. If a Remote start configura-
tion issue prevents the engine from starting, the parking lights flash a
Remote Start fault report to identify the fault.
AUX/Trunk**
Press and hold
AUX
The Trunk opens (if connected) when button is held for 2 seconds.
* See online guide.
**This is an optional feature, see your authorized Directed dealer.
6© 2013 Directed. All rights reserved.
Battery Information
The remote controls are powered by one coin cell battery (CR-2032)
that can be purchased at most retailers. When the battery begins to
weaken, the operating range is reduced.
Battery Disposal
Directed cares about the environment. If you need to dis-
pose of the battery, please do so in accordance with your
municipal requirements for battery disposal.
Patent Information
This product is covered by one or more of the following United States
patents:
Remote Start Patents:
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Vehicle Security Patents:
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Other patents pending.
7
© 2013 Directed. All rights reserved.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television,
which can be determined by turning the equipment OFF and ON, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Remote Controls
To satisfy FCC RF exposure compliance requirements, this device should be
used in hand-held, hand operated configurations only. The device and its an-
tenna must maintain a separation distance of 20 cm or more from the person’s
body, except for the hand and wrists, to satisfy RF exposure compliance. This
device is designed to be used in a person’s hands and its operating configu-
rations do not support normal transmissions while it is carried in pockets or
holsters next to a person’s body.
Other manuals for 4606X
1
Table of contents
Other Clifford Car Alarm manuals
Clifford
Clifford 4606X User manual
Clifford
Clifford 3706X User manual
Clifford
Clifford XL1000 User manual
Clifford
Clifford SE 3030 User manual
Clifford
Clifford concept 50x User manual
Clifford
Clifford CONCEPT 470 User manual
Clifford
Clifford Responder LC3 4706X User manual
Clifford
Clifford Model RSX3.5 User manual
Clifford
Clifford intellivoice User manual
Clifford
Clifford 500 User manual
Clifford
Clifford 20.5X User manual
Clifford
Clifford 5606X User manual
Clifford
Clifford Matrix 2.5X User manual
Clifford
Clifford Matrix 2.2X User manual
Clifford
Clifford Polaris 4 User manual
Clifford
Clifford Wireless Immobilizer XL 500 User manual
Clifford
Clifford Matrix 2.2X User manual
Clifford
Clifford 22CX User manual
Clifford
Clifford AvantGuard 3 User manual
Clifford
Clifford 4115X User manual
Popular Car Alarm manuals by other brands
Ultra Start
Ultra Start 2500M SERIES install guide
Ultra Start
Ultra Start 650 Series owner's manual
Audiovox
Audiovox Prestige Platinum+ APS-511C owner's manual
Sparkrite
Sparkrite SRA8 Guide
Viper
Viper 4708V owner's manual
Federal Signal Corporation
Federal Signal Corporation Pathfinder Siren Series Installation and maintenance manual
