NAME AND FUNCTION OF EACH PART
Function description on each button of main controller
Power supply and full auto function area
Turn on/off massage chair
When power is on, the VFD display screen is lightened, and
then user can choose the functions which the flashing
function buttons and memory function buttons correspond.
When power is off, the massage chair resets, at this moment, all the
function buttons can not work. When the button is flashing, it
signals the power supply is shut off and the massage chair has gone
to standby mode. After reset, the VFD display screen will also be shut
off.
Full auto function:There are four auto massage modes from RECOVERY,
EXTEND, RELAX to REFRESH for different people at different time.
Semi-auto function area
Upper back auto: Press this button
to turn on UPPER BACK AUTO function.
Lower back auto: Press this button
to turn on LOWER BACK AUTO function.
Press this button to turn on or off
the waist heater.
Press this button to turn on or off
the sole heater.
Airbag auto: Press this button to
turn on or off AIRBAG AUTO function.
Airbag intensity adjusting: Press this button to adjust the air
intensity; there is a 5-step shift mode for your options. When
the air intensity reaches the maximum/minimum point, a
double short reminding sound will be heard.
Press this button to turn on or off seat vibration function.
Vibration intensity adjusting: Press this button to adjust the
vibration intensity; there is a 5-step shift mode for your option.
When the vibration intensity reaches the maximum/minimum
point, a double short reminding sound will be heard.
Reclining backward operation
Backrest ascending
button
Backrest descending
button
Legrest ascending
button
Legrest descending
button
Before sitting down
Before sitting down, make sure all the components are back to their
original positions, if not, please turn on the power supply switch and
reset the components.
Caution
Do not sit on the massage chair when the legrest is raising.
Do not put heavy burden onto the legrest suddenly, otherwise, the
mechanical structure may be damaged.
Reclining and stretching system
Reclining backward/ forward
Keep pressing backrest descending button , the backrest will gradually
go down while the legrest will go up simultaneously with the double
reminding sound Di Di produced by the controller; When the massage chair
reaches to the proper angle, release the backrest descending button , at
this moment, the backrest and legrest will stop simultaneously. During
descending, if the legrest reaches to its highest point firstly, it will stop
ascending, while the backrest will continually descend. The controller will
give out continuous reminding sound when backrest reaches to the highest
point; the controller will give out continuous reminding sound when backrest
reaches to its lowest point while the legrest has not reached to its highest
point, at this moment, if only keep pressing the button, the legrest will
ascend continuously till to its highest point. The angle of legrest can be
adjusted separately by pressing button and button, during legrest
ascending/descending, the backrest keeps still. When legrest reaches to the
highest or lowest point, a continuous reminding sound will be heard.
USE METHOD
