Cateye Stealth 10 User manual
Click the button and follow the
instructions.
CATEYE STEALTH 10
CC-GL10
Quick Start
START
Thank you for purchasing our cyclocomputer CATEYE STEALTH 10.
This Quick Start Manual explains how to set up the computer and how to install the unit on
your bicycle.
Please set up the unit according to the specified procedure, then it will be ready for use as a
cyclocomputer.
Before use, read the instruction manual that comes with the product thoroughly to the
end to understand the functions of this unit, and to use it safely in a correct manner.
Next
This PDF contains a movie file.
When you click on the movie screen, a message regarding security appears. Click the
“Trust in the text” or “Play” button to close the message.
Click the screen again to play the movie.
Next
CATEYE STEALTH 10
Quick Start Manual Contents
Click on the item to view.
Return to a Cover
Setting up the computer
Uploading the measurement data
Setting up the computer from your PC
How to attach the bracket (movie format)
Operation of buttons
Set up the computer by operating the buttons as follows.
Check the button position before you start setting up.
AC
MENU
MODE
POWER
Next
CATEYE STEALTH 10
Quick Start Manual Setting up the computer
Formatting operation
Setting the speed unit
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Power ON
Pressing and holding the button on the back of the
computer for 2 seconds turns on the power, and the
screen lights up.
POWER
Power ON
(Press and hold)
Power ON
Return to Contents
Next
Return
CATEYE STEALTH 10
Quick Start Manual Setting up the computer
Setting the speed unit
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Formatting operation
Press the MENU button on the back of the computer and
the AC button simultaneously.
After all screen items light up, the display will be changed
to the speed unit setting screen, and setup will start.
All screen items light up
MENU
MENU
AC
AC
MENUAC MENUAC MENUAC
123
Press and hold the* MENU button for 3 seconds
after releasing the AC button.
Formatting operation
Power ON
Return to Contents
Next
Return
Formatting
operation
CATEYE STEALTH 10
Quick Start Manual Setting up the computer
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Setting the speed unit
Setting the speed unit
When the MODE button is pressed, either “km/h”or “m/h
(mile)” is selected for the speed unit display. Select the dis-
play of your choice.
Press the MENU button to go to the next step “Selecting
the time zone”.
To the next step
km/h ↔m/h (mph)
MENU
MODE
Formatting operation
Setting the speed unit
Power ON
Return to Contents
Next
Return
CATEYE STEALTH 10
Quick Start Manual
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Setting up the computer
Setting the time zone
Select the code for the city nearest from your current lo-
cation, while viewing the “Time zone list”.
When the MODE button is pressed, the city code chang-
es. After selecting the appropriate city code, press and
hold the MODE button to go to the next step “Setting the
daylight saving time”.
To the next step
Setting the time zone Switching the display
MODE
MODE
(Press and hold)
Formatting operation
Setting the speed unit
Power ON
Setting the time zone
Return to Contents
Next
Return
Time zone list
CATEYE STEALTH 10
Quick Start Manual Setting up the computer
GPS search screen
(Setup completed)
Setting the clock display format
Setting the daylight saving time
Change ON/OFF according to the period of daylight sav-
ing time, when you are on Daylight Saving Time.
Press and hold the MODE button to go to the next step
“Setting the clock display format”.
To the next step
OFF ↔ON
MODE
MODE
(Press and hold)
Setting the daylight
saving time
Formatting operation
Setting the speed unit
Power ON
Setting the time zone
Setting the daylight saving time
Return to Contents
Next
Return
