Casio FX-CG10 User manual

CASIO Worldwide Education Website

http://edu.casio.com

CASIO EDUCATIONAL FORUM

http://edu.casio.com/forum/

fx-CG10/20

Manager PLUS

User’s Guide

E-1

Getting Started

IAbout fx-CG10/20 Manager PLUS

• fx-CG10/20 Manager PLUS is an emulator that lets you perform fx-CG10/fx-CG20 operations on

your computer.

• You can record key operations you perform on the emulator as “Key-Log records”, and edit Key-

Log records as required.

• The keys on the Key-Log editor screen as well as the emulator LCD screen contents can be

pasted into other applications. This means that emulator data can be used to create assignments,

tests, and other materials.

• A presentation feature lets you play back saved Key-Log records.

• You can connect your fx-CG10/fx-CG20 unit to your computer and display its contents on your

computer screen.

Important!

• Be sure to install the fx-CG10/20 Manager PLUS before you connect fx-CG10/fx-CG20 to your

computer. Connecting before you install the fx-CG10/20 Manager PLUS can result in improper

operation.

IUsing This Manual

• For details about operation of the fx-CG10/fx-CG20 Graphic Scientific Calculator, see the user

documentation that comes with the calculator.

• The procedures in this manual assume that you are already familiar with the following standard

computer operations.

- Menu operations using the mouse, including: clicking, double-clicking, dragging, etc.

- Text input using the keyboard

- Icon operations, general window operations, etc.

- If you are not familiar with these types of operations, refer to the user documentation for your

computer.

• The screen shots shown in this manual are all from the English version of Windows®XP.

• Note that the actual appearance of the screen that appears when using this software depends on

your computer system setup and on the operating system you are using.

• Screen shots shown in this User’s Guide are intended for illustrative purposes only. The actual

text and values that appear on display may differ from the examples shown in this User’s Guide.

E-2

ISystem Requirements

Operating Systems: Windows®XP Home Edition, Windows®XP Professional (32-bit), Windows

Vista®(32-bit), Windows®7 (32-bit/64-bit)

Your hardware configuration needs higher than functionalities that operating

system recommends.

Computer: IBM PC/AT or compatible computer

Computer with one of the Windows®operating systems pre-installed

(Excluding computers with an upgraded operating system and self-built

computers.)

Disk Space: 100MB for installation and uninstall

Note: Actual requirements and product functionality may vary based on your system

configuration and operating system.

Other: USB port for direct connection. Do not connect via a USB hub.

Video adapter and display must support resolution of XGA (1024×768) or

higher, 16 bit or higher system color.

Internet Explorer®6.0 or later.

CD-ROM drive

Adobe®Reader®6.0 or later.

Microsoft®Excel®2000, Microsoft®Excel®2003, Microsoft®Excel®2007 or

Microsoft®Excel®2010

Note

• Windows is a registered trademark or trademark of Microsoft Corporation in the United States

and/or other countries.

• Microsoft Excel is a trademark of Microsoft Corporation registered in the United States and/or

other countries.

• Company and product names used herein are trademarks of their respective owners.

E-3

Contents

1. Installing and Uninstalling fx-CG10/20 Manager PLUS ...................... E-4

2. Screen Configuration............................................................................. E-9

Menu Bar.......................................................................................................................E-10

Toolbar..........................................................................................................................E-15

Status Bar .....................................................................................................................E-16

3. Emulator Mode and Key-Log Editor Mode......................................... E-17

4. Emulating fx-CG10/fx-CG20 Calculator Operation............................ E-18

5. Using the Emulator Key-Log ............................................................... E-24

6. Configuring Options Dialog Box Setting ........................................... E-30

7. Other Functions.................................................................................... E-32

Printing..........................................................................................................................E-32

Shortcut Menu...............................................................................................................E-34

8. File Types Supported by fx-CG10/20 Manager PLUS ....................... E-35

9. Differences between fx-CG10/fx-CG20 Calculator and

fx-CG10/20 Manager PLUS Functions ................................................ E-36

10. Using Screen Receiver to Display the Calculator Screen Image

on Your Computer................................................................................ E-46

11. Error Message Table ............................................................................ E-49

E-4

1. Installing and Uninstalling fx-CG10/20

Manager PLUS

This section explains how to install and uninstall fx-CG10/20 Manager PLUS.

To install fx-CG10/20 Manager PLUS

1. Place the CD-ROM into your computer’s CD-ROM drive.

• After a short while, the fx-CG Manager PLUS screen will appear on the display.

2. Click “fx-CG10/20 Manager PLUS”, and then click “Install”.

• This will display a dialog box for selecting the screen language.

E-5

3. Select the language you want and then click [OK].

4. Click the [Next] button.

• This will display the end user license agreement (EULA).

5. Carefully read the EULA.

E-6

6. If you agree to the terms and conditions of the license agreement, click “I accept the terms…”,

and then click the [Next] button.

• If you do not agree to the terms and conditions of the license agreement, click “I do not accept

the terms…” and then click [Cancel] button to exit the install procedure.

7. Perform either of the two following steps to specify the installation drive and folder.

7-a: If you want to use default settings, simply click the [Next] button. This is the method you

normally should use.

7-b: If you want to specify a different folder, click the [Change] button. Select the folder you

want and then click [Next].

E-7

8. Click the [Install] button.

• This will start installation.

9. The dialog box shown below will appear when installation is complete.

10. Click the [Finish] button.

• This completes installation.

Note

• Installing the software will put a “fx-CG10_20 Manager PLUS” shortcut icon on your Windows

desktop.

E-8

To uninstall fx-CG10/20 Manager PLUS

1. Display the Windows Control Panel.

2. Click [Add/Remove Program].

3. On the list of applications that appears, select “fx-CG10/20 Manager PLUS”.

4. Click the [Add/Remove] button.

• This will display the program maintenance wizard.

5. Click the [Yes] button.

• This completes the uninstall operation.

To start up fx-CG10/20 Manager PLUS

1. On your computer’s desktop, click the “fx-CG10_20 Manager PLUS” icon.

• You could also start up the application by clicking [Start] - [Program] - [CASIO] - [fx-CG10/20

Manager PLUS] - [fx-CG10/20 Manager PLUS].

E-9

2. Screen Configuration

The following shows the fx-CG10/20 Manager PLUS screen.

Menu Bar

Toolbar

Emulator

Status Bar

File Display Area

* When you have both the emulator window and Key-Log (or bitmap file) window open on the

display, the emulator window always will be displayed on top.
