Carrier RMAP-ST User manual
Please read the contents carefully before use.
This user guide contains the product warranty.
| AIR PURIFIER |
AIR PURIFIER AND
SMART AIR PURIFIER
User Manual
Air Purifier Models
RMAP-ST | RMAP-XL
Smart Air Purifier Models
RMAP-SST | RMAP-SXL
Features of the Air Purifier
Our 3-in-1 high-efficiency filter includes a pre-filter for large airborne particles,
a high-efficiency (models RMAP-ST, RMAP-XL) or HEPA (models RMAP-SST,
RMAP-SXL) filter for fine particles, and a carbon filter for odors and VOCs
(volatile organic compounds). In addition, the all-in-one design makes filter
replacement easy.
Advanced Filtration
Continuously samples incoming air, measures levels of pollution and indicates air
quality with an easy-to-read LED screen.
A powerful, 18-speed fan with 360-degree airflow pulls polluted air from below
and returns cleaner air in multiple directions.
Use Smart Auto Mode to allow the air purifier to automatically adjust fan speeds
based on the air quality level.
Air Quality Monitoring
360-Degree Airflow
Easy Operation
Note Functions and specifications may differ depending on the model.
* Wi-Fi® connection required. Works with Hey Google or Alexa and select Apple and Android™
mobile devices. Free Carrier Home app download required.
Connect Smart Wi-Fi® models with the Carrier® Home app so you can manage
your air purifier from anywhere by integrating with Hey Google or Alexa for
voice control.*
Smart Features
Table of Contents
Safety Precautions.......................................................................... 2
What's In the Box.............................................................................4
Product Description....................................................................... 5
Preparation for Setup/Use .......................................................... 9
Smart Air Purifier Setup/Connection ...................................11
Product Operation ........................................................................12
Indoor Air Quality Indications and
On-Screen Codes ..........................................................................15
Care and Maintenance................................................................16
Troubleshooting.............................................................................18
Customer Support....................................................................... 20
Warranty and Legal Notice....................................................21
Before Using
Product Setup
How to Operate
Things You
Should Know
2
AIR PURIFIER
Power Supply
Indication Description
Indicates that there is a possibility of injury or material damage in case of
violation of the instructions.
This product has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is intended to fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit in the outlet, contact a qualified electrician. Do not
attempt to defeat this safety feature.
Indicates that there is a possibility of death or serious injury in case of
violation of the instructions.
WARNING
CAUTION
Read these instructions thoroughly for the safety of users and to prevent property damage.
This air purifier is for 120V use only.
Note
Be sure to plug your product into a 120V outlet.
►Do not turn off the product by unplugging the power plug while in use.
►Contact customer service if the power plug or the power cord is damaged.
►Connect the power plug firmly to the wall outlet and do not use a damaged
power plug, a damaged power cord, or loose outlet.
Unplug the product during thunder and lightning. Product can be damaged due
to electric shock.
►If the product is not used for long period of time, unplug the unit to prevent
unnecessary overheating and to save electricity consumption.
Table of Contents
Safety Precautions
USER MANUAL
3
Safety Precautions
WARNING
Plug the product into an outlet. Do not press the product up against the wall plug.
• Do not extend the power cord at will.
• Do not use with a power strip as it may cause electric shock or fire.
Leave at least 12 inches (30 cm) between wall and product.
• If the air inlet and outlet space is crowded, it may impact the product's ability to filter
and recirculate the air.
Place on flat surface.
Initial Setup
►Do not use the product near flammable substances or a gas leak.
►Do not use the product in places exposed to high humidity, oil, grease, or water.
►Do not install the product in direct sunlight or near a heating vent.
PROHIBITED
When Using
CAUTION
Avoid installing the product within 3 feet (1 meter) of a television or other electronic device.
Turn off power immediately if water or other foreign matter enters the product. Dry the
product completely before turning on.
Using a dirty pre-filter or no filter will degrade product performance.
If there is a strange sound, burning smell or smoke coming from the product, unplug it
immediately and contact customer service.
►Do not replace the filter while the product is in use or plugged in.
►Do not use filters that are not recommended by the manufacturer.
►Do not move the product while in use.
PROHIBITED
►Do not clean when power is on as it may cause electric shock or malfunction.
CAUTION
When Cleaning
PROHIBITED
4
AIR PURIFIER
What's in the Box
Air Inlets
Bottom Base
Optional casters
included
Display
Air Outlet
Filter
Remote for
Smart Air Purifier
models only
What's in the Box
Note Product features and specifications may vary depending on the model.
Control Panel
Indoor Air
Quality
Indicator
+
+
–
–
•
•
•
•
•
•
•
•
OK
AUTO
x 8
USER MANUAL
5
Product Description
Product Specifications
Width
Height
Depth
Model Air Purifier
RMAP-ST
Air Purifier XL
RMAP-XL
Smart Air Purifier
RMAP-SST
Smart Air Purifier XL
RMAP-SXL
Power 120V, 60Hz, 1-phase
Wi-Fi
®
No No Yes Yes
Remote
Control No No Yes Yes
Dimensions
13.7" W x 13.7" D x 26.5" H
350mm W x 350mm D
x 675mm H
13.7" W x 13.7" D x 31.5" H
350mm W x 350mm D
x 800mm H
13.7" W x 13.7" D x 26.5" H
350mm W x 350mm D
x 675mm H
13.7" W x 13.7" D x 31.5" H
350mm W x 350mm D
x 800mm H
Room Size
Up to 430 sq. ft. Up to 560 sq. ft. Up to 430 sq. ft. Up to 560 sq. ft.
HEPA Filter
Replacement
Model
Number
RMAPFIL-HST RMAPFIL-HXL RMAPFIL-HST RMAPFIL-HXL
6
AIR PURIFIER
Product Description
Filter Type Function
①
Pre-Filter
(microfiber net) Filters large dust particles, smoke, pet dander and pollutants.
②
HEPA Filter Captures over 99.97% of particles sized 0.3 microns including pollen
and other allergens.
③
Carbon Filter Activated carbon filter traps odors.
③
Carbon Filter
①
Pre-Filter
②
HEPA Filter
Filter Detail
It is recomended that you replace the filter every 6-12 months. Replacement
period may vary depending on the product usage. Visit CarrierAtHome.com or
contact your dealer to order your replacement filter.
Note
Model: RMAPFIL-HST
USER MANUAL
7
Product Description
Display
Control Panel
Sleep mode / Timer Increase the timer and fan speed
setting value
LED ON/OFF & Wi-Fi® connection
(LED off cycle lasts 6 hours) Smart automatic operation
Decrease the timer and fan speed
setting value Power ON/OFF
Sleep
Smart Auto Mode
Sleep Mode
LED
Filter Replacement
Indicator
Wi-Fi Indicator
(Smart Air Purifier only)
Timer
Auto
Control Panel Descriptions
Sleep
LED
Auto
Turbo
LED Indoor Air
Quality Indicator
Note See page 12 for complete list of product operations.
8
AIR PURIFIER
Product Description
Remote Control (Smart Air Purifier only)
Remote Control Buttons
This product contains a lithium button/coin cell
battery. If a new or used lithium button/coin cell
battery is swallowed or enters the body, it can
cause severe internal burns and can lead to death
in as little as two hours.
Always completely secure the battery
compartment. If the battery compartment does
not close securely, stop using the product, remove
the battery, and keep it away from children.
1
2
3
If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate
medical attention.
Power ON/OFF Decrease the timer and
fan speed setting value Safety lock
Smart automatic
operation Timer Sleep mode
Increase the timer and
fan speed setting value
Confirm your timer
setting
LED ON/OFF
(Off cycle lasts 6 hours)
•
+
–
Remote Control Battery
CAUTION
CAUTION
+
+
–
–
•
•
•
•
•
•
•
•
OK
AUTO
AUTO
OK
