Canon EOS 1200D Installation guide

This basic manual covers only the most basic operations.

For other features and more details, see the

Camera Instruction Manual pdf le in the CD-ROM.

Basic Instruction Manual

COPY

The EOS REBEL T5/EOS 1200D is a high-performance, digital single-

lens reflex camera featuring a fine-detail CMOS sensor with approx.

18.0 effective megapixels, DIGIC 4, high-precision and high-speed

9-point AF, approx. 3.0 fps continuous shooting, Live View shooting,

and Full High-Definition (Full HD) movie shooting.

The camera is highly responsive to any shooting situation, and provides

many features for demanding shots.

Refer to This Manual While Using the Camera to Further

Familiarize Yourself with the Camera

With a digital camera, you can immediately view the image you have

captured. While reading this manual, take a few test shots and see how

they come out. You can then better understand the camera.

To avoid botched pictures and accidents, first read the “Safety

Warnings” (p.100-102) and “Handling Precautions” (p.12, 13).

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images or copyrighted music and images with music in the memory

card for anything other than private enjoyment. Also be aware that

certain public performances, exhibitions, etc., may prohibit photography

even for private enjoyment.

Introduction

COPY

Before starting, check that all the following items have been included

with your camera. If anything is missing, contact your dealer.

* Battery Charger LC-E10 or LC-E10E is provided. (The LC-E10E comes with a

power cord.)

The Instruction Manual and CD-ROMs provided are listed on the next page.

If you purchased a Lens Kit, check that the lenses are included.

Depending on the Lens Kit type, lens instruction manuals may also be

included.

Be careful not to lose any of the above items.

Item Check List

Battery Pack LP-E10

(with protective cover) Battery Charger

LC-E10/LC-E10E*

Wide Strap

Camera

(with eyecup and body cap)

Interface Cable

COPY

The instruction manual consists of a booklet and PDF manuals in

electronic form (provided on the CD-ROM disc). The booklet is the

Basic Instruction Manual. For more detailed instructions, see the

Camera Instruction Manual on the CD-ROM disc.

Camera Instruction Manual CD-ROM

Contains the following manuals in PDF format:

• Camera Instruction Manual

• Quick Reference Guide

Software Instruction Manual CD-ROM

Contains instruction manuals in PDF format for the

software on the Software CD-ROM.

* Instructions for viewing the Instruction Manual CD-ROMs are on page 89.

Software CD-ROM (EOS DIGITAL Solution Disk)

Contains various software. For more information and

installation procedures for the software, see pages 94-96.

Instruction Manual and CD-ROMs

Camera Basic

Instruction Manual

COPY

The camera can use the following cards regardless of capacity: If the

card is new or was previously formatted by another camera or

computer, it is recommended that you format the card with this

camera (p.42).

• SD memory cards

• SDHC memory cards

• SDXC memory cards

When shooting movies, use a large-capacity SD card rated SD

Speed Class 6 “ ” or higher.

If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card

with a slow reading speed, the movie may not play back properly.

If you want to shoot still photos while shooting a movie, you will need

an even faster card.

To check the card’s reading/writing speed, refer to the card

manufacturer’s Web site.

Compatible Cards

Cards that Can Record Movies

The camera can use UHS-I cards, but since it is not compatible with the

UHS-I standard, reading/writing speeds will be equivalent to SD Speed

Class 10 at most.

In this manual, “card” refers to SD memory cards, SDHC memory

cards, and SDXC memory cards.

*The camera does not come with a card for recording images/

movies. Please purchase it separately.

COPY

Quick Start Guide

1Insert the battery (p.24).

To charge the battery, see page 22.

2Insert a card (p.24).

With the card’s label facing toward

the back of the camera, insert it into

the card slot.

3Attach the lens (p.32).

Align the lens’s white or red index

with the camera’s index in the

matching color.

4Set the lens’s focus mode

switch to <AF> (p.32).

5Set the power switch to <1>

(p.27).

When the LCD monitor displays the

date/time/zone setting screens, see

page 29.

White index Red index

COPY

Quick Start Guide

6Set the Mode Dial to <A>

(Scene Intelligent Auto) (p.48).

All the necessary camera settings

will be set automatically.

7Focus on the subject (p.37).

Look through the viewfinder and

aim the viewfinder center over the

subject.

Press the shutter button halfway, and

the camera will focus on the subject.

If necessary, the built-in flash will be

raised automatically.

8Take the picture (p.37).

Press the shutter button completely

to take the picture.

9Review the picture.

The image just captured will be

displayed for 2 sec. on the LCD

monitor.

To display the image again, press

the <x> button (p.65).

To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.67).

To view the images captured so far, see “Image Playback” (p.65).

To delete an image, see “Erasing Images” (p.88).

COPY

Icons in this Manual

<6> : Indicates the Main Dial.

<W><X><Y><Z> : Indicates the <S> cross keys on the top,

bottom, left, and right.

<0> : Indicates the Setting button.

0, 9, 7, 8: Indicates that the corresponding function

remains active for 4 sec., 6 sec., 10 sec., or 16

sec. respectively after you let go of the button.

* In this manual, the icons and markings indicating the camera’s buttons, dials,

and settings correspond to the icons and markings on the camera and on the

LCD monitor.

3: Indicates a function that can be changed by pressing the

<M> button and changing the setting.

M: Shown at the upper right of a page title to indicate a

function that is available only in the Creative Zone modes

(p.18).

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Problem-solving advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is <1> (p.27).

It is assumed that all the menu settings and Custom Functions are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-55mm f/3.5-5.6 IS II lens as an example.

Conventions Used in this Manual

COPY

Introduction 2

Item Check List.................................................................................3

Instruction Manual and CD-ROMs....................................................4

Compatible Cards.............................................................................5

Quick Start Guide..............................................................................6

Conventions Used in this Manual .....................................................8

Handling Precautions......................................................................12

Nomenclature..................................................................................14

Getting Started 21

Charging the Battery.......................................................................22

Installing and Removing the Battery and Card ...............................24

Turning on the Power......................................................................27

Setting the Date, Time, and Zone...................................................29

Selecting the Interface Language...................................................31

Attaching and Detaching a Lens.....................................................32

Lens Image Stabilizer .....................................................................35

Basic Operation ..............................................................................36

QQuick Control for Shooting Functions........................................38

3Menu Operations..................................................................40

Formatting the Card........................................................................42

Switching the LCD Monitor Display.................................................44

Feature Guide.................................................................................45

Contents

COPY

Contents

Basic Shooting and Image Playback 47

AFully Automatic Shooting (Scene Intelligent Auto)................... 48

AFull Auto Techniques (Scene Intelligent Auto)......................... 51

7Disabling Flash......................................................................... 53

CCreative Auto Shooting............................................................ 54

2Shooting Portraits...................................................................... 57

3Shooting Landscapes............................................................... 58

4Shooting Close-ups................................................................... 59

5Shooting Moving Subjects........................................................ 60

6Shooting Night Portraits ............................................................ 61

QQuick Control............................................................................ 63

xImage Playback........................................................................ 65

Shooting with the LCD Monitor (Live View Shooting) 67

AShooting with the LCD Monitor ................................................ 68

Using AF to Focus (AF Method)..................................................... 71

Shooting Movies 77

kShooting Movies....................................................................... 78

Setting the Movie Recording Size.................................................. 80

COPY
