HR-1

HRVATSKI

Instructions Manual For Induction Hob

ENGLISH

Manuale di istruzioni per il piano cottura a induzione

ITALIANO

Használati útmutató indukciós főzőlaphoz

MAGYAR

Navodila za uporabo za indukcijsko kuhalno ploščo

SLOVENSKO

Instrukcja obsługi płyty indukcyjnej

POLSKI

Manual de instruções para placa de indução

PORTUGUES

Priručnik s uputama za uporabu indukcijske ploče za kuhanje

HRVATSKI

CI642CTT/E1

Thank you for purchasing the CANDY induction hob. Please read this instruction manual

carefully before using the hob and keep it in a safe place for future reference.

EN-2

EN-3

EN-4

59cm 52cm

6.2cm 5.8cm

EN-5

1. Max. 1300/1500W zone

2. Max. 2300/2600W zone

3. Max. 1800/2000W zone

4. Max. 1800/2000W zone

5. Glass plate

6. Control panel

1. On/Off control

2. Timer control

3. Boost

4. Heating zone selection controls

5. Power / Timer regulating key

6. Keylock control

four

2

1

3

4

5

3

2 1

4 5 6

EN-6

EN-7

How to use

Start cooking

Touch the ON/OFF control for three seconds. After power

on, the buzzer beeps once, all displays show “–” or “– –”,

indicating that the induction hob has entered the state of

standby mode.

Place a suitable pan on the cooking zone that you wish to

use.

• Make sure the bottom of the pan and the surface of the

cooking zone are clean and dry.

Touching the heating zone selection control ,and an

indicator next to the key will flash

Select a heat setting by touching the “-”or “+” control.

•If you don’t choose a heat setting within 1 minute, the

Induction hob will automatically switch off. You will need to

start again at step 1.

•You can modify the heat setting at any time during

cooking.

If the display flashes alternately with the heat setting

This means that:

•you have not placed a pan on the correct cooking zone or,

•the pan you’re using is not suitable for induction cooking or,

•the pan is too small or not properly centered on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.

The display will automatically turn off after 1 minute if no suitable pan is placed on it.

EN-8

Finish cooking

Using the Boost function

Touching the heating zone selection control that you

wish to switch off

Turn the cooking zone off by scrolling down to “0” or

touching “-” and “+” control together. Make sure the

display shows “0”.

Turn the whole cooktop off by touching the ON/OFF

control.

Beware of hot surfaces

H will show which cooking zone is hot to touch. It

will disappear when the surface has cooled down to

a safe temperature. It can also be used as an energy

saving function if you want to heat further pans, use

the hotplate that is still hot.

OR

Activate the boost function

Touching the heating zone selection control.

Touching the boost control , the zone indicator show

“P” and the power reach Max.

EN-9

•The cooking zone returns to its original setting after 5 minutes.

•If the original heat setting equals 0, it will return to 9 after 5 minutes.

Locking the Controls

•You can lock the controls to prevent unintended use (for example children accidentally turning the

cooking zones on).

•When the controls are locked, all the controls except the ON/OFF control are disabled.

To lock the controls

Touch the lock control The timer indicator will show “ Lo“

To unlock the controls

Touch and hold the lock control for a while.

When the hob is in the lock mode, all the controls are disable except the ON/OFF , you can always

turn the induction hob off with the ON/OFF control in an emergency, but you shall unlock the hob first

in the next operation.

Cancel the Boost function

Touching the "Boost" control or the “-” button to cancel

the Boost function, then the cooking zone will revert to

its original setting.

Touching “-” and “+” control together. The cooking zone

switch off and the boost function cancel automatically

OR

EN-10
