Bryant T2-NHP01-A User manual

T2- NHP01- A, T2- NAC01- A

LegacytSeries

Non- Programmable Thermostat

Owner’s Manual

YOU WILL LOVE THIS THERMOSTAT.

This Legacytnon- programmable thermostat is an easy

to use model that provides the most sought- after features

for keeping your home comfortable. And with a slim

profile, it is designed to be as smart – and smart- looking

– as any of the other electronics in your home. Let this

manual show you how easy it is to enjoy the newest ex-

perience in home comfort.

NOTE: Read the entire instruction manual before starting the installation.

TABLE OF CONTENTS

BUTTON IDENTIFICATION 4.................................

ON- SCREEN INDICATORS 6

.....................................

OPERATING THE THERMOSTAT

Setting the temperatures for heating and cooling 8

....................

Using the fan 9..................................................

Using emergency heat (heat pump systems only) 10..................

Installing or replacing the batteries 11...............................

Using the thermostat to turn the heating and cooling system off 14......

Auto changeover 14..............................................

ADVANCED OPTIONS

Advanced options display codes chart 15

............................

Changing from Fahrenheit to Celsius 16............................

Turning on the continuous backlighting 17..........................

Keypad lockout 18...............................................

Unlocking the keypad 19........................................

TABLE OF CONTENTS

WHATIF...

The battery icon is displayed 20

....................................

“Aux heat on” is displayed (heat pump systems only) 20..............

“Em heat” is displayed (heat pump systems only) 20..................

There is a power outage 21........................................

You get a system error message 21.................................

COMMON TERMS AND WHERE TO FIND THEM

Auto changeover 22

..............................................

Auxiliary heat (heat pump systems only) 22.........................

Backlighting 22.................................................

Emergency heat (heat pump systems only) 22........................

Mode 22........................................................

BUTTON IDENTIFICATION

a. FAN Selects whether the fan operates continuously (on) or only when

needed for heating or cooling (auto)

b. MODE Selects whether thermostat is set for heating, cooling, emergency

heat (heat pump system only), auto (heat and cool as needed), or off

c. UP Increases the temperature or adjusts the screen selection up when

setting advanced features

d. DOWN Decreases the temperature or adjusts the screen selection down

when setting advanced features

ON- SCREEN INDICATORS

actual temp

o

heat

aux

heat

fan

auto

fan

cool

set at

ON- SCREEN INDICATORS

1. Fan mode – on or auto

2. System is in auxiliary (supplemental) mode

3. Current temperature

4. Thermostat mode is either off or using emergency heat

5. Fahrenheit

6. Keypad is locked (no padlock means unlocked)

7. Celsius

8. Battery strength indicator

9. Selected cooling set point; “on” indicates system is in cooling mode

10. Second stage of cooling is active

OPERATING THE THERMOSTAT

Setting the temperatures for heating and cooling

Your thermostat is installed with the heating set at 68F and the cooling set at 72F.

You can use these or change them so your home is as warm or as cool as you would

like it to be. These steps will hold the temperature where you set it.

1. To change the heating temperature, press the mode but-

ton on the left until the screen says heat.

2. Press the up or down button located on the right side of

the display until you reach the desired temperature.

3. To change the cooling temperature, press the mode but-

ton on the left until the screen says cool.

4. 4. Press the up or down button located on the right side of the display until

you reach the desired temperature.
