Brinkmann Gas Outdoor Grill User manual

ASSEMBLY INSTRUCTIONS:

8 M6 X 12 mm Bolts (Black)

17 M6 X 12 mm Bolts (Silver)

4 M6 X 30 mm Bolts (Silver)

2 M5 X 12 mm Bolts (Black)

2 M4 X 12 mm Bolts (Black)

8 M4 X 12 mm Bolts (SIlver)

1 Shoulder Bolt (Black)

Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before

you begin the installation process.

PARTS BAG CONTAINS:

Qty. Qty.

1 Locking Nut

2 M6 Washers

3 Hinge Pins

3 Cotter Pins

3 AA/1.5V Alkaline Batteries

1 Caster Tightening Pin

M6 X 12 mm Bolts (Black)

Hinge Pins (Short) M6 Washers

Caster Tightening Pin

M4 X 12 mm Bolts (SIlver)

Cotter Pins

M6 X 30 mm Bolt (Silver)

Shoulder Bolt Locking Nut

M5 X 12 mm Bolt (Black)

AA/1.5V Alkaline Batteries

M4 X 12 mm Bolts (Black)

M6 X 12 mm Bolts (Silver)

READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY

BEFORE ASSEMBLING OR OPERATING YOUR GRILL.

WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.

The following tools are required to assemble this Brinkmann Heavy-Duty Gas Grill:

• Screwdriver

• Hex Nut Wrench

1 Grease Tray

1 Cart Base

1 Lower Cart Brace

1 Door Stopper

1 Tank Holder

1 Tank Gauge Bracket With Spring

1 Tank Gauge Needle Assembly

1 Tank Heat Shield

1 Wind Deector

2 Locking Swivel Casters

2 Swivel Casters

1 Sear Burner Grease Tray

1 Grease Cup

PARTS LIST:

1 Grill Body Assembly

1 Left Side Table Assembly

1 Right Side Table Assembly

1 Warming Rack

3 Cooking Grills

5 Heat Tents

1 Sear Burner Bezel

1 Sear Burner Knob

1 Sear Burner Grate

1 Left Panel

1 Right Panel

1 Left Door

1 Upper Cart Brace

1 Right Door

1 Back Panel

This grill is designed with Dual Fuel Valves to easily

convert from LP (propane) gas to natural gas.

A Brinkmann conversion kit must be purchased

and installed for use with natural gas.

To see trouble shooting or assembly videos, visit us at:

(Proof of purchase will be required.)

Inspect contents of the box to ensure all parts are included and undamaged.
