Briggs & Stratton 1971 Setup guide

Illustrated Parts List

Las Partes ilustradas Listan

IPL No. 193449A

Revision 3 (08/25/2005)

Questions? Help is just a moment away!

Preguntas? La ayuda es justa un momento lejos!

Call: Generator Helpline - 1-800-743-4115 M-F 8-5 CT

Llamada: Generador Helpline - 1-800-743-4115 M-F 8-5 CT

web: www.briggsandtratton.com

01971

(5250W)

BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC

JEFFERSON,WISCONSIN, U.S.A.

5250 Watt Portable Generators

EXPLODED VIEW - MAIN UNIT

5250 Watt Portable Generators

PARTS LIST - MAIN UNIT

Item Part # Description

1 B194759GS CRADLE

2 194150GS KIT,Vibration Mount, 45°

4 190220GS HOUSING, Engine Adapter

5 NSP ASSY,Alternator (see page 4)

6 194151GS KIT, Hardware Mounting Adapter

8 96796GS WASHER

9 22695GS HOUSING, Receptacle

10 * SBHCS, 3/8-16 x 1.0 Lg.

11 47480GS HHCS, 5/16-24 x 7

12 68759GS OUTLET, 120V, 20A

13 84198GS CAP, Circuit Breaker

16 * NUT, Pal, 3/16

17 43437GS OUTLET, 120/240V, 30A

19 * NUT, Pal, 5/32

20 B4986GS DECAL, Ground, Green

21 194153GS KIT,Vibration Mount

22 * PPPHS, 3.5 x 18mm

23 194154GS KIT, Grounding Hardware

25 191427GS ADAPTER PANEL

26 * SCREW, M5 - 2.24 x 50

30 191190GS CAP

31 191436GS DECAL, Hot Muffler

32 74908GS TAPTITE, M5-0.8 x 10

33 93857GS BAR, Retaining

34 194152GS ASSY, Panel Control

35 194265GS KIT, Fuel Hose w/ Clamps

Item Part # Description

37 75207GS BREAKER, Circuit, 20A

40 194398GS KIT, Fuel Tank Hardware

41 192980GS KIT,Valve, Fuel

44 194217GS ASSY,Tank, Fuel (Includes Items 41,

50, 51 & 52)

45 90878GS CAP, Fuel

48 186790EGS WIRE, Ground

50 188333GS DECAL, Gas Fill

51 194799GS DECAL, Danger

52 189235GS DECAL, Start Instructions

54 194448GS KIT, Insulation w/ Clip

55 191435GS DECAL, Fuel Shut-off

60 193452GS SHIELD, Heat

900 § ENGINE

Parts Not Illustrated

193449GS MANUAL, Owners

MS6669 MANUAL, Engine

BB3061BGS BOTTLE, Oil

188971GS CORD, Ext.

193552GS KIT, Decal Service

189208GS FUEL STABILIZER

* - Items without part numbers are common fasteners and

are available at local hardware stores.

§ - Contact Engine Manufacturer

5250 Watt Portable Generators

EXPLODED VIEW AND PARTS LIST - ALTERNATOR

Item Part # Description

1 186059GS ADAPTER, Mounting,Alternator

2 193623GS ROTOR

3 191042AGS STATOR

4 186060GS RBC, with O-Ring (p/n 189197GS)

5 86308CGS SCREW

6 91825GS ASSY, Holder, Rectifier/Brush

7 66849GS SCREW

8 22694GS RECEPTACLE, 6 pin

9 81917GS PIN, Roll

10 193428AGS ASSY,Wire, Ground

11 74908GS SCREW
