Brandt WFK1018A User manual

GUIDE D’INSTALLATION

INSTRUCTIONS FOR USE

MANUAL DE INSTALAÇÃO & UTILIZAÇÃO DA MÁQUINA DE LAVAR ROUPA

Lave-Linge

Washing machine

Máquina de lavar roupa

WARNINGS

SPECIFICATIONS

INSTALLATION AND ASSEMBLY

USING THE APPLIANCE.

PRACTICAL TIPS

MAINTENANCE

AND CLEANING

SAFETY

AND TROUBLESHOOTING

ENVIRONMENTAL

WARNINGS

washing machine

contents

AVERTISSEMENTS

SPÉCIFICATIONS

INSTALLATION ET MONTAGE

UTILISATION DE L’APPAREIL

ET CONSEILS PRATIQUES

MAINTENANCE

ET ENTRETIEN DE L’APPAREIL

SÉCURITÉ

ET RÉSOLUTION DE PROBLÈMES

AVERTISSEMENTS SUR

L’ENVIRONNEMENT

lave-linge

sommaire

Dear Costumer,

You have just acquired a BRANDT washing machine and we would like to thank you.

We have invested all our dedication and know-how in this appliance so that it would

best meet your needs. With innovation and performance, we designed it to be always

easy to use.

In the BRANDT product range, you will also find a wide choise of ovens, microwaves,

cooking hobs, ventilation hoods, cookers, dishwashers, driers, fridges and freezers,

that you can coordinate with your new BRANDT washing machine.

Visit our website www.brandt.com where you will find all of our products, as well as

useful and complementary information.

BRANDT

As part of our commitment to constantly improving our products, we reserve the right

to make changes to them based on technical advances to their technical and functional

features and appearance.

Warning:

Before installing and using your appliance, please carefully read this

Guide to Installation and Use, which will allow you to quickly familiarise

youself with its operation.

www.brandt.com

warnings

This washing machine comes with a

manual that includes operating, maintenance

and installation instructions. Please read all

the instructions before using the washing

machine.

Do not wash items that have previously

been cleaned, washed, soaked or treated

with petrol, solvents for dry cleaning, other

inflammable substances or explosives, as

they produce fumes that could catch fire or

explode.

Do not add petrol, solvents for dry cleaning

or other inflammable or explosive substances

to the wash water as they produce fumes

that could catch fire or explode.

Do not repair or replace any part of the

washing machine or try to carry out any type

of servicing unless it is recommended in the

maintenance instructions in the manual.

Do not climb onto the machine or stand

on the open hatch door.

Do NOT use an extension lead or adaptor

to connect your washing machine to the

mains supply.

The machine should only be used for the

purpose it is designed for.

Follow the washing instructions

recommended by the manufacturer of the

garment to be washed.

Do not turn your washing machine on until

you are sure that:

• It has been installed in accordance with

the installation instructions.

• All the water, drainage, mains electricity and

earth connections meet the local regulations

and/or other applicable regulations.

To avoid the risk of fire, electrical shocks, injury or damage when using your washing

machine, please take the following precautions:

thanks for placing your trust in us

Washing in less time.

• The wash programmes do not last as

long giving you more free time.

Time delay.

• To take advantage of cheap electricity

rates.

WITH INNOVATION ALWAYS IN MIND

LCD screens.

• Which allows you to have constant

information about the wash programme

and its duration.

Detergent dispenser designed to offer

maximum convenience.

• Easy to remove for cleaning.

• Possibility of using liquid detergent.

Our new range of washing machines has been designed to make life more convenient for you:

WITH YOUR CONVENIENCE ALWAYS IN MIND

Large hatch.

Maximum opening.

• Designed higher than the normal axis and

with the drum tilted to achieve maximum

ergonomics.

• Its maximum opening makes it much

easier to put clothes in.

Easy-access filter.

• And simple maintenance.

WITH SAVINGS ALWAYS IN MIND

8 kg capacity.

• Which allows you to do less washes and

make savings.

washing machine

Water inlet hose

specifications

Drain hose

Work top

Power

cord

Control

panel

Detergent

dispenser

Stainless

steel

drum Filter

Kickplate

Hatch

Rear plugs

Spanner

Drain pipe bender

ACCESSORIES LOCATED

INSIDE THE DRUM

Levelling

feet

washing machine

a There are 3 blocking screws on the back

of the washing machine.

b Use the spanner supplied to loosen and

completely remove the 3 screws together

with the metal washer and the black

rubber and plastic tubes that make up

the blocking system.

c Fit the 3 plastic plugs supplied in the

holes you removed the screws from.

installation and assembly

Do not throw the blocking screws away.

You may need to move the washing

machine at a later date.

Important

aRemove the base, corner protectors and

top cover.

1UNPACKING AND

UNBLOCKING THE

WASHING MACHINE

UNBLOCKING

UNPACKING

The water supply hose is inside the drum:

aConnect the bent end of the hose to the

threaded inlet of the electrovalve located

at the rear of the washing machine.

bConnect the other end of the hose to the

water intake. Then securely tighten the

connection nut.

It is important that the drain hose bend

is correctly fastened to the outlet, to

prevent any risk of it becoming

detached and causing flooding.

If your washing machine has a hot

water intake, connect the hose with

the red threaded end to the hot water

tap, and to the electrovalve with the

red filter.

The washing machine must be

connected to the mains water supply,

using the new supply hoses supplied

with the appliance. Do not use water

supply hoses that have been used

before. For your washing machine to

work properly, the mains water

pressure must be between 0.05 and

1MPa (0.05 and 10 Kgr/cm2).

aIt is recommended that you have a fixed

drainage outlet 50 tom 70 cm from the

floor.

Avoid the drain hose being too tight,

kinked or restricted. Use the bend

supplied.

Important

CONNECTION TO THE MAINS WATER SUPPLY AND

DRAINAGE installation and assembly

CONNECTION TO THE

MAINS WATER SUPPLY

DRAINAGE

CONNECTION

Important

LEVELLING THE WASHING MACHINE AND CONNECTING

IT TO THE MAINS ELECTRICITY SUPPLY

installation and assembly

Consult the specifications plate located on the

hatch door of the washing machine before

making the electrical connections. Ensure that

the voltage reaching the plug is the same as

that on the plate.

Do not remove the specifications plate. The

information on it is important.

ELECTRICAL CONNECTION

LEVELLING

It is very important to correctly earth the

washing machine.

The electrical installation, plug, socket,

fuses or automatic switch and counter

must be correctly dimensioned for the

maximum power indicated on the

specifications plate.

Do not plug the washing machine plug into

the socket with wet or damp hands.

To remove the power cord, pull on the body

of the plug.

If the power cord is damaged, it must be

replaced by a cord or special unit provided

by either the manufacturer or your after-

sales service.

With built-in washing machines, the plug

must be accessible after installation.

aFirst of all, we recommend that

you fix and level the rear feet. When

they are properly fixed, secure the

metal locknut tightly to the top

part.

bPut the washing machine into its

niche. Dampen the floor to help

you move the machine into its final

position.

cFinally level and secure the front

feet in the same way as you

levelled the rear feet.

Keep the spanner supplied, in case

you need it again.

Important

When your washing machine has been

correctly installed, we recommend that you

pre-clean the machine.

This is to check that the installation, the

connections and the drainage are all correct,

and to thoroughly clean the inside of the

washing machine before any wash

programmes are run (see the operating

instructions on the following pages).

a Press ON/OFF button.

b Select the normal programme at 60ºC.

c Press the start/pause button.

PRE-CLEANING
