System Setup
Disc Menu
This function allows youto choose the menulanguage
stored on the disc.
The default is English.
Note: the disc menulanguages depend on the
information available on thedisc.
Parental:
Enter this option toset the parental controllevel to some
unsuitable disc scenes beingwatched by the children.
Optional parental control levels:KID SAFE, G, PG,PG 13, PGR,
R, Nc17, ADULT.
The default of thisoption is ADULT.
Default:
Select this item andpress OK button toreset
all settings to theoriginal factory settings.
--Preference Page--
Preferred Menu Language
Audio ENG
Subtitle ENG
Disc Menu ENG
Parental
Default
English
Swedish
Finnish
--Preference Page--
Set Parental Control
Audio ENG
Subtitle ENG
Disc Menu ENG
Paretal
Default
1 KID SAFE
2 G
3 PG
4 PG 13
5 PGR
6 R
7 NC 17
8 ADULT
--Preference Page--
Load Factory Setting
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default Reset
The unit utilizeslong-life Li polymer battery for portable power supply.The battery has
no "Memory Effect"and thus can be recharged safely regardless of whether the battery
is fully orpartially discharged. It's enough to recharge no longer than6H each time, fully
recharged battery canlast about 2 hours.
The battery canbe only recharged when turning power to OFF state,and keep continuous
power supply,the red light will be on, and the light will turn yellow when it's fully charged.
1. The normalworking temperature is: 0 ~45 ;
2. Alwaysunplug AC/DC power supply for the unit whennot in use;
3. Heat willcreate during playing, it's normal, while avoid long timeplaying and
unattended;
4. Avoidhaving the unit collide with any objects, and place away from all possible heat
sources or dampareas.
°C °C
The specification and rechargeable battery use
Using and Maintaining Rechargeable Battery
Specification
Compatible disc:
Signal system: PAL/NTSC
Panel size: 7inch
Picture resolution: 480X234(RGB)
Frequency response: 20Hz to 20 kHz
Video output: 1Vp-p/75 Ohm, unbalanced
Audio output:1.4Vrms/10kOhm
Audio S/N:Better than 80 dB
Dynamic range: Betterthan 85 dB
USB: support USB1.1
Laser: Semiconductor Laser, WaveLength: 650 nm/795 nm
Power source: DC9-12V
Power consumption: 10W
Operating temperature: 5~40°C
Weight: 0.753kg
Dimensions (W xD x H): 206x 158 x 41mm
Battery Type:Li Polymer
DVD+R/RW, DVD-R/RW, CD-DA,CD-R/RW, MP3, JPEG,VCD,
SVCD,XVID, .MPEG4
Precautions related toBattery Recharge
17
Rechargeable battery use
16
