Bose®FreeStyle™

Earbuds

Owner’s Guide

2 - English

Important Safety Information

prior written permission.

Please read this owner’s guide carefully and save it for future reference.

CAUTIONS

• Sounds that you rely on as reminders or warnings may have an unfamiliar char-

acter when using headsets. Be aware of how these sounds may vary in character

so you can recognize them as needed.

• Do not drop, sit on, or allow the headset to be immersed in water.

WARNINGS

• Contains small parts which may be a choking hazard. Not suitable for

children under age 3.

• This product contains magnetic material. Contact your physician if

you have questions on whether this might affect the operation of your

implantable medical device.

• Long-term exposure to loud music may cause hearing damage. It is best to avoid

high volume levels when using headset, especially for extended periods.

• Use caution when using your headset while operating a vehicle or engaging in

any activity that requires your full attention. Check and follow local laws regard-

ing headset use. Some jurisdictions impose specic limitations, such as single

earpiece conguration, on the use of such products while driving.

Limited Warranty

Your Bose® headphones are covered by a limited warranty. Details of the limited

warranty are provided on the product registration card that is included in the car-

ton. Please refer to the card for instructions on how to register. Failure to register

will not affect your limited warranty rights.

This product conforms to all applicable EU Directive requirements. The

complete Declaration of Conformity can be found at www.Bose.com/

compliance.

Names and Contents of Toxic or Hazardous Substances or Elements

Toxic or Hazardous Substances and Elements

Part Name Lead (Pb) Mercury (Hg) Cadmium (Cd)

Hexavalent

(CR(VI))

Polybrominated Biphenyl

(PBB)

Polybrominated

diphenylether (PBDE)

Metal parts X 0 0 0 0 0

Plastic parts 0 0 0 0 0 0

Speakers X 0 0 0 0 0

Cables X 0 0 0 0 0

O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit require-

ment in SJ/T 11363-2006.

X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the

limit requirement in SJ/T 11363-2006.

iPad, iPhone, iPod, iPod classic, iPod nano, iPod shufﬂe and iPod touch are trademarks of Apple Inc.,

registered in the U.S. and other countries.

“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been

designed to connect speciﬁcally to iPod, iPhone, or iPad, respectively, and has been certiﬁed by the

developer to meet Apple performance standards. Apple is not responsible for the operation of this device

or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod,

iPhone, or iPad may affect wireless performance.

4 - English

Contents

Please complete and retain for your records:

The serial and model number can be found on the warranty card.

Serial number __________________________________________________________________

Model number _________________________________________________________________

Purchase date__________________________________________________________________

We suggest you keep your receipt with this owner’s guide.

Welcome.............................................................................................................. 5

Carton contents................................................................................................. 5

Connecting to your iPhone, iPod, or iPad...................................................... 6

Using the earbuds with your iPhone, iPod, or iPad ..................................... 6

For use with ................................................................................................ 6

Earbud controls .......................................................................................... 6

Basic functions ........................................................................................... 7

Media playback functions......................................................................... 7

Importance of proper ﬁt ................................................................................... 8

Fitting the headphones to your ear ........................................................ 8

Changing eartips ........................................................................................ 9

Adjusting for comfort and stability................................................................ 9

Using the adjustment slider .................................................................... 9

Using the clothing clip .............................................................................. 9

Troubleshooting ................................................................................................ 10

Cleaning............................................................................................................... 11

Using the earbuds

English - 5

Welcome

Thank you for purchasing the Bose® FreeStyle™ earbuds for use with select

iPhone, iPod and iPad models. The Bose FreeStyle earbuds offers a combination

of lifelike audio performance and comfortable t not available from most

conventional headsets.

Carton contents

Volume Up

Answer/End

button

Volume Down

Clothing clip Adjustment slider

Carrying case

StayHear® tips

Large

(black)

Medium

(gray)

Small

(white)

left right

Microphone

(back of button)

left right

Note: The earbuds comes with medium StayHear®tips attached.

Using the earbuds

6 - English

Connecting to your iPhone, iPod, or iPad

You can connect the earbuds to the standard 3.5 mm headphone jack on your

iPhone, iPod, or iPad.

Using the earbuds with your iPhone, iPod,

or iPad

The Bose® FreeStyle™ earbuds include a small in-line remote with an integrated

microphone and easy to access Answer/End and volume control buttons.

For use with

The remote and mic are supported only by iPhone 3GS or later, iPad, iPod touch

(2nd generation or later), iPod classic (120GB, 160GB), and iPod nano (4th gen-

eration or later). The remote is supported by iPod shufe (3rd generation or later).

Audio is supported by all iPad and iPod models.

Note: Full controls may not be available for some iPhone, iPod, or iPad models.

Note: For information on using your earbuds with other devices, refer to

http://global.Bose.com

Earbud controls

Volume up

Answer/End

Volume down

Using the earbuds

English - 7

Basic functions

Increase volume Press and release the + button.

Decrease volume Press and release the – button.

Answer a call When you receive an incoming call,

press and release the Answer/End

button to answer.

End a call Press and release the Answer/End

button.

Decline an incoming call Press and hold the Answer/End button

for about two seconds, then release.

Switch to an incoming or on-hold call

and put the current call on hold While on a call, press and release the

Answer/End button once. Press and

release again to switch back to the rst

call.

Switch to an incoming or on-hold call

and end the current call While on a call, press and hold the

Answer/End button for about two

seconds, then release.

Use Voice Control Press and hold the Answer/End button.

See iPhone User Guide for compat-

ibility and usage information about this

feature.

Media playback functions

Play or pause a song or video Press and release the Answer/End

button.

Skip to the next song or chapter Press and release the Answer/End

button twice quickly.

Fast forward Press and release the Answer/End

button twice quickly and hold the

second press.

Go to the previous song or chapter Press and release the Answer/End

button three times quickly.

Rewind Press and release the Answer/End

button three times quickly and hold the

third press.

Using the earbuds

8 - English

Importance of proper ﬁt

When you wear the earbuds properly, they provide the comfort and clarity you

expect from Bose.

Fitting the headphones to your ear

The headphone earpiece has a soft StayHear® tip attached, allowing it to rest

comfortably in the bowl of your ear. The wing part of the tip ts just under your ear

ridge.

Note: Each tip is marked with a either an L or an R to indicate

which earpiece it is for. Be sure to attach the left StayHear®tip to

the left earpiece and the right StayHear®tip to the right earpiece.

To determine if the tip is the right size:

1. Insert the earpiece into the canal just enough for the headphone to rest lightly

against your ear.

2. Tilt the headphone back and press the tip wing under the ear ridge until it is

secure.

The tips should t comfortably yet securely in the bowl of the ear.

Using the earbuds

English - 9

Changing eartips

Select the type and size of eartip that provides you with the best comfort and t.

1. Gently peel the edges of the attached tip away from the earpiece, using care

not to tear the tip.

CAUTION: To prevent damage, do not pull on the StayHear®tip wing.

2. Position the opening of the new tip over the nozzle and the small slot over the

nozzle hook.

Note: Each tip is marked with a either an L or an R to indicate which earpiece it is for.

Be sure to attach the left StayHear®tip to the left earpiece and the right StayHear®tip

to the right earpiece.

3. Ease the base of the tip down around the base of the earpiece until the tip

feels secured.

Adjusting for comfort and stability

There are several ways you can adjust your earbuds to provide additional comfort

and stability. Using the adjustment slider and clothing clip you can customize how

you wear your earbuds.

Using the adjustment slider

Move the adjustment slider up or down to reduce or increase

the amount of loose cord between the left and right earpiece.

Finding the right position for the slider can help optimize the

placement of the Answer/End button and integrated micro-

phone.

Using the clothing clip

Use the clothing clip to fasten the

cable to your clothing, for conve-

nience, stability, and to help

manage the cable. This can be

helpful during high-movement

activities or when using the ear-

buds in a single earpiece congura-

tion.

Using the earbuds

10 - English

Troubleshooting

If you experience any trouble using your earbuds, try the following troubleshooting

instructions. If you still need help, contact Bose customer support.

Problem What to do

No audio/Intermittent • Make sure that the headphone plug is

securely connected to the headphone

jack.

• Try another audio device.

Excessive bass • Turn off any audio enhancement

features on the audio source.

Microphone is not picking up sound • Make sure that the headphone plug is

securely connected to the headphone

jack.

• Make sure the microphone is not being

blocked or covered.

The microphone is located on the back of

the Answer/End button. (You may notice

the small opening for the microphone.)

Phone not responding to button

presses • Make sure that the headphone plug is

securely connected to the headphone

jack.

• For multi-press functions: Vary speed of

presses.

iPhone, iPod or iPad not responding

to remote • Full controls may not be available for

some iPhone, iPod and iPad models.

Eartips falling off • Make sure the eartips are securely at-

tached to the earpiece and nozzle hook.

Lost eartip • Visit owners.Bose.com for replacement

tips.

Sound is mufed from earpiece • Make sure eartips and earbud nozzles

are clear of any debris or wax build-up.

• Unplug the earbuds from the audio

source, then plug back in making sure

they are securely connected.

• Try another audio device.

Other manuals for Freestyle Speaker System

Table of contents

Languages:

Popular Headset manuals by other brands

Sena

Sena SMH10 quick start guide

IASUS

IASUS Stealth IA-NT4-BASIC-BT manual

Sennheiser

Sennheiser EPOS ADAPT 230 user guide

Doro

Doro Flexus HS2005 user guide

GE 98971 datasheet

Hama

Hama 00184070 quick start guide

Plantronics

Plantronics Blackwire 3200 Series user guide

Blue Tiger

Blue Tiger Advantage PLUS user manual

Jawbone

Jawbone Icon user manual

Jabra

Jabra FR 20 user guide

Roxcore

Roxcore Flow A+ manual

Turtle Beach

Turtle Beach XP 510 user guide

Philips

Philips SHB6101 Specification sheet

Jabra

Jabra PRO 9460 Duo datasheet

HyperX

HyperX HyperX Cloud Flight manual

Jabra

Jabra Steel quick start guide

HyperX

HyperX cloud ii quick start guide

Southwing

Southwing SA505 Specifications
