Bodyworx J1530CA User manual

Motorized Treadmill

Owner’s Manual

Retain this owner’s manual for future reference

Read and follow all instructions in this owner’s manual

Version A

Model No: J1530CA

BODY WORX

INTRODUCTION

Computer Handle pulse

Hand bar

Safety key

Upright post

Side rail

Rear cover

Motor cover

Bottom frame

Main frame

Congratulations on choosing this treadmill.

You have taken the first step to a healthier and more rewarding lifestyle.

This treadmill is especially designed to give you reliable performance and enjoyable

workout in the comforts of your home. Please find below the features and benefits of this

treadmill.

Incline can meet your different requirement, jogging, running, walking.

Low impact design with cushions, and PU roller so that your joints are protected

against possible injury.

Foldable design for convenient storage.

Mobility wheels for easy moving and relocation.

Hand contact heart-rate system to monitor cardio performance.

Emergency safety key for quick motor shut-off.

TECHNOLOGY DATA

Voltage AC-220V 50Hz

Max weight 115Kg

Folding: 926*756*1500mm

Dimension Unfolding: 1810*756*1290mm

Running belt 1300*420mm

Horsepower 900W

Speed 1.0 16.0Km/h

Incline 0-15%

Remark: Our company retain the priority of revision not to advise in advance.

KEY FEATURES

CAUTION:

Before beginning any exercise program always consult your physician. If you

experience chest pains, nausea, dizziness or shortness of breath, stop exercising

and consult your physician before continuing.

When using an electrical product, basic precautions should always be followed.

Read all instructions before using this treadmill.

GROUNDING INSTRUCTIONS

This product must be grounded! If treadmill should malfunction or breakdown, grounding

provides a path of least resistance for electrical current to reduce the risk of electrical

shock. The product is equipped with a cord having an equipment-grounding conductor and

a grounding plug. This plug must be plugged into an appropriate outlet that is properly

installed and grounded in accordance with local codes and ordinances.

DANGER! Improper connection of the equipment-grounding conductor can result in a risk

of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to

whether the product is properly grounded. Do not modify the plug provided with the

product- if it will not fit the outlet; have a proper outlet installed by a qualified electrician.

ELECTRICAL SAFETY

To reduce the risk of burns, fire, electrical shock, or injury to persons, take the following

precautions.

When plugged in, do not leave the treadmill unattended at any time. Unplug the

treadmill from the power source when it is not in use.

Do not use the treadmill if the unit is wet or the plug or cable is damaged or the

treadmill is not working properly. Do not use damaged or defective equipment.

Keep the power cable and plug away from heated surfaces.

Never place the power cord under carpeting or place any object on top of the power

cord.

Use only the power cord provided with this treadmill

Please turn the switch to the “off” position before shut down power supply, then remove

the plug from the outlet.

This exercise equipment is designed and built for optimum safety for the home use.

However, certain precautions always apply whenever you operate any exercise

equipment. Be sure to read the entire manual before assembly and operation of this

machine. Also, please note the following safety precautions.

IMPORTANT SAFETY PRECAUTIONS

WARNING!

Connect this unit to a properly grounded outlet only. Please using special circuit

with special power supply, plug with power supply must be connected with earth.

MECHANICAL SAFETY

Before you start to exercise, make sure the unit functions correctly. To maintain the

safety level of the exercise equipment does not use a faulty device.

Replace defective components immediately and/or keep the equipment out of use until

repair.

Inspect the equipment prior to exercising to ensure that all nuts and bolts are fully

tightened before each use.

Do not use attachments not recommended by the manufacturer.

Never drop or insert any object into any opening.

Never activate the speed when someone is standing on the treadmill.

APPROPRIATE ATTIRE

Always wear appropriate clothing. Do not wear clothing that might catch on any part of

this treadmill

Always wear non-slippery shoes while working with the treadmill. Do not wear shoes

with heels or leather soles. Check the soles of your shoes and remove any dirt and

embedded stones.

CHILDREN AND PETS

Most exercise equipment is not recommended for small children. Children should not

use the equipment unless they are under adult supervision. To ensure safety, keep

young children off the treadmill at all times.

Exercise equipment has many moving parts. In the interest of safety, keep others

(especially children and pets) at a safe distance while you exe

CAUTION!

Stop your workout immediately if you feel any plainer abnormal symptoms and

consult your physician. Read this manual before operating this treadmill.

Step 1: Take the machine from the

package, put on the level floor; put the

upright into the bottom frame like picture

Attention: when insert the right upright

post, should connect the signal wires well

between upright post and bottom frame.

Step 2: Use 10pcs screws (right and left

each 5pcs) M8X15 fix the upright post

Attention: fix the front screws well on the

upright, the fix the other side screws.

Step 3: Use 6pcs (our side upright right

and left 3pcs) ST3*10 fix the cover of

upright on the bottom frame.

Step4: Take the computer from package;

connect well the signal wire between

computer and upright

Step5: Insert the back of computer’s U

clamp into the upright post, right and

left each 3pcs M8*15 screws fix the

upright post and computer, like

pictures

Step6: Like the pictures, fix all of the

screws, finish the assembly.

ASSEMBLY INSTRUCTIONS

PLACEMENT IN YOUR HOME

To make exercise a desirable daily activity for you, the treadmill should be placed in a

comfortable and attractive setting. This treadmill is designed to use minimal floor space

and to go nicely in your home.

- Do not place the treadmill outdoors.

- Do not place the treadmill near water or in high moisture content environment.

- Made sure power cord is no tin the path of heavy traffic.

- If your room is carpeted, check the clearance to make sure there is enough space

between the carpet fiber and the treadmill deck. If you are uncertain, it is best to place

mat beneath your treadmill.

- Locate the treadmill at least 4 feet from walls or furniture.

- Allow the safety area of 2m x1m behind the treadmill so that you can easily get on and

off the treadmill without getting trapped during an emergency.

Occasionally after extended use you will find a black dust below your treadmill. This is

normal wear and does not mean there is anything wrong with your treadmill. This dust can

be easily removed with a vacuum cleaner. If you wish to prevent this dust from getting on

your floor or carpet, place a mat beneath your treadmill.

LEVELING THE BASE

It is important that you place the treadmill on a firm level surface.

Check the treadmill to ensure the frame is level once you have moved the treadmill into

the position of your choice.

SETTING UP YOUR TREADMILL

Owner’s M anual 7

CAUTION!

Make sure the running deck is level to the ground. If the deck is positioned on

uneven surface it would cause premature damage to the electronic system.

TURN POWER ON

The On/Off switch for the treadmill is located next to the power supply cord at the back of

the motor cover. Flip this switch to the “ON” position.

SAFETY TETHER KEY AND CLIP

The safety key is designed to cut the main power to the treadmill should your fall.

Therefore, the safety key is designed to bring the treadmill to an immediate stop. At high

speeds, it may be uncomfortable and somewhat dangerous to come to a complete stop

immediately. So, use the safety key as emergency top only. To bring the treadmill to a

complete stop safely and comfortably, use the red stop button.

Your treadmill will not start unless the safety key is properly inserted into the key holder in

the middle of the console. The other end of the safety key should be securely clipped to

your clothing so that in the case that you fall, you will pull the safety key from the console,

which will stop the treadmill immediately to minimize injury. For your safety, never use the

treadmill without securing the safety key clipped to your clothing. Pull on the safety key clip

to make turn it will not come off your clothing.

GETTING ON AND OFF THE TREADMILL

Handle with care when getting on or off the treadmill. Try to use the handlebars while

getting on or off. While you are preparing to use the treadmill, do not stand on the running

belt. Straddle the running belt by placing your feet on both side rails of the treadmill deck.

Place your foot on the belt only after the belt has begun to move at a consistent slow

speed.

During exercise, keep your body and head facing forward at all times. Never attempt to

turn around on the treadmill when the running belt is still moving. When you have finished

exercising, stop the treadmill by pressing the red stop button. Wait until the treadmill

comes to a complete stop before attempting to get off the treadmill.

GETTING STARTED

Owner’s Manual 8

WARNING!

Never use this treadmill without first securing the safety tether clip to our clothing.

CAUTION!

For your safety, step onto the belt when the speed is no more than 3km/h.

FOLDING THE TREADMILL

1. Before folding the body of the treadmill, must cut off the power.

2. Check treadmill’s incline if is the original place

3. Uplift the base deck will parallel to the upright, pedal will pop-up by itself

4. Check the iron sheet before the pedal, if it to the right place(put into the hole),like the

pictures.

UNFOLDING THE TREADMILL

1. Unfolding the treadmill, should choose the place to the power 1m and the place

should smoothness

2. Unfolding the treadmill, first the hands should take hold of the end of the frame, using

foot let the pedal tilt, hands push down the big frame, when the big frame down 1m to the

land, people should leave off the treadmill 1m until it unfold completely.

MOVING THE TREADMILL

This treadmill is easy to move around safety.

To move the treadmill

A Switch off the power

B Unplug the power cord

C Moving the treadmill by using the PU transportation Wheel

Sure the upper point, could use one hand take hold of the end of the big frame, the other

hand take hold of the same sides hand bar, incline 30°~40°,could move the treadmill

slowly.

HANDLING YOUR TREADMILL

Cylinder

pedal

?Windows and button instruction:

1.One big LCD window display the following function:

Distance, time, speed, calories, pulse, circle, body fat date, ring course

2.Fuction button:stop,program,speed+,speed-,incline+,incline-,model,start,speed fast

button 2,4,6,8,10,12KM/H,incline fast button:0,3,6,9,12,15%

A. Program button: under the stop, play the model button could circle choose

program: manual program-P01-P02-P03-P04-P05-P06-P07-P08-P09 –body model:

B. Model button: under the manual, play the model button into time count down

adjust-calories count down adjust-distance count down adjust-usual model-time

count down—

C. Start: under the stop, play it will start the motor.

D. Stop/enter button, when the motor running, play stop, the motor will stop

E. Speed+: under setting, put it will add the setting number, under motor running, play

it will add the speed

F. Speed-:under setting, put it will reduce the setting number, under motor running,

play it will down the speed.

G. Incline+: under motor running, play it will add the incline.

H. Incline-:under motor running, play it will reduce the incline.

I. Speed fast button: 2,4,6,8,10,12KM/H.under motor running, play it will adjust the

speed to the number display.

J. Speed fast button: 0,3,6,9,12,15% under motor running, play it will adjust the

incline to the number display.

?Program/start instruction

1 Program instruction

One manual program, it include: usual model. time count down, calories count

OPERATING THE CONSOLE

Other manuals for J1530CA

Other Bodyworx Treadmill manuals

Bodyworx

Bodyworx JT175 User manual

Bodyworx

Bodyworx J1621EA User manual

Bodyworx

Bodyworx J1530CA User manual

Bodyworx

Bodyworx JTC200 User manual

Bodyworx

Bodyworx JX150HR User manual

Bodyworx

Bodyworx JX540 User manual

Bodyworx

Bodyworx CHALLENGER 400 User manual

Bodyworx

Bodyworx JX150 User manual

Bodyworx

Bodyworx JX125 User manual

Bodyworx

Bodyworx JX325 User manual

Bodyworx

Bodyworx J1600EA User manual

Bodyworx

Bodyworx J1651EA User manual

Bodyworx

Bodyworx COLORADO175 User manual

Bodyworx

Bodyworx JX324 User manual

Bodyworx

Bodyworx JX735 User manual

Bodyworx

Bodyworx Colorado 300 User manual

Bodyworx

Bodyworx JX335 User manual

Bodyworx

Bodyworx JX200 User manual

Bodyworx

Bodyworx SPORT3050 User manual

Bodyworx

Bodyworx JT175 User manual

Bodyworx

Bodyworx JTM2000 User manual

Bodyworx

Bodyworx JI2040 User manual

Bodyworx

Bodyworx JX300 User manual

Bodyworx

Bodyworx TM3000 User manual

Popular Treadmill manuals by other brands

Treadly

Treadly TREADLY 2 user manual

HEALTH ONE

HEALTH ONE Walk Ro user manual

NordicTrack

NordicTrack NTL12941 user manual

NordicTrack

NordicTrack T7.5 S user manual

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 user manual

Merax

Merax MS282992 manual

FYTTER

FYTTER RU-2SX manual

Precor

Precor 903 owner's manual

FitLogic

FitLogic freewill d225 owner's manual

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB instruction manual

Horizon Fitness

Horizon Fitness Adventure 5 Plus Service manual

Stamia

Stamia InMotion II owner's manual

Smooth Fitness

Smooth Fitness EVO 3i user manual

NordicTrack

NordicTrack NETL81810.0 user manual

Schwinn

Schwinn 830/Journey 8.0 Assembly manual / owner's manual

Keys Fitness

Keys Fitness HealthTrainer HT-740T owner's manual

Spirit

Spirit XT8 Service manual

NordicTrack

NordicTrack T 14.0 Treadmill Manuel de l'utilisateur
