Congratulations on purchasing the A4 FLEXFLO variable speed Peristaltic

Metering Pump.

Your FLEXFLO A4 pump is pre-configured for the tubing that shipped with your

metering pump. The tubing assembly has an Identification number printed for

easy re-order.

Please Note: Your new pump has been pressure tested at the factory with

clean water before shipping. You may notice trace amounts of clean water in the

pre-installed tube assembly. This is part of our stringent quality assurance pro-

gram at Blue-White Industries.

For more information please visit us at: ww.blue-white.com

For videos and tutorials please visit as at:

https://www.blue-white.com/resources/videos

Page 4 ®

FLEXFLO A4

1.0 Introduction

1.1 What’s In The Box

The following items are included with every A4 peristaltic metering pump:

Page 5

FLEXFLO A4 1.0 Introduction

A4 Peristaltic Pump

USB Flash Drive With Instruction Manual

Standard Mounting Brackets

Spare Tubing

Tube Installation Tool

Injection Fitting

Suction Tubing

Discharge Tubing

Suction Strainer

Congratulations on purchasing the A4 FLEXFLO variable speed Peristaltic

Metering Pump.

Your FLEXFLO A4 pump is pre-configured for the tubing that shipped with your

metering pump. The tubing assembly has an Identification number printed for

easy re-order.

Please Note: Your new pump has been pressure tested at the factory with

clean water before shipping. You may notice trace amounts of clean water in the

pre-installed tube assembly. This is part of our stringent quality assurance pro-

gram at Blue-White Industries.

For more information please visit us at: ww.blue-white.com

For videos and tutorials please visit as at:

https://www.blue-white.com/resources/videos

Page 4 ®

FLEXFLO A4

1.0 Introduction

1.1 What’s In The Box

The following items are included with every A4 peristaltic metering pump:

Page 5

FLEXFLO A4 1.0 Introduction

A4 Peristaltic Pump

USB Flash Drive With Instruction Manual

Standard Mounting Brackets

Spare Tubing

Tube Installation Tool

Injection Fitting

Suction Tubing

Discharge Tubing

Suction Strainer

2.0 Engineering Specifications

2.1 OUTPUT VERSUS FLUID VISCOSITY

Fluid viscosity and motor RPM both have an effect on fluid output. For your reference the

charts below display the various tubes we offer and their output at different viscosities and

different motor RPM. All testing was conducted with a three foot suction lift.

Tube Material

2.0 Engineering Specifications Page 7

FLEXFLO A4

Page 6 ®

FLEXFLO A4

Flow Rate (ml/min)

200

400

600

800

1000

1200

1400

0 30 60 90 125

Motor RPM

output of 1,700 cP fluid vs. motor rpm

500

1000

1500

2000

2500

0 30 60 90 125

Motor RPM

output of water vs. motor rpm

MNH

MNJ

MNK

MTK

MGK

MNGG

MNEE

MG2G

100

120

140

160

0 30 60 90 125

Motor RPM

output of 12,000 cP fluid vs. motor rpm

500

1000

1500

2000

2500

0 30 60 90 125

Motor RPM

output of 200 cP fluid vs. motor rpm

Maximum Working Pressure (excluding pump tubes)

125 psig (8.6 bar)

Note: see individual pump tube assembly maximum pressure ratings.

Maximum Fluid Temperature (excluding pump tubes)

3/8” OD x 1/4” ID tubing connections: 130 °F (54 °C)

M/NPT connections: 185 °F (85 °C)

Note: see individual pump tube assembly max temperature ratings.

Ambient Operating Temperature 14 °F to 115 °F (-10 °C to 46 °C)

Ambient Storage Temperature -40 °F to 158 °F (-40 °C to 70 °C)

Maximum Viscosity 12,000 Centipoise

Maximum Suction Lift 30 ft. Water at sea level (14.7 atm psi)

Operating Voltage

115VAC/60Hz, 1ph (2.0 Amp Maximum)

230VAC/60Hz, 1ph (1.0 Amp Maximum)

220VAC/50Hz, 1ph (1.0 Amp Maximum)

240VAC/50Hz, 1ph (1.0 Amp Maximum)

230VAC/50Hz, 1ph (1.0 Amp Maximum)

Power Cord Options

115V60Hz = NEMA 5/15 (USA)

230V60Hz = NEMA 6/15 (USA)

220V50Hz = CEE 7/VII (EU)

240V50Hz = AS 3112 (Australia/New Zealand)

230V50Hz = BS 1363/A (UK)

Motor Brushless DC

Motor Speed Adjustment Range 2,500:1 (0.04% – 100%) Max rpm = 125 rpm

Motor Speed Adjustment Resolution

0.1% increments > 1% motor speed and < 100%

0.01% increments < 1% motor speed

Display 5” touchscreen color LCD, UV resistent

Display Languages English, Spanish, French, German, and Portuguese selectable

Security Programmable 6-digit password

Maximum Overall Dimensions 12-1/8”W x 15-1/4”H x 16-1/2”D (30.8W x 38.8H x 41.9D cm)

Product Weight 45.5 lb. (20.64 Kg)

Approximate Shipping Weight 50 lb. (22.68 Kg)

Enclosure NEMA 4X (IP66), Polyester powder coated aluminum & Noryl

RoHS Compliant Yes

Standards cETLus, CE

2.0 Engineering Specifications

2.1 OUTPUT VERSUS FLUID VISCOSITY

Fluid viscosity and motor RPM both have an effect on fluid output. For your reference the

charts below display the various tubes we offer and their output at different viscosities and

different motor RPM. All testing was conducted with a three foot suction lift.

Tube Material

2.0 Engineering Specifications Page 7

FLEXFLO A4

Page 6 ®

FLEXFLO A4

Flow Rate (ml/min)

200

400

600

800

1000

1200

1400

0 30 60 90 125

Motor RPM

output of 1,700 cP fluid vs. motor rpm

500

1000

1500

2000

2500

0 30 60 90 125

Motor RPM

output of water vs. motor rpm

MNH

MNJ

MNK

MTK

MGK

MNGG

MNEE

MG2G

100

120

140

160

0 30 60 90 125

Motor RPM

output of 12,000 cP fluid vs. motor rpm

500

1000

1500

2000

2500

0 30 60 90 125

Motor RPM

output of 200 cP fluid vs. motor rpm

Maximum Working Pressure (excluding pump tubes)

125 psig (8.6 bar)

Note: see individual pump tube assembly maximum pressure ratings.

Maximum Fluid Temperature (excluding pump tubes)

3/8” OD x 1/4” ID tubing connections: 130 °F (54 °C)

M/NPT connections: 185 °F (85 °C)

Note: see individual pump tube assembly max temperature ratings.

Ambient Operating Temperature 14 °F to 115 °F (-10 °C to 46 °C)

Ambient Storage Temperature -40 °F to 158 °F (-40 °C to 70 °C)

Maximum Viscosity 12,000 Centipoise

Maximum Suction Lift 30 ft. Water at sea level (14.7 atm psi)

Operating Voltage

115VAC/60Hz, 1ph (2.0 Amp Maximum)

230VAC/60Hz, 1ph (1.0 Amp Maximum)

220VAC/50Hz, 1ph (1.0 Amp Maximum)

240VAC/50Hz, 1ph (1.0 Amp Maximum)

230VAC/50Hz, 1ph (1.0 Amp Maximum)

Power Cord Options

115V60Hz = NEMA 5/15 (USA)

230V60Hz = NEMA 6/15 (USA)

220V50Hz = CEE 7/VII (EU)

240V50Hz = AS 3112 (Australia/New Zealand)

230V50Hz = BS 1363/A (UK)

Motor Brushless DC

Motor Speed Adjustment Range 2,500:1 (0.04% – 100%) Max rpm = 125 rpm

Motor Speed Adjustment Resolution

0.1% increments > 1% motor speed and < 100%

0.01% increments < 1% motor speed

Display 5” touchscreen color LCD, UV resistent

Display Languages English, Spanish, French, German, and Portuguese selectable

Security Programmable 6-digit password

Maximum Overall Dimensions 12-1/8”W x 15-1/4”H x 16-1/2”D (30.8W x 38.8H x 41.9D cm)

Product Weight 45.5 lb. (20.64 Kg)

Approximate Shipping Weight 50 lb. (22.68 Kg)

Enclosure NEMA 4X (IP66), Polyester powder coated aluminum & Noryl

RoHS Compliant Yes

Standards cETLus, CE

4.1 Agency Listings

Symbol

Description

Warning (Risk of electric shock)

Caution (Refer to the user’s guide)

Ground, Protective Conductor Terminal

ENCLOSURE RATING

NEMA 4X Constructed for either indoor or outdoor use to provide a degree of protection to personnel against incidental

contact with enclosed equipment; to provide a degree of protection against falling dirt, rain, sleet, snow,

windblown dust, splashing water, and hose-directed water; and that will be undamaged by external formation

of ice on enclosure.

IP66 No ingress of dust; complete protection against contact. Water projected in powerful jets against enclosure

from any direction shall have no harmful effects.

This pump is ETL listed to conforms to the following: UL Standard 778 as a motor operated water pump.

CSA Standard C22.2 as process control equipment

This pump complies to the Machinery Directive 2006/42/EC, BS, EN 60204-1, Low Voltage

Directive 2014/35/EU BS EN 61010-1, EMC Directive 2014/30/EU, BS EN 50081-1/BS EN

50082-1.

Page 9

FLEXFLO A4 4.0 Features

3.1 Non-Wetted Components 3.2 Wetted Components

Page 8 ®

FLEXFLO A4

3.0 Materials of Construction

Pump Head: Valox® (PBT) thermoplastic

Pump Head Cover: Polycarbonate

Permanently lubricated sealed motor shaft support ball bearing.

Cover Screws: Stainless steel

Roller Assembly:

Rotor: Valox® (PBT)

Rollers: Nylon

Roller Bearings: SS Ball Bearings

Motor Shaft: Chrome plated steel

TFD System Sensor: Hastelloy C-276

Power Cord: 3 conductor, SJTW-A water-resistant

Tube Installation Tool: GF Nylon

Mounting Brackets and Hardware: 316 Stainless steel

Pump Tube

Assembly:

Tubing: Flex-A-Prene®, Flex-A-Chem or

Flex-A-Thane®

Adapter Fittings: PVDF

Injection / Back-Flow

Check Valve:

Body & Insert: PVDF

Check Ball: Ceramic

Spring: Hastelloy C-276

Ball Seat O-Ring: TFE/P (optional EPDM)

Static Seal O-Ring: TFE/P (optional EPDM)

Ancillary Items Provided:

With “B” Tubing and

“M” M/NPT

Connections Only:

Suction Strainer:

Body: PVDF

Check Ball: Ceramic

Ball Seat O-Ring: TFE/P (Optional EP)

4.1 Agency Listings

Symbol

Description

Warning (Risk of electric shock)

Caution (Refer to the user’s guide)

Ground, Protective Conductor Terminal

ENCLOSURE RATING

NEMA 4X Constructed for either indoor or outdoor use to provide a degree of protection to personnel against incidental

contact with enclosed equipment; to provide a degree of protection against falling dirt, rain, sleet, snow,

windblown dust, splashing water, and hose-directed water; and that will be undamaged by external formation

of ice on enclosure.

IP66 No ingress of dust; complete protection against contact. Water projected in powerful jets against enclosure

from any direction shall have no harmful effects.

This pump is ETL listed to conforms to the following: UL Standard 778 as a motor operated water pump.

CSA Standard C22.2 as process control equipment

This pump complies to the Machinery Directive 2006/42/EC, BS, EN 60204-1, Low Voltage

Directive 2014/35/EU BS EN 61010-1, EMC Directive 2014/30/EU, BS EN 50081-1/BS EN

50082-1.

Page 9

FLEXFLO A4 4.0 Features

3.1 Non-Wetted Components 3.2 Wetted Components

Page 8 ®

FLEXFLO A4

3.0 Materials of Construction

Pump Head: Valox® (PBT) thermoplastic

Pump Head Cover: Polycarbonate

Permanently lubricated sealed motor shaft support ball bearing.

Cover Screws: Stainless steel

Roller Assembly:

Rotor: Valox® (PBT)

Rollers: Nylon

Roller Bearings: SS Ball Bearings

Motor Shaft: Chrome plated steel

TFD System Sensor: Hastelloy C-276

Power Cord: 3 conductor, SJTW-A water-resistant

Tube Installation Tool: GF Nylon

Mounting Brackets and Hardware: 316 Stainless steel

Pump Tube

Assembly:

Tubing: Flex-A-Prene®, Flex-A-Chem or

Flex-A-Thane®

Adapter Fittings: PVDF

Injection / Back-Flow

Check Valve:

Body & Insert: PVDF

Check Ball: Ceramic

Spring: Hastelloy C-276

Ball Seat O-Ring: TFE/P (optional EPDM)

Static Seal O-Ring: TFE/P (optional EPDM)

Ancillary Items Provided:

With “B” Tubing and

“M” M/NPT

Connections Only:

Suction Strainer:

Body: PVDF

Check Ball: Ceramic

Ball Seat O-Ring: TFE/P (Optional EP)

Page 11

FLEXFLO A4 5.0 Installation

5.1 Mounting Location

1. Choose an area located near the chemical supply tank, chemical injection point, and electrical supply. Also,

choose an area where the pump can be easily serviced.

2. Finding a secure surface and using the provided mounting hardware, mount the pump close to the injection

point. Keep the inlet (suction) and outlet (discharge) tubing as short as possible. Longer discharge tubing

increases back pressure at pump head.

NOTE: Mounting the pump lower than the chemical container will gravity-feed chemical into it. This “flooded

suction” installation will reduce output error due to increased suction lift. A shut-off valve, pinch-clamp, or

other means to halt gravity-feed to the pump must be installed during servicing.

NOTE: Install a back flow prevention check valve at the discharge side of the pump to prevent the system fluid

from flowing back through pump during tube replacement or during tube rupture.

NOTE: It is recommended to have a pressure relief valve at the discharge side of the of pump to prevent

premature wear and damage to the pump tube, in the event that the discharge line becomes blocked.

NOTE: The does not require back pressure. Keep the discharge pressure as low as possible to maximize pump

the tube life.

All diagrams are strictly for guideline purposes only. Always consult an expert before installing

metering pump on specialized systems. Metering pump should be serviced by qualified persons

only.

Always wear protective clothing, face shield, safety glasses and gloves when working on or near

your metering pump. Additional precautions should be taken depending on solution being

pumped. Refer to MSDS precautions from your solution supplier.

Risk of chemical overdose. Be certain pump does not overdose chemical during backwash and

periods of no flow in circulation system.

Be sure that installation does not constitute a cross connection with drinking water supply.

Check your local plumbing codes.

The pump should be serviced by qualified persons only. If equipment is used in a manner not

specified in this manual, the protection provided by the equipment may be impaired.

The pump should be supplied by an isolating transformer or RCD (operating current less or

equal 30 mA).

CAUTION

Page 10 ®

FLEXFLO A4

5.0 Installation

5.2 Pump Dimensions

nRaise metering pump 4-1/2 inches (11.43 cm) off ground or a surface.

nMade out of tough Stainless Steel.

nProvides a stable mounting surface.

Stainless Steel extended brackets allow the pump to be securely mounted to

most any surface; floor, shelf, or skid. Brackets lift the pump up 4-1/2 inches

(11.43 cm), for easy pump access in hard to reach areas.

Extended Brackets

Front View

Bottom View

Mounting Hole Spacings

(for standard and extended type brackets)

11.5” (29.2 cm)

2.5” (6.35 cm)

Maximum bolt hole size

0.200” diameter (4 places)

Side View

Table of contents

Other Blue-White Water Pump manuals

Blue-White

Blue-White FLEX-PRO PROSERIES-M Flex-A-Prene M-3 Operating instructions

Blue-White

Blue-White FlexFlo A-1600 Series User manual

Blue-White

Blue-White Chem-Feed C-1100A User manual

Blue-White

Blue-White CHEM-FEED MD3 User manual

Blue-White

Blue-White FLEXFLO M2 Series User manual

Blue-White

Blue-White CHEM-FEED C-1700N User manual

Blue-White

Blue-White Flexiflo M3 Series User manual

Blue-White

Blue-White FLEXFLO A-100 User manual

Blue-White

Blue-White FLEXFLO A-100NVP User manual

Blue-White

Blue-White FLEXFLO A1A Series User manual

Blue-White

Blue-White FLEXFLO A3 Series User manual

Blue-White

Blue-White CHEM-FEED CD1 Series User manual

Blue-White

Blue-White C3 Series User manual

Blue-White

Blue-White PROSERIES-M CHEM-PRO MD-3 Operating instructions

Blue-White

Blue-White CHEM-FEED MD1 Series User manual

Blue-White

Blue-White CHEM-FEED MD3 Series User manual

Blue-White

Blue-White Flex-Pro Pro M Series User manual

Blue-White

Blue-White FLEXFLO A-100NV User manual

Blue-White

Blue-White FLEXFLO A-100NE User manual

Popular Water Pump manuals by other brands

Neptun

Neptun NPHW 5500 operating instructions

Sensidyne

Sensidyne Gilian BDX-II Operation & service manual

Draper

Draper 47808 instructions

Trolla

Trolla 12820 manual

Sunfab

Sunfab SVH Series installation guide

WilTec

WilTec 50740 Operation manual

Fieldmann

Fieldmann FVC 5015 EK user manual

Everbilt

Everbilt EFSUB5-122HD Use and care guide

Graco

Graco Husky 3300e manual

esotec

esotec 101018 operating manual

moyno

moyno 2000 CC Service manual

Becker

Becker BASIC VASF 2.80/1-0.AC230 operating instructions

Sykes AmeriPumps

Sykes AmeriPumps GP100M Operation and maintenance instructions

DUROMAX

DUROMAX XP WX Series user manual

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 operating instructions

Franklin Electric

Franklin Electric IPS Installation & operation manual

Xylem

Xylem e-1532 Series instruction manual

Milton Roy

Milton Roy PRIMEROYAL instruction manual
