Blomberg WTI 7400 User manual

WASHER-DRYER

Model: WTI 7400

INSTRUCTION MANUAL

Contents

1. Precautions for safety and use

2. Installation instructions

3. Description of controls

4. Using the appliance for washing

5. Using the appliance for drying

6. Cleaning and maintenance

7. Troubleshooting

8. Programme guide

9. How To Obtain Service

10. Guarantee Details

This appliance is tagged in accordance with European Directive 2002/96/EC on Waste Electrical and

Electronic Equipment - WEEE.

This directive contains the regulations governing the collection and recycling of decommissioned appliances

throughout the European Union.

The symbol of the rubbish bin with a line through it on the appliance or its packaging indicates that the prod-

uct must be disposed of separately from other waste at the end of its life cycle. The user is thus obliged to

consign scrapped appliances to the special electronic and electrotechnical waste disposal centres, or return

them to the dealer on purchase of a similar new appliance, on a one-to-one basis.

Consignment to the appropriate facility for environmentally responsible recycling, treatment and disposal

helps to prevent any negative effects on the environment and health, and encourages the reuse and/or recy-

cling of the appliance’s component materials.

Illegal dumping of the appliance by the user will be subject to prosecution under the relevant law.

READ THE INSTRUCTIONS

Attention!

You are advised to read all the instructions in this manual carefully;

it will inform you about the right conditions for the proper, safe use

of your washer-dryer

It is very important to keep this instruction manual with the appli-

ance for future reference.

In the event of sale or transfer, ensure that the manual always ac-

companies the appliance, to provide the necessary information

about its use.

1. PRECAUTIONS FOR SAFETY AND USE

Attention!

These precautions are detailed for reasons of safety.

This section must be read carefully before installation and

use.

Disposing of packaging

Never leave packaging residues unattended in the home.

Separate waste packaging materials by type and consign

them to the nearest recycling centre.

Packaging materials (plastic bags, polystyrene, etc.) must not

be left within reach of children.

Disposing of old appliances

Once no longer in use, appliances must be rendered un-

usable: permanently disarm the lock on the door (this

will prevent children risking their lives by locking them-

selves inside during play) and cut the power supply lead

after removing the plug from the socket.

The appliance must be delivered to a recycling facility.

Environmental protection

Use the whole of the maximum recommended capacity. Nev-

er exceed the maximum permitted load.

Do not use the prewash function for lightly or normally soiled

items.

Follow the manufacturer's recommendations on detergent

usage.

Use the highest spin speed permitted for the fabric type. Fast

spins reduce the drying time and thus energy consumption.

Safety instructions

This appliance is intended for domestic use and is compliant

with Directives 72/23/EEC and 89/336/EEC (including Direc-

tives 92/31/EEC and 93/68/EEC) currently in force.

Read all the instructions in this manual carefully before instal-

lation and use.

Check that the drum assembly has been released before use

(see instructions). Failure to release the drum assembly may

cause damage to the washer-dryer and the surrounding furni-

ture or appliances during the spin cycle.

This Instruction Manual is an integral part of the appliance: it

must always be kept intact with the appliance. Installation

must be carried out by qualified staff in compliance with the

relevant regulations. The appliance is built to provide the fol-

lowing functions: washing and drying of clothes or fabrics

stated to be suitable for machine washing by the producer on

the relevant label. All other uses are to be considered im-

proper. The manufacturer declines all liability for uses

other than those stated above.

The nameplate with the technical data, serial number and

mark is in a visible position in the part in view after the door

has been opened. The nameplate must never be removed.

The electrical and plumbing works required to install the

appliance must only be carried out by skilled staff.

The appliance must be connected to earth in compliance with

electrical system safety regulations. The manufacturer de-

clines all liability for direct or indirect injury or damage

deriving from a non-existent or defective earth connec-

tion.

In the event that the appliance is not connected by means of a

plug, an omnipolar circuit-breaker device with contact gap of

at least 3 mm must be provided.

The plug to be connected to the power supply lead and the

relative socket must be of the same type and comply with the

relevant regulations. Check that the mains voltage and fre-

quency are the same as the values marked on the name-

plate. The use of adapters or junctions is not recommended.

Never disconnect the plug by pulling on the power supply

lead.

The appliance is only disconnected from the electricity

supply if the plug has been removed from the socket or

the electrical system master switch has been turned off.

The power plug must be accessible after the appliance

has been installed.

The appliance must be installed using new sets of hoses

(supplied with the appliance). Old hose sets should not be

reused.

Take care that the appliance is not standing on the power

supply cable.

The washer-dryer must never be used on vehicles, on board

ships or planes, or in environments with hazards, such as ex-

plosive or corrosive environments (powders, vapours and

gases) or explosive and/or corrosive liquids,

Do not install the washer-dryer in places with a risk of frost.

Frozen pipes may burst under the pressure.

Make sure that the drain hose connected to the sink is se-

curely fastened and cannot move.

If it is not fixed in place, the repulsive force of the water might

thrust it away from the sink, causing the risk of flooding.

When connecting the hose to a sink also check that the wa-

ter drains from it quickly, as otherwise the sink may

overflow.

Do not overload the appliance.

Never use detergents which contain solvents or chemicals for

washing in the washer-dryer. They might damage the ap-

pliance and form poisonous vapours. These fumes might

also catch fire and explode.

Garments soaked in petroleum products must not be washed

in the washing machine. Before washing, check that gar-

ments do not contain inflammable devices (e.g. cigarette-

lighters, matches, etc.)

If volatile cleaning fluids are used, ensure that these sub-

stances have been removed from the garments before they

are placed in the appliance.

Before loading garments for washing, check that the pockets

are empty, buttons secure and zips fastened.

Do not wash frayed or torn garments.

During washing at high temperatures, the glass in the door will

become very hot.

Check that all water has been drained from the appliance

before opening the door.

If there is water inside, pump it out before opening the door. If

in doubt, read the instruction manual.

The water in the appliance is not suitable for drinking!

Swallowing washing machine detergents may injure the mouth

and throat.

Before removing the garments from the washer-dryer check

that the drum is at a standstill.

Switch the appliance off after each use to avoid wasting elec-

tricity.

Leave the door ajar between washes to keep the gasket in

good condition.

In the event of a malfunction never attempt to repair the ap-

pliance yourself. Disconnect the appliance from the electrici-

ty supply and turn off the water tap. Then contact a qualified

engineer. Repairs must only be carried out by qualified

staff.

The appliance is intended for use by adults. Do not allow

children to tamper with the washer-dryer's controls or play

with it and do not keep children in the vicinity while the

programme is in progress.

Young animals or small children might climb into the washer-

dryer .

Always check the inside of the drum before use and do not

allow children to play with the appliance.

Keep children away from the appliance when the door or the

detergent drawer is open; the appliance might contain deter-

gent residues which may cause permanent injury to the eyes,

mouth and throat, or even cause death by suffocation.

This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervi-

sion.

That the tumble dryer is not to be used if industrial chemicals

have been used for cleaning

That lint must not be allowed to accumulate around the tum-

ble dryer

Do not dry unwashed items in the tumble dryer

Items that have been soiled with substances such as cooking

oil, acetone, petrol, kerosene, spot removers, turpentine,

waxes and wax removers should be washed in hot water with

an extra amount of detergent before being dried in the tumble

dryer

Items such as foam rubber (latex foam), shower caps, water-

proof textiles, rubber backed articles and clothes or pillows fit-

ted with foam rubber pads should not be dried in the tumble

dryer

Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

The final part of a tumble dryer cycle occurs without heat (cool

down cycle) to ensure that the items are left at a temperature

that ensures that the items will not be liable to combustion.

Never stop a tumble drier before the end of the drying cycle

unless all items are quickly removed and spread out so that

the heat is dissipated to avoid combustion.

Do not store flammable fluids near the appliance.

Lengthy periods out of use.

If the appliance is not to be used for a lengthy period it should

be disconnected from the electricity and water supplies and

the door should be left ajar to prevent unpleasant smells from

building up inside.

Important!

This appliance is easy to use.

However, for the best results it is important to read this manual

carefully and follow all the instructions before putting it into op-

eration.

The manual provides the correct instructions for installation, use

and maintenance, as well as giving useful advice.

For Great Britain only

Warning: this appliance must be earthed.

Fuse replacement

If the mains lead of this appli-

ance is fitted with a BS 1363A

13amp fused plug, to change a

fuse in this type of plug use an

A.S.T.A. approved fuse to BS

1362 type and proceed as fol-

lows:

1. Remove the fuse cover

(A) and fuse (B)

2. Fit replacement 13A fuse

into fuse cover

3. Refit both into plug

Important:

The fuse cover must be refitted when changing a fuse and if the

fuse cover is lost the plug must not be used until a correct re-

placement is fitted.

Correct replacement are identified by the colour insert or the

colour embossed in words on the base of the plug.

Replacement fuse covers are available from your local electrical

store.

If the appliance is provided with a plugless supply cord:

It is necessary to install in the fixed wiring an all-pole dis-

connection device having a gap between contacts of at

least 3,5mm. After installation the disconnection device has

to be easy to reach.

The connection to the mains must be carried out by a quali-

fied technician in accordance to the scheme shown below

and the regulations in force

L= brown

N= blue

= yellow-green

In the event of damage to the supply cord, it has to be re-

placed by the manufacturer or an authorized technical ser-

vice center in order to avoid any risk.

The manufacturer declines all responsibility for injury or

damage caused by failure to comply with the above regula-

tions or deriving from tampering with even just one part of the

appliance and the use of non-original spare parts.

2. INSTALLATION INSTRUCTIONS

Important!

The appliance must be installed by a qualified engineer in

compliance with the relevant regulations.

The washer-dryer is heavy. Take care when lifting it.

2.1 UNPACKING

The unit on flexible mounts is fixed in place for transport using

the screws (A) on the rear of the washer-dryer, with the relative

plastic spacers (B). Once the screws have been removed, the

power supply lead can be used.

1. Undo all the screws with a 10 mm spanner

2. Remove all the screws (A) from the rear

3. Remove all the plastic spacers (B)

4. Fit all the plastic plugs (C) provided,

to prevent water splashes from getting

into the appliance, and contact with live

parts.

Warning!

Do not turn the appliance upside-down or place it on its sides.

All the transport retainer fittings should be kept in a safe place;

they must be fitted again if the appliance has to be moved

around in the future.

A+B

Table of contents

Other Blomberg Washer Dryer manuals

Blomberg

Blomberg LRI1854310 User manual

Blomberg

Blomberg LRF1854310W User manual

Blomberg

Blomberg WDER8540421W User manual

Blomberg

Blomberg LRF285411W User manual

Blomberg

Blomberg LRI2854310 User manual

Blomberg

Blomberg LRF2854121G User manual

Blomberg

Blomberg LRI285410W User manual

Blomberg

Blomberg WDEX8540430W User manual

Blomberg

Blomberg WMD24400W User manual

Blomberg

Blomberg LRF1854311W User manual

Blomberg

Blomberg LRI285411 User manual

Popular Washer Dryer manuals by other brands

Whirlpool

Whirlpool WFC8090GX Use and care guide and installation instructions

Whirlpool

Whirlpool LTE5243DQ6 User instructions

Bosch

Bosch XQG100-WDU285H00W User manual and installation instructions

montpellier

montpellier MWD7512S Installation and operating instructions

LG FHD0905 T Series owner's manual

Midea

Midea MF200D85B owner's manual

Maytag

Maytag MGT3800XW installation instructions

Siemens

Siemens WD15G440TR Instruction manual and installation instructions

Equator

Equator Clothes Processor EZ1500 owner's manual

Splendide

Splendide WDC7100XCP Specifications

John Lewis

John Lewis JLWD 1408 instruction manual

Ariston

Ariston A1200WD Instruction booklet

Whirlpool

Whirlpool YLTE5243DQ5 installation instructions

Whirlpool

Whirlpool WFCR 75230 Health & safety, use & care and installation guide

ATT

ATT Hammer Jet v1 operating manual

AEG

AEG LAVAMAT 63742 VI Instruction booklet

Electrolux

Electrolux EWW8024P5WB user manual

GE GTD42EASJWH owner's manual
