BLADEZ BF 640HRP User manual

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com

Treadmill Owner’s Manual

BF 635 HRP & BF 640HRP

Revision Date: 10/24/05

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

INTRODUCTION:

Congratulations for selecting BLADEZ as your primary source of fitness. BLADEZ

treadmills offer many exercise programs that benefit users of all levels and ages.

Your new treadmill is designed to make your workouts more effective and enjoyable.

Please read this entire manual carefully before using your treadmill. This will

allow you to get a full understanding of all the features your BLADEZ’ treadmill

provides. If you have any questions or concerns, please contact the BLADEZ

Corporation or any authorized BLADEZ FITNESS distributors in your area.

BLADEZ Corporation

20155 Ellipse

Foothill Ranch, CA 92610

Phone: 949-206-0330

Fax: 949-206-0350

Email: customerser[email protected]

BEFORE YOU BEGIN

It is very important to get yourself familiar with the frequently used components of

your POWERMILL.

Frame

Power Cord

Socket

Power Switch

Circuit Breaker

Safety Key

Console

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

TABLE OF CONTENTS

SECTION PAGE

1. IMPORTANT SAFETY INSTRUCTIONS ............................................................... 3

2. ASSEMBLY INSTRUCTIONS................................................................................. 5

3. GETTING STARTED.................................................................................................9

•BF-635HRP DISPLAY SCREEN ........................................................................11

•BF-640HRP DISPLAY SCREEN ........................................................................12

4. WORKOUT PROGRAMS DETAILS (BF-635HRP) ...............................................13

•WORKOU T PROGRAMS DETAILS (BF-640HRP) ........................................15

•CALCULATING YOUR TARGET HEART RATE............................................20

5. PREVENTIVE MAINTENANCE.............................................................................21

6. TROUBLESHOOTING.............................................................................................22

7. WARRANTY.............................................................................................................24

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

SECTION 1

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using the treadmill.

Notice: Before using this or any other exercise equipment consult your family physician or

health care professional to develop a well planned exercise program to fit your health needs. If

you encounter any pain or breathing discomfort while working out, STOP!, and consult a

physician before continuing

WAR NIN G!

1. It is wise to always unplug this appliance from the electrical outlet immediately after use.

2. Keep Children away from machine while in use.

3. Do not wear loose or dangling clothing while using the treadmill

4. Keep a minimum clearance of 18” on each side and 24” at the rear of the treadmill for

safety.

5. It is mandatory that you unplug the treadmill prior to cleaning to reduce the risk of electric

shock, serious burns, and the risk of injuries.

6. The treadmill should never be left unattended when in operation. Unplug the treadmill from

the outlet when not in use or when servicing the treadmill.

7. Close supervision is necessary when this appliance is used by, on, or near children, invalids,

disabled persons, or those with diminished capacity.

8. Use this appliance only for its intended use as described in this manual.

Do not use any attachment not recommended by the manufacturer.

9. Never operate this appliance if it has a damaged cord or plug, or if it is not working

properly. Call your service center for any service concerns before taking your treadmill in for

repair.

10. Keep the cord away from heated surfaces.

11. Never drop or insert any object into any opening.

12. Do not use outdoors.

13. Do not operate where aerosol (spray) products are being used or where oxygen is being

administered.

14. To disconnect, turn all controls to the off position, then remove plug from outlet.

15. Connect this appliance to a properly grounded outlet only.

16. This appliance is intended for household use only.

SAVE THESE INSTRUCTIONS

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

IMPORTANT SAFETY INSTRUCTIONS CONTINUED

GROUNDING INSTRUCTIONS

This product must be grounded. If it malfunctions or breaks down, grounding

provides a path of least resistance for electric currents, to reduce the risk of electric

shock. This product is equipped with a cord which has an equipment-grounding

conductor and a grounding plug. The plug must be plugged into an appropriate

outlet that is properly installed and grounded in accordance with all local codes and

ordinances.

WA R N I N G ! – An improper connection of the equipment grounding conductor

can result in a risk of an electrical shock. Check with a qualified electrician or

serviceman if you are in doubt as to whether the product is properly grounded. Do

not modify the plug provided to you. If it does not fit the outlet, have a proper outlet

installed by a qualified electrician.

This product is for use on a nominal 110-120-volt circuit and has a grounding plug

that looks like the plug illustrated in the figure. Make sure that the product is

connected to an outlet having the same configuration as the plug. No adapter or

extension cord should be used with this product.

GROUNDING METHODS

GROUNDED

OUTLET

GROUNDING

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

SECTION 2

ASSEMBLY INSTRUCTIONS

ITEM Description Qty

A Computer Set 1

B Frame 1

C Left Upright 1

D Right Upright 1

E Left Handrail 1

F Right Handrail 1

G Left Handrail Cover 1

H Right Handrail Cover 1

I Water Bottle Holder 1

J Water Bottle 1

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

ASSEMBLY INSTRUCTIONS CONTINUED

ASSEMBLY PART LIST

ITEM NO. DESCRIPTION QUANTITY

a Bolt M8xP1.25x40 2

b Bolt M8xP1.25x60 4

c Bolt M8xP1.25x75 4

d Bolt M5xP0.8x15 2

e Bolt 2

f Screw Cover 6

g Allen wrench 5mm 1

h Wrench 1

i Power Cord 1

j. Safety Key 1

k Silicone 1

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

ASSEMBLY INSTRUCTIONS CONTINUED

A minimum of two people are required to

assemble this treadmill. Also, READ and

understand ALL INSTRUCTIONS

thoroughly BEFORE ASSEMBLING the

treadmill.

1. Tie the attached black guide wire

bottom from the left (C) upright to

the main connector from the base

frame as shown.

2. Then pull the connector through the

left (C) upright from the top and

secure with an adhesive tape before

performing the next step.

3. Secure the left (C) and right (D)

uprights onto the treadmill base

with 2 (a) bolts to the front and 4

* Ensure that the wire is not pinched when

securing the upright

4. Snap 6 of the screw covers (f) onto

the bolt openings as shown.

5. Pull the main cable connector from

the left console tubing and connect

with the connector from the left (C)

upright.

6. Connect elevation and speed

control cables from the left (E) and

right (F) side handrails with the

connector from the computer

console’s mounting tubes as shown

in arrows.

7. Insert handrails (E, F) onto the

computer console’s mounting tubes.

* Ensure that the wire is not pinched

between the hand rail and the console

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

ASSEMBLY INSTRUCTIONS CONTINUED

8. Rest the handrails on top of the

uprights. Secure them with 4 (b)

bolts.

9. Snap the rail covers (G, H) in

place and secure with 2 (e) bolts

on the bottom as shown.

10. Place water bottle holder (N)

against right (D) upright and

secure with 2 (d) screws.

BladeZ Corporation • 20155 Ellipse • Foothill Ranch • CA • 92610

www.ebladez.com • Phone 949-206-0330 • Fax 949-206-0350

SECTION 3

GETTING STARTED

MOVING THE TREADMILL

The treadmill has wheels located at the front as part of the elevation assembly. Elevate

the treadmill up to 10% or greater then un plug. Next lift the rear of the treadmill and

push the treadmill using the front wheels.

SAFETY KEY & CLIP

Your Bladez treadmill is equipped with a safety key that will disable the treadmill if it is

not in place. You should attach the clip end to your clothing. The magnet end goes into

the recess of the console. If at any time you need to stop the treadmill quickly simply

pull the safety key off the console. This will cut all power to the treadmill and it will

come to a complete stop. To resume your workout, place the safety key back in place.

You will then need to program your workout again.

BEFORE STARTING

Straddle the running belt and stand on the plastic side rails. Insert the safety key and

attach the rope to your clothing. Do not stand on the walking belt while starting or

stopping the treadmill.

KEY FUNCTIONS

START – This key is used to begin any treadmill program or quick start.

MODE – This key is used to enter into the program mode. It is also used to

change the values on the display readout such as changing from

ELEVATION to PULSE.

STOP – This key is used to stop the treadmill at any time. Press the STOP

button and hold for 3 seconds and the treadmill will reset itself.

This key is used to change values during programming

It is also used to adjust the speed on the treadmill.

This key is used to adjust the elevation on the treadmill.
