Billion BiPAC 7800GZ User manual

BiPAC 7800GZ

3G (HSPA) 802.11g ADSL2+

VPN Firewall Router

Quick Start Guide

Billion BiPAC 7800GZ 3G (HSPA) 802.11g ADSL2+ VPN Firewall Router

-1-

Package Contents

BiPAC 7800GZ 3G (HSPA) 802.11g ADSL2+ VPN Firewall Router

CD containing the on-line manual

RJ-11 ADSL/ telephone cable

Ethernet (RJ-45) cable

One 2dBi Wireless detachable antenna

Two 3G antennae

Power adapter

Quick Start Guide

Splitter/ Micro-filter (Optional)

Warning

PLEASE READ THE QUICK START GUIDE AND

FOLLOW THE

STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU

INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.

IF YOU NEED MORE INFORMATION ON THIS SOFTWARE

CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON

CD-ROM.



Do not use the

router

in high humidity or high temperatures.

Do not use the same power source for the router as other

equipment.

Do not open or repair the case yourself. If the router is too hot,

turn off the power immediately and have it repaired at a qualified

service center.



Avoid using this

product

and all

accessories

outdoors.



Place the router on a stable surfac

Only use the power adapter that comes with the package. Using a

different voltage rating power adaptor may damage the router.

Attention

Quick Start Guide

-2-

Hardware Overview

The Front LEDs

The Rear Ports

* Note: For WPS configuration, please refer to the WPS section of User Manual.

Connect it with

the supplied

power adapter.

Connect the supplied

RJ-11 cable to this port

when connecting to the

ADSL/telephone

network

Press

for

more than

1 second to restore

the device to its

default mode

Connect your computer

to a LAN port using the

included Ethernet cable

(with RJ-45 cable)

When the device is bo

oting, the

green light will be lit and the red

light will flash. When the system

is ready, it will be lit green. Lit

red when the device fails to boot

or when the device is in

emergency mode.

Insert a SIM card

into this slot.

Lit up steady when connected

to an Ethernet device. Lit

green when the speed of

transmission hits 100Mbps;

Lit orange when the speed of

transmission hits 10Mbps.

Blinking when data is

transmitted/received.

Lit green when the

device is successfully

connected to an ADSL

DSLAM. (“line sync”)

Lit green when 3G service is

ready. Blinking orange slowly

when 3G signal is weak;

blinking orange fast when 3G

signal is middle; lit up orange

steady when 3G signal is

strong. Lit off when there is

no 3G signal.

Power

ON/OFF

switch

Lit green when a wireless

connection is established. Flash

orange when WPS configuration is

in progress. However, if WPS fails

the LED will only lit for 1 min

before goes off. Blinking when

data is transmitted/received.

Connect the

detachable

antenna for

wireless

connection

Push WPS button to

trigger Wi-Fi Protected

Setup

function

Lit red when WAN port

fails

to get IP address. Lit green

when WAN port gets IP

address successfully. Lit off

when the device is in bridge

mode or when ADSL

connection is absent.

Con

nect the detachable

antennas to these two

ports for 3G connection.

3G Antenna

Billion BiPAC 7800GZ 3G (HSPA) 802.11g ADSL2+ VPN Firewall Router

-3-

Hardware Connection

BiPAC 7800GZ offers three modes to connect to the internet. Besides using ADSL, users can

set EWAN (Ethernet port # 4) or 3G for internet connection. BiPAC 7800GZ also allows Dual

WAN connection: ADSL fail-over to 3G, EWAN fail-over to 3G, ADSL fail-over to EWAN, and

counter likewise.

ADSL fail-over to 3G

Broadband (EWAN) fail-over to 3G

Quick Start Guide

-4-

ADSL fail-over to EWAN

Billion BiPAC 7800GZ 3G (HSPA) 802.11g ADSL2+ VPN Firewall Router

-5-

Hardware Installation

1. 3G Connection

Slide the SIM card into the card slot of the device with the gold contact facing down

Make sure that the SIM card has been slid into the bottom of the slot

with a click.

When removing

the SIM card, press the SIM card again it will be ejected from the

card slot.

Warning

Before inserting or removing the

SIM card, you must

disconnect the router from the power adapter.

Attention

Connect the detachable

antenna

to the two

jacks

on the back and right side of device as it shows as

above. Making sure they are firmly screwed in.

Quick Start Guide

-6-

2. Power Connection

Plug the supplied power adapter into the wall jack and

the other side to the router.

Please note that the plug type may differ according to country.

Please make sure

when press Power Switch the front LEDs will be lit or off.

3. LAN Connection

Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the

other side to the PC’s Ethernet interface.

4. EWAN Connection

Connect RJ-45 Ethernet cable to the Ethernet port # 4 (EWAN), and connect the

other side to another alternative broadband device, such as Cable Modem, VDSL,

Fibre Modem or PON optic lines. Please refer to User Manual for detail instruction.

Billion BiPAC 7800GZ 3G (HSPA) 802.11g ADSL2+ VPN Firewall Router

-7-

5. ADSL Connection

Connect the supplied RJ-11 phone cable to the router’s ADSL port, and the other

side to the phone jack on the wall.

6. Splitter/ Micro-filter Connection

Splitter / Micro-filters are important for ADSL installation, they help ensure that

high-frequency signals are directed to the ADSL modem, and low-frequency

signals are directed to the telephone or other analog voice-channel device to

prevent inter-modulation distortion and get good speeds and stable ADSL sync

rate.

a) Splitter connection

If the installation has only a single telephone and a single ADSL modem, then a

splitter can be employed.

Quick Start Guide

-8-

b) Micro-filter connection

If the installation has several telephones or other analog devices then an internal

micro-filter can be employed at each analog device.

Connecting to the Router

1. Open the web browser and type http://192.168.1.254 in the browser's address box. This

number is the default IP address for this router. Press Enter.

2. A username and password window will appear. The default username is “admin”, and

password is “admin”. Press OK to proceed.

3. You will get a status report web page and main menu screen.

Please see the relevant sections of user manual for detailed instructions on how to

configure your router.

Troubleshooting

1. None of the LEDs are on when you turn on the router.

Check the connection between the adaptor and the router. If the error persists, you may have

a hardware problem. In this case you should contact technical support.

2. Can’t ping any PCs on the LAN.

Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC

connected. If it is off, check the cables between your router and the PC. Make sure you have

uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet

mask are consistent between the router and the workstations.

3. Frequent loss of ADSL line sync (disconnections).

Ensure that all other devices connected to the same telephone line as your router (e.g.

telephones, fax machines, analogue modems) have a line filter connected between them and

the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified

and licensed electrician), and ensure that all line filters are correctly installed and the right
