Bernafon VERITE 7 Assembly instructions

FITTING GUIDE

VÉRITÉ 9 | 7 | 5

Hearing systems

www.bernafon.com

BERNAFON VÉRITÉ

Table of contents

Vérité – Overview 5

Selection chart for acoustic options 6

Fitting ranges 7

Selecting speaker unit length 8

Attaching speaker unit to Vérité 8

Detaching speaker unit from Vérité 9

Selecting correct dome size 10

M-speaker unit in detail 11

Changing the domes 11

Changing the NoWax guard in the M-speaker unit 11

Attaching the Ear Grip to the M-speaker 12

Custom Molds for the M-speaker 13

P-speaker unit for power fittings 17

Using the measurement gauge 17

Instant fit with Power Dome 18

Custom fit with the Power Mold 19

Changing from Power Dome to Power Mold 22

Changing from Power Mold to Power Dome 23

Wax protection 24

Wearing Vérité 25

Adjusting length and shape of the speaker unit wire 26

Vérité program selector, remote control and SoundGate 27

Fitting Vérité 9 | 7 | 5 with Oasis 28

Client 30

Hearing instrument 32

Fitting 33

End Session 36

Vérité – Customization 37

Colors 37

Changing the shells, battery drawer and wind filter 38

Ordering information 40

Color sets and tools 40

M-speaker parts for instant fit 41

M-speaker parts for custom fit 42

P-speaker parts for instant fit 43

P-speaker parts for custom fit 44

Vérité Fitting Guide

910

BERNAFON VÉRITÉ

Vérité is a premium receiver-in-the-ear instrument

that delivers unmatched client benets thanks to

its outstanding ChannelFree™ signal processing,

binaural coordination, unique design and wireless

connectivity. This guide is designed to help you t

and manage Vérité hearing systems.

1 Program selector

2 Connector plug

3 Speaker wire

4 Left/right indicator

5 Speaker

6 Size indicator

7 Shell

8 Battery drawer

9 Wind lter

10 Housing

11 Ear Grip

12 NoWax lter

Vérité – Overview

Selection chart for acoustic options

P-speaker Instant Tulip Dome Power Domes ( 8, 10, 12 ) WaxStop

Custom Power Mold NoWax

Speaker unit Fitting type Ear pieces Wax

protection

M-speaker Instant Open Domes

( 6, 8, 10 )

Tulip Dome Power Domes ( 8, 10, 12 ) NoWax

Custom Micro Mold Canal Mold Canal Lock Skeleton WaxStop

250 500 1.000 2.000 4.000 10.000

100

120

250 500 1.000 2.000 4.000 10.000

100

120

250 500 1.000 2.000 4.000 10.000

100

120

250 500 1.000 2.000 4.000 10.000

100

120

250 500 1.000 2.000 4.000 10.000

100

120

BERNAFON VÉRITÉ

Fitting ranges

M-speaker unit

P-speaker unit

Vérité offers two speaker units: the M-speaker

is appropriate for mild to moderate losses, while

the P-speaker provides additional power for

severe hearing loss. Expected tting ranges with

different ear pieces are shown below.

Open Dome Tulip Dome Custom Mold/Power Dome

Tulip Dome Power Mold/Power Dome

dB HL

Hz Hz Hz

Hz Hz

Before tting Vérité it is necessary to determine

the correct speaker unit length. The measurement

procedure is the same for both the M-speaker

and P-speaker. Place the Bernafon measuring tool

over the ear, keeping the top line horizontal. With

your eyes at the same level as the ear, determine

which mark is closest to an imaginary line running

over the top of the ear canal. In this example, the

correct choice is size 1.

Power Molds will have a better t if you choose a

slightly longer wire length than you would when

tting a Power Dome. If the top of the ear canal

falls between two numbers on the gauge, choose

the higher number.

Correct speaker unit attachment is imperative.

Slide the connector plug into the connector sock-

et of the instrument, taking care to align the pins

in the connector plug with the socket. When the

connector plug is in place, push rmly until there

is no visible gap between the end of the connec-

tor plug and the wind lter.

To test the attachment, pull gently on the speaker

wire. If the speaker unit comes off, it was not at-

tached properly.

Selecting speaker unit length

Attaching speaker unit to Vérité

Speaker units can easily sustain internal

damage if dropped. Before you attach the

speaker unit, please place a dome on the

speaker to protect it. (See page 11.)

BERNAFON VÉRITÉ

Detaching speaker unit from Vérité

To detach the speaker unit, rst open the battery

drawer slightly and remove the wind lter with

your ngernails, lifting the bottom end next to the

battery drawer. You may need to gently twist the

top of the wind lter until it comes loose.

Hold the instrument rmly and place an index

ngernail behind the connector plug to detach the

speaker unit by pulling.

Do not attempt to detach the speaker

unit by pulling up on the wire. This could

damage the wire and the connector.

Selecting correct dome size

Check the ear canal and choose between “small”,

“medium” or “large” for the dome.

The dome should stay in the ear canal without

movement while wearing, talking or eating.

The correct dome size is very important for

optimal performance and comfort. If the dome

is too big, your client may experience occlusion.

If the dome is too small, the speaker may start

moving in the ear or even fall out of the ear canal.

Ears with excessive cerumen production may

have more problems with domes coming off.

In this case, a power mold would be a better

solution.

Dome too small

Dome too big

Push the dome rmly onto the speaker

as far as it will go to make sure that it is

properly mounted. Failure to do so could

cause the dome to fall off in the ear canal.

Hands must be clean and dry before

mounting the dome.
