Beko D 7081 E User manual
Dear Customer,
We wish that this product, manufactured at modern facilities with total quality
notions, will deliver you the best performance. In order to guarantee this, please
read this instruction manual thoroughly and keep it for your future reference.
Contents
1Technical features Page 3
2Steps before operating Fullautomatic
Washing Machine and safety precautions Page 6
3Preparation Page 8
4Program selection and washing operations Page 13
5Care and Maintanence Page 19
6Determining location and installation Page 21
7Helpful tips on stain removal Page 24
8Before calling service Page 24
2
Models
7
85
60
59
74
220/50
10
2100
52
1000
Hot&cold
water
inlet
D 7102 E
D 7102 ES
7
85
60
59
74
220/50
10
2100
52
800
Hot&cold
water
inlet
D 7081 E D 7082 E
7
85
60
59
74
220/50
10
2100
52
800
cold
water
inlet
D 7101 E
7
85
60
59
74
220/50
10
2100
52
1000
cold
water
inlet
Maximum capacity (kg.)
Height (cm.)
Width (cm.)
Depth (cm.)
Net weight (kg.)
Power requirement (V/Hz)
Nominal current (A)
Power (W)
Washing speed (rpm)
Spin speed (rpm)
The appearance and specifications
are subject to change without notice
to raise the unit quality.
The graphics shown in the manual
are schematic and it is possible that
they not conform with your washing
machine.
1Technical features
Top lid
Control panel
Front door
Kick plate
Kick plate cover
3
Your Washing Machine
4
•The current requirement in order for safe operation of this machine is 16 Ampheres. You will need to have a certified
electrician to connect a 16 Amp fuse, if there is not enough current load.
• Your washing machine is set to 230 Volts.
• Do not forget to check the grounding in all cases of use with or without the transformer. Our company will not be
responsible for any damages caused by operations without grounding.
• The performance of the washing machine depends on the effectiveness of the cleaning agent. Stains can be
permanent if low quality detergents are used. Please take necessary effort to clean the stained clothes as described
in following pages before washing them in the machine.
• Your washing machine is designed only for domestic use.
• In order to bring the machine ready to use, please call your service technician or a certified plumber.
• If the power cord or the plug is damaged, please call a certified technician.
• Always use new “water inlet hose” received within your machine.
• Please perform the first wash with detergent, at COTTON 90 program and without placing your laundry inside the
washing machine. This will ensure that the drum is free from any left over dirt from production .
Due to the quality control processes during production, there may be some water left over in your machine.
This does not cause any damage to your product.
2Steps before operating Fullautomatic Washing Machine and safety precautions
5
Attention! Before any operation of the machine check the following.
• Did you close the front door?
• Is the tap open?
• Is water drain hose placed properly?
• Is power connected?
Sorting laundry
Sort the laundry according to the following groups and wash them seperately:
- white and resistant colored fabrics,
- colored fabrics,
- delicate fabrics (silk, rayon etc.),
- wool.
Be sure to empty pockets and remove any belts, buttons, pins, etc. from the clothing. You can place little clothing materials
(baby socks, etc) inside of pillow cases to avoid them slip into the pump and filter. For stained fabrics, refer to the “Practical
information” section of the operating manual.
Open the front door
To open the front door press the “door open” button.
For your safety, front door can be opened only when the machine is off.
Loading the machine
Place the fabrics uniformly inside the machine. Hand knits should be placed inside out in the machine. Make sure that there
is no clothing at the side of the door. Close the door by pushing lightly. If the door does not close completely, the machine
could not be started-a safety measure. Front door is locked untill the end of the washing program and it will not be opened
about 2 minutes following the end of the program.
3Preparation
6
Detergent and softener selection
Choose the appropirate detergent specifically used at the full automatic washing machines. Suggested amount is given
on the detergent cover.
Do not attempt to use detergents and bleaching elements that contain chlor and sulphur. The amount of the detergent
depends on the dirt level of fabric, the amount of fabric and the softness of the water.
The detergent dispensing drawer comprises 3 compartments:
– left compartment ( II ) for main wash
– middle compartment for fabric softener
– right compartment ( I ) for pre-wash
Detergent Dispenser
Attention! Fill the softener according to the supplier recommendation (app. <100 ml).
Do not exceed the “MAX level” marked on the detergent dispenser.
WARNING!
When the CURTAIN program is selected Pre-wash function is automatically set. Pre-wash
can be operated even without detergent.
7
Control Panel
Auxillary washing machine
On/Off Button
Timedelay adjustment button
Remain time
Start/Pause/Cancel button
Program follower
Spin speed selection
Door open button
Program selection knob
