basIP AT-10 User manual
quickstart guide
AT-10
IP INDOOR VIDEO ENTRY PHONE
Full User Manual
The indoor video entry phone works on the Android 6.0 operating
system.
It comes in 3 color variations: White, Gold, Black and has two installation
options: wall mount and flush mount, using a special bracket.
10" IP indoor video entry phone with IPS screen, Wi-Fi, resolution
1280x800 and the ability to connect alarm sensors.
wiki.bas-ip.com
2Loudspeaker
4Microphone
5MicroSD slot
6MicroUSB port
3Screen
1Camera
An indoor video phone (monitor) home screen consists of the main
desktop and 2 additional (by default).
In addition, you can add an unlimited number of custom desktops and
flexibly configure them (set the number of application icons and their
layout). Up to 8 application icons can be placed on each desktop.
Main screen
FIRST SCREEN
The first desktop displays the current
date and time.
Second SCREEN
On the desktop are displayed:
Date•
Time•
Weather widget•
Main sections of the monitor menu:•
Calls •
Messages •
Outdoor panels view menu •
IP cameras view menu •
third SCREEN
On the third desktop, additional system
menus and applications are displayed:
Quad splitter•
Security alarms•
Smart home menu•
Clamp any of the icons on the additional
desktop for one second, after which the
desktop will go into edit mode
Click on the button to add a new desktop
in the lower right corner
Select the required number of icons
displayed on this desktop:
2 x 2 / 3 x 2 / 4 x 2
Click on the add application icon and select
the necessary ones in a new window
After adding the necessary applications
to the desktop, you must click on the «Ok»
button to return to normal mode.
To remove the desktop, go to edit mode
and click on the «Delete» icon
in the lower-left corner.
To add a new desktop, you must:
How to change an application on the main desktop
You can change the main sections of the monitor menu (calls, messages, entrance panel
monitoring menu, IP camera viewing menu) into any other app.
To do this you must:
Press the app icon to be replaced and hold for a few seconds.•
Select the desired application in the opened tab.•
Press the new icon and hold for a few seconds to return the default app. •
Adding a new desktop and apps
The navigation bar is used for quick access to some features.
To open the bar, you need to swipe down at the top of the screen
or press any empty space.
In the bar, you have access to the following features:
Call elevator
EVRC IP controller is required
for functioning.
Adjusting the sound modes
Normal - a mode in which all sounds
are turned on.
Mute - a mode in which all sounds except
the alarm are turned off. You can also
adjust the time while mute mode will
be enabled.
Do Not Disturb - a mode in which all
sounds except the alarm are turned off
and incoming calls from other devices
are not displayed on the screen.
Concierge quick call to specified number
of concierge, another monitor, or SIP
number of any other device.
You can enable the feature in the monitor
settings or via the web interface.
concierge quick call
For «system settings» access is possible only
after entering the admin password).
Navigation bar
Call menu
When the Motion detection feature is enabled,
missed calls are displayed in the right corner
of the call icon, and notifications of videos
recorded when motion sensors are triggered
are displayed in the left corner.
By pressing the icon, the call history is displayed:
- missed call;•
- оutgoing call;•
- incoming call. •
An entry about a call contains the following info:
date and time when a call was made;•
subscriber number;•
сonversation duration.•
To open additional options, tap the entry.
Icons meaning:
- to call the selected number;•
- to view photos/videos taken during the call;•
- to save photos/videos taken during the call•
to SD card;
- to delete the entry.•
With the button in the lower right corner
of the screen, you can open the keypad for dialing
the number.
By pressing this button for a few seconds, you can
clear the call history.
On the main desktop, next to the call
icon, you can check the number
of missed calls.
Call menu
If the EVRC-IP is installed in your house,
you can call the elevator from the monitor
during the conversation between the monitor
and the panel.
If you hold lock Key 1/Key 2, the elevator call
button will appear. The elevator will be called
to the floor where the panel is installed
to move up / down;
During the incoming call, the following
screen will be displayed this screen.
Icons meaning:
- to answer a call;•
- to decline a call/end a conversation;•
- to open the keyboard;•
- to open the lock/s; •
- to turn on / off the microphone;•
- to record the video of the•
conversation;
- to take a photo of the screen.•
Call display
For quick access, you can save up to
10,000 contacts. They can be inner
numbers of panels, concierges, another
monitors or SIP number of any device.
You can add contacts in this monitor
menu or in the web interface.
Contacts
• Open the Call menu and go to the Contacts tab.
Press plus icon in the left low corner.•
Enter contact name.•
Specify number type: inner or SIP (required•
for entering a number in the correct format).
Select device type: multi-apartment panel,•
individual panel, or regular device (monitor
or any other device). This data is also necessary
for the correctcontact display in various
sections of the monitor.
Enter a number in the corresponding format.•
Press Add contact after entering all data. •
How to add contact via a monitor:
Number formats:
An inner number of a multi-apartment
panel consists of Building No., Unit No.,
and Device No. For example, 0001-01-1
is the number of the panel located
in the 1st unit of building No. 1.
An inner number of an individual panel
consists of Building No., Unit No., Floor No.,
Apartment No., and Device No. For example,
0001-01-02-04-1 is the number of the first
individual panel located in apartment No. 4
on the 2nd floor of the first unit of building No. 1.
An inner number of a regular device
consists of Building No., Unit No.,
Floor No., and Apartment No.
For example, 0001-01-00-01 is the
number of the monitor located in the
1st apartment on the 1st floor in the
1st unit of the 1st house.
SIP number must be entered in the format
sip:callee SIP number@address of the SIP
server or device IP address.
For example, sip:[email protected].bas-ip.com,
where 3925 is a SIP number, us.sip.bas-ip.com
is the address of the SIP server.
You also have several additional options:
• to add the contact to favorites and it will be displayed at the top of the list;
to add the contact to the blacklist and not receive notifications about calls from this contact•
(but a call will be displayed as missed in the list);
to accept calls from this contact automatically (autoanswer);•
for multi-apartment and individual panels, you can select the Use as default option.•
In this mode, the selected panel will be displayed by default when opening panel monitoring
menu.
If you tap a contact card, its detailed
info will be displayed.
By pressing the star icon, you can add
a contact to favorites so that it appears
at the top of your contacts list.
Press the button with three dots, to edit
or delete a contact.
To make a call, press the call button
on the right.
When you call the entrance panel, there
will be a search and connection
to the device.
The panel automatically accepts the call
for 30 seconds, and after the call ends
automatically.
To quickly find a required contact, enter
its name in the search bar.
Contacts search
This menu displays additional monitors
that have the same logical address,
but different device numbers.
Devices
This tab will appear in the menu if you have
enabled and configured the feature of recording
video when a motion sensor is triggered. Here you
can view the recorded videos. The tab contains
information about the date, time, duration of the
recording and the name of the camera from which
the video was recorded.
If necessary, you can delete a video by pressing
the corresponding button on its card or delete all
videos using the button in the lower right corner.
Motion detections
If you press the button in the upper left corner
near the device, the menu for editing the name
will be displayed. In the new window, you can
enter the name of the additional monitor you
want to display.
After pressing the Apply changes button,
the updated device name will be displayed.
You can also refresh the page by dragging
the page down.
By pressing the Delete button (in the lower right
corner), you can restore the default device names.
Messages menu
This menu displays messages received
from the concierge or management
company (via the Link). When a message
is got, you will hear a notification sound
and when unlocking the screen,
the counter above the application
icon will change.
If you go to the Messages menu,
the following interface will be displayed:
To read a message, double-tap it.
You can select showing all messages, only new or read ones at the top of the screen.
There are 2 types of messages:
• Info mail with information that does not require feedback.
• Poll with the help of which a management organization can gather feedback by giving
users a choice of options or the ability to enter their own reply.
