Baseus CCGAN100UE User manual
Baseus GaN2 Pro Quick
Charger 2C+2U 100W EU
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer
Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
3
Product Parameter
Name:
GaN2 Pro Quick Charger
Model No.:
CCGAN100UE
Material:
PC
Input:
AC 100V-240V~,50/60Hz, 2.5A Max.
Type-C1/Type-C2
Output:
5.0V 3.0A (15.0W), 9.0V 3.0A (27.0W),
12.0V 3.0A (36.0W), 20.0V 3.0A
(60.0W)
Type-C1+Type-C2 Output:
65.0W+30.0W/30.0W/30.0W+65.0W
USB1+USB2 Output:
5.0V 3.0A (15.0W)
Type-C1/Type-C2+USB1/USB2 Output:
65.0W+30.0W
Type-C1/Type-C2+USB1/USB2 Output:
60.0W+20.0W+18.0W
Type-C1/Type-C2+USB1/USB2 Output:
60.0W+20.0W+15.0W
65.0W:
5.0V 3.0A (15.0W), 9.0V 3-0A (27.0W),
12.0V 3.0A (36.0W), 15.0V 3.0A
(45.0W), 20.0V 3.25A (60.0W)
60.0W:
5.0V 3.0A (15.0W), 9.0V 3-0A (27.0W),
12.0V 3.0A (36.0W), 15.0V 3.0A
(45.0W), 20.0V 3.0A (60.0W)
Type-C 30.0W:
5.0V 3.0A (15.0W), 9.0V 3.0A (27.0w),
12.0V 2.5A (30.0W), 15.0V 2.0A
(30.0W), 20.0V 1.5A (30.0W)
USB 30.0W:
5.0V 3.0A (15.0W), 9.0V 3.0A (27.0W),
12.0V 2.5A (30.0W), 20.0V 1.5A
(30.0W)
20.0W:
5.0V 3.0A (15.0W), 9.0V 2.22A (20.0W),
12.0V 1.67A (20.0W)
18.0W:
5.0V 3.0A (15.0W), 9.0V 2.0A (18.0W),
12.0V 1.5A (18.0W)
Product size:
92*30.5*54.8mm
Product weight:
About 205g
Name:
Baseus Mini White Series Data Cable (with
E-mark chip)
Material:
TPE
Current:
5.0A (20.0V 5.0A 100.0W)
Interface:
Type-C to Type-C
Length:
1m
The above data are measured by the Baseus laboratory, the actual use will be slightly
different depending on the specific circumstances
4
Packing List
Charger*1
User Manual*1
Warranty card*1
5A C to C 20V 5A 100W Charging Cable (With E-mark Chip)*1
Product Diagram
Designed by Baseus/ Made in China
Indicator Light
Type-C1 Output
Type-C2 Output
USB1 Output
USB2 Output
5
Product description
This product is a 100W travel charger made of new semiconductor material Gan. The
product has small size, rich interfaces (2C 2U), complete fast charging protocols, and
supports QC4+, PD3.0, QC3.0, QC2.0, SCP, FCP, AFC, PE+, etc- the maximum output
power of type-C1 and type-C2 is 100W when they are used separately (20V-5A), which
can provide full speed fast charging for most laptops. When Type-C1 or Type-C2 and
USB1 or USB2 ports are changed at the same time, 95W output power can still be
supported, which can provide the same speed fast charging for Apple laptops. At the
same time, it can support the fast charging for Huawei 22.5W SCP, Samsung 45W,
Xiaomi 27W and other mobile phones, which can achieve fast charging for most mobile
phones and laptops. Products built-in over-current, over-voltage, temperature
protection and other multiple safety protection circuit.
Tips
Please read all instructions and warnings before using this product. Non-standard use
will damage the product or personal safety.
•Do not store the product in high temperature, strong light and strong magnetic
field. Do not place it in other harsh environments such as fire source.
•Improper use of the product can easily cause damage to the product or may
endanger personal and property safety.
•Consumer shall be liable for any personal and property damage resulted from their
improper use against the user manual or ignoring the warning, to which our
company will not bear any legal liability.
•Disintegration of this product by non-professionals is strictly prohibited.
•Use of household appliances or loads in excess of the output current of this product
shall be avoided (no output due to circuit protection).
•Intense physical actions including knocking, throwing, trampling on and squeezing,
etc. shall be avoided.
6
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for which the
claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g. during transport, cleaning
by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
7
EU Declaration of Conformity
This toy complies with the following directives: Directive No. 2014/30/EU, Directive No.
2014/35/EU and Directive No. 2011/65/EU as amended 2015/863/EU. You will receive a
complete EU declaration of conformity from the importer.
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
8
Vážený zákazníku,
děkujeme Vám za zakoupení našeho produktu. Prosíme, pečlivě si přečtěte následující
instrukce před prvním použitím a uživatelský manuál si uschovejte pro pozdější užití.
Zejména dbejte na bezpečnostní pokyny. Pokud máte jakékoliv dotazy či připomínky
ohledně přístroje, prosíme, obraťte se na zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce
Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
9
Parametry produktu
Název:
GaN2 Pro Rychlá nabíječka
Model:
CCGAN100UE
Materiál:
PC
Vstup:
AC 100V-240V~,50/60Hz, 2.5A Max.
Typ-C1/Type-C2
Výstup:
5.0V 3.0A (15.0W), 9.0V 3.0A (27.0W),
12.0V 3.0A (36.0W), 20.0V 3.0A
(60.0W)
Typ-C1+Typ-C2 výstup:
65.0W+30.0W/30.0W/30.0W+65.0W
USB1+USB2 výstup:
5.0V 3.0A (15.0W)
Typ-C1/Type-C2+USB1/USB2 výstup:
65.0W+30.0W
Typ-C1/Type-C2+USB1/USB2 výstup:
60.0W+20.0W+18.0W
Typ-C1/Type-C2+USB1/USB2 výstup:
60.0W+20.0W+15.0W
65.0W:
5.0V 3.0A (15.0W), 9.0V 3-0A (27.0W),
12.0V 3.0A (36.0W), 15.0V 3.0A
(45.0W), 20.0V 3.25A (60.0W)
60.0W:
5.0V 3.0A (15.0W), 9.0V 3-0A (27.0W),
12.0V 3.0A (36.0W), 15.0V 3.0A
(45.0W), 20.0V 3.0A (60.0W)
Typ-C 30.0W:
5.0V 3.0A (15.0W), 9.0V 3.0A (27.0w),
12.0V 2.5A (30.0W), 15.0V 2.0A
(30.0W), 20.0V 1.5A (30.0W)
USB 30.0W:
5.0V 3.0A (15.0W), 9.0V 3.0A (27.0W),
12.0V 2.5A (30.0W), 20.0V 1.5A
(30.0W)
20.0W:
5.0V 3.0A (15.0W), 9.0V 2.22A (20.0W),
12.0V 1.67A (20.0W)
18.0W:
5.0V 3.0A (15.0W), 9.0V 2.0A (18.0W),
12.0V 1.5A (18.0W)
Rozměry:
92*30.5*54.8mm
Hmotnost:
cca 205g
Název:
Datový kabel Baseus Mini White Series
(s čipem E-mark)
Materiál:
TPE
Proud:
5.0A (20.0V 5.0A 100.0W)
Rozhraní:
Typ-C na Typ-C
Délka:
1m
Výše uvedené parametry jsou měřeny laboratoří Baseus, skutečné parametry se mohou
mírně lišit v závislosti na konkrétních produktech a okolnostech.
10
Obsah balení
Nabíjecí zařízení *1
Uživatelský manuál *1
Záruční list *1
5A C na C 20V 5A 100W Nabíjecí kabel (S čipem E-mark) *1
Schéma produktu
Navrhl Baseus/ Vyrobeno v Číně
LED kontrolka
Typ-C1 výstup
Typ-C2 výstup
USB1 výstup
USB2 výstup
