Baseus BS-W522 User manual
Baseus Simple Mini Magnetic
Wireless Charger
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer
Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
3
Product Introduction
Thanks for choosing our wireless charger, before you use this product, please read this
manual carefully and save it.
Product parameters
Name:
Baseus Simple Mini Magnetic Wireless
Charger
Model:
BS-W522
Material:
Aluminum alloy+Tempered glass+TPE
Color:
Black/White/Blue
Interface:
Type-C PD protocol
Input Current:
DC 5V 2A, 9V 2.67A Max.
(It is recommended to use the PD adapter
with power of 18W or above.)
Output Power:
15W Max.
Compatibility:
Only supports iP 12 series with magnetic
wireless charging function
(Only compatible with standard iP12
series cases and Baseus magnetic cases.
Third-party magnet accessories may not
be compatible with the charger)
Product Size:
65.6mmx60.6mmx6.5mm (Without
packaging)
Product Weight:
60.0g (Without packaging)
Length:
1.5m
Note: The above parameters are derived from the actual measurement of the product.
The actual parameters will vary with the product or other factors.
4
Packing list
Wireless Charger x1
User Manual x1
Warranty card x1
User instruction
1. Plug Type-C port into the adapter port, and put your phone on the emission area,
make sure the receiving area of the mobile is magnetic suction with the emission area of
the wireless charger. (Normally the receiving area is in the middle of the mobile)
2. Remove your phone once charging is completed.
LED
Type-C Input
Top
The center of
Wireless
charger
Bottom (side for charging)
5
Indicator
1. Connect the wireless charger to the Type-C port, the green LED will be light on.
2. The green LED is breath at charging mode.
3. If the LED flashes very fast, please check if you placed the Wireless Charger and the
mobile properly and please make sure there is no metal placed between the charger
and the mobile.
Safety Instructions
If your mobile is running APP with high power consumption, or is running APP for a long
time, while charging wirelessly, the mobile may heat up. It is a normal situation, will not
influence the life or performance of the mobile and the Wireless Charger.
•This charger only supports iP 12 series with magnetic wireless charging function.
•This charger is only compatible with standard iP12 series cases and Baseus
magnetic cases. Third-party magnet accessories may not be compatible with the
charger.
•It is recommended to use PD certified adapters, or other PD adapters that meet
international safety standards (5V 2A, 9V 2A);
•The applicable operation temperature range is from 0°C to 35°C and the storage
temperature range is from -20°C to 50°C. Using the Wireless Charger out of the
suggested temperature range may damage the product or shorten battery life.
•Avoid children and pets chewing, swallowing the Wireless charger.
6
•Do not disassemble, modify or repair the Wireless Charger by yourself;
•Do not place the magnetic stripe card (e.g. credit card, phone card, bank
passbook and record card near the Wireless Charger while charging, to avoid the
magnetic filed generated by the Wireless Charger to damage the magnetic stripe
card.
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for which the
claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g. during transport, cleaning
by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
7
EU Declaration of Conformity
This toy complies with the following directives: Directive No. 2014/53/EU and Directive
No. 2011/65/EU as amended 2015/863/EU. You will receive a complete EU declaration of
conformity from the importer.
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
8
Vážený zákazníku,
děkujeme Vám za zakoupení našeho produktu. Prosíme, pečlivě si přečtěte následující
instrukce před prvním použitím a uživatelský manuál si uschovejte pro pozdější užití.
Zejména dbejte na bezpečnostní pokyny. Pokud máte jakékoliv dotazy či připomínky
ohledně přístroje, prosíme, obraťte se na zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce
Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
9
Představení produktu
Děkujeme, že jste si vybrali naši bezdrátovou nabíječku, než začnete produkt používat,
přečtěte si prosím pozorně tento manuál a uschovejte jej pro budoucí použití.
Parametry produktu
Název:
Baseus Simple Mini Magnetická
bezdrátová nabíječka
Model:
BS-W522
Materiál:
Hliníková slitina + tvrzené sklo + TPE
Barva:
Černá / bílá / modrá
Rozhraní:
Protokol PD typu C
Vstupní proud:
DC 5V 2A, 9V 2.67A Max.
(Doporučuje se používat adaptér PD s
výkonem 18 W nebo vyšším)
Výstupní výkon:
15W Max.
Kompatibilita:
Podporuje pouze řadu iP 12 s funkcí
magnetického bezdrátového nabíjení
(Kompatibilní pouze se standardními
pouzdry řady iP12 a magnetickými
pouzdry Baseus. Magnetické příslušenství
jiného výrobce nemusí být kompatibilní s
nabíječkou)
Rozměry:
65.6mmx60.6mmx6.5mm (bez obalu)
Hmotnost:
60.0g (bez obalu)
Délka:
1.5m
Poznámka: Výše uvedené parametry slouží jen pro informaci. Skutečné parametry se
mohou lišit podle produktu nebo v závislosti jiných faktorů.
10
Obsah balení
Bezdrátová nabíječka x1
Uživatelský manuál x1
Záruční list x1
Uživatelské instrukce
1. Zapojte port typu C do portu adaptéru a položte mobilní zařízení na vysílací oblast.
Ujistěte se, že přijímací oblast mobilního telefonu je magneticky připojená k vysílací
oblasti bezdrátové nabíječky. (Obvykle je přijímací oblast uprostřed mobilního zařízení)
2. Po dokončení nabíjení odpojte mobilní zařízení.
LED kontrolka
Vstup Typu-C
Horní strana
Centrum
bezdrátové
nabíječky
Spodní strana (pro nabíjení)
