MDRC1119TS
19inch pathology display with touch screen interface
The MDRC1119 TS is a 1
MegaPixelpathology display with touch
screen interface. The 19inch display brings
reliable,DICOMcompliantimagestoabroad
paletteofimagingapplications.
ConsistentDICOMimages,anywhere,anytime
The highquality LCD panel of the MDRC1119 TS presentspathology
imageswithbettercontrast,higherbrightnessandawiderviewinganglethan
conventionalcomputermonitors.
AdvancedBacklightOutputStabilization(BLOS)technologyensuresfast
powerupandcontinuousLCDbacklightstability,resultinginlongtermimage
consistency.
AndthankstotheintegratedDICOMPart14LookUpTable,theMDRC1119TS
isDICOMcompliant“outofthebox”.
Technicalspecifications MDRC1119TS
Screentechnology TFTColorLCD
Activescreensize(diagonal) 483mm(19.0")
Activescreensize(HxV) 301x376mm(11.9x14.8")
Aspectratio(H:V) 5:4
Resolution 1MP(1280x1024)
Pixelpitch 0.2940mm
Colorimaging Yes
Grayimaging No
Colorsupport 16.8million
Viewingangle(H,V) 178°
UniformLuminanceTechnology(ULT) No
PerPixelUniformity(PPU) No
AmbientLightCompensation(ALC) No
BacklightOutputStabilization(BLOS) Yes
IGuard No
Maximumluminance 300cd/m²
DICOMcalibratedluminance 180cd/m²
Contrastratio 1300:1
Responsetime(Tr+Tf) 10ms
Scanningfrequency(H;V) 31.579.95kHz;5075Hz
Housingcolor Darkgray
Videoinputsignals DVIDSingleLink
VGA(DB15)
Videoinoutterminals SeparateH&Vsync
CompositesynconH
SynconGreensupported
USBports 1upstream,2downstream
USBstandard 1.1
Powerrequirements(nominal) 100250V
Powerconsumption(nominal) 45W
Powersavemode Yes
Powermanagement DVIDMPMstatessupported
PowerOnstate
ActiveOffstate
DPMSstatessupported
Dotclock 165MHz
OSDlanguages English,French,German,Spanish,Italian,Dutch,SimplifiedChinese,Taditional
Chinese,Japanese,Korean
Dimensionswithstand(WxHxD) Landscape:418x535~425x223mm
Dimensionsw/ostand(WxHxD) Portrait:346x418x70mm
Landscape:418x346x70mm
Dimensionspackaged(WxHxD) 502x494x294mm
Technicalspecifications MDRC1119TS
Netweightwithstand 8.7kg
Netweightw/ostand 6.0kg
Netweightpackagedwithstand 11.7kg
Netweightpackagedw/ostand 9.0kg
Heightadjustmentrange 120mm
Tilt 0°/+10°
Swivel 45°/+45°
Pivot 90°
Mountingstandard VESA(100mm)
Screenprotection NA
Recommendedmodalities CT,MR,US,DR,CR,NM,Film
Certifications EN6060112(2001),EN55011(ClassB),IEC6100032,IEC6100033,IEC
6100042,IEC6100043,IEC6100044,IEC6100045,IEC61000411,IEC
6100046,IEC6100048,CE,EN606011MedicalPart1,FCCB,cul,PSE,BSMII,VCCI
,CCC,KCC,CSAc22.2No601.1,UL505011
Suppliedaccessories Usermanual
Videocables(DVISingleLink,Analog)
Maincables(UK,European(CEBEC/KEMA),USA(UL/CSA;adaptorplugNEMA
515P),Chinese(CCC))
USBcable
Externalpowersupply
Optionalaccessories BarcoExternalMedicalLCDDisplaySensor
QAsoftware MediCalQAWeb
Unitsperpallet 24
Palletdimensions(WxH) 800x1200mm
Warranty 3years
Generatedon:01Dec2013
Technicalspecificationsaresubjecttochangewithoutpriornotice.
Pleasecheckwww.barco.comforthelatestinformation.
