VT Vandal-Resistant

Housing AVTPSC

Vandal-resistant indoor housing

for Axis Network Cameras

Indoor installation

Sheet steel construction

Epoxypolyester painted

Key lock

VT Vandal-Resistant Housing AVTPSC has been designed

for surveillance applications in premises highly exposed to

vandalism (underground parking lots, subway stations, prisons,

police stations, corridors, supermarkets etc).

The housing is made of sheet steel (1.5 mm thick), painted

with epoxypolyester powder and the front window is made

of PMMA glass (4 mm thick). The housing is equipped with

an internal bracket for camera attachment and adjustment

and the compass opening allows for easy installation and

maintenance. The cable outlet is made possible from the fixing

base, from both sides (left or right) and from the 2 M20 cable

glands on the rear.

Optionally, VT Vandal-Resistant Housing AVTPSC can be

equipped with a heater. Supported cameras are AXIS 210, AXIS

210A, AXIS 211, AXIS 211A, and AXIS 221 Day & Night.

1 2 3

VT Verso Housing Fan

HPV42K0A017 VT Power Supply

0AVTPSCPS1

Heater 0AVTPSCH1

29983/EN/R2/0709

www.axis.com

VT Vandal-Resistant Housing AVTPSC

©2007 Axis Communications AB. The Axis trademark is registered by Axis AB. All other company names and products are trademarks or

registered trademarks of their respective companies. We reserve the right to introduce modifications without prior notice.

Specifications

Supported products *AXIS 210, AXIS 210A, AXIS 211, AXIS 211A, AXIS 221

Casing Made of sheet steel, 1.5 mm thick (0.06”)

Epoxypolyester powder painted RAL9002

PMMA glass 4 mm (0.15”) thick

Compass opening

Power Camera power supply:

OAVTPSCPS1: In 100 – 240 V AC, 50/60 Hz

Out 12 V DC, 1 A max

Operating conditions Temperature: up to + 50 °C (-4 °F to 122 °F)

Temperature with heater: -20 °C

Accessories

(not included)

Heater OAVTPSCH1

- Power: in 12 V DC/24 V AC, 20 W,

- Operating conditions: on 15 °C +/- 3 °C (59 °F),

off 22 °C +/-3°C (71°F)

Approvals CE according to EN61000-6-3, EN60065, EN50130-4

IK8

Dimensions (HxWxD)

and weight

178 x 354.5 x 155 mm (window dimensions: 117 x 96 mm)

Weight: 3.5 kg

72˚

155

C

C

117

R302

80

21

299

330

96

354.576

296

C  C

( 386 )

178

147

47 35

To receive a fully working unit for outdoor use, please use the following guide and select one item from each column. Items in grey boxes are optional.

VERSO housing – accessories and order guide
