Avalue Technology LPC-1909 Series User manual

Part No. E2017L990A1R

LPC-1909

19" Fanless Multifunctional Touch Panel Computer

Quick Reference Guide

2nd Ed –02 September 2015

LPC-1909

2 LPC-1909 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

LPC-1909 Quick Reference Guide

Content

1. Getting Started.................................................................................................4

1.1 Safety Precautions.............................................................................................4

1.2 Packing List.......................................................................................................4

1.3 System Specifications ........................................................................................5

1.4 System Overview...............................................................................................7

1.4.1 Front View......................................................................................................................7

1.4.2 Rear View ......................................................................................................................7

1.5 System Dimensions ...........................................................................................8

2. Hardware Configuration...................................................................................9

2.1 LPC-1909 connector mapping...........................................................................10

2.1.1 Serial port 1 connector (COM1)......................................................................................10

2.1.2 Serial port 2 connector (COM2)......................................................................................11

2.2 Installing Hard Disk & Memory ..........................................................................12

LPC-1909

4 LPC-1909 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x LPC-1909 Panel PC

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

—Chipset drivers and utilities

1 x Power Adapter

4 x VESA mounting screws

Quick Reference Guide

LPC-1909 Quick Reference Guide

1.3 System Specifications

Panel

LCD size

19", 4:3

Display type

SXGA

Resolution

1280 x 1024

Pixel pitch

0.294mm (H) x 0.294mm (V)

Luminance

350 cd/m²

Contrast ratio

1000

Viewing angle

80(U), 80(D), 85(L), 85(R )

Response time

10ms

Backlight

LED

Touch type

5 Wires resistive

Touch Light

transmission

Touch interface

USB (EETI)

System

Board

EBM-BYT

CPU

Onboard Intel® Atom Quad-Core E3845 1.91GHz with Integrated Chipset

I/O Chipset

E/C IT8528E

System Memory

One 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1333 SDRAM

SSD

One CompactFlash Type I/ II Socket

Hard Driver Bay

One 2.5" SATA HDD

Watchdog Timer

H/W Reset, 1sec. ~ 65535sec./1sec.step

H/W Status

Monitor

Monitoring system temperature, voltage, and cooling fan status. Auto throttling

control when CPU overheats

Expansion

1 x mPCIe with SIM Slot, 1 x mPCIe Supports mSATA

Rear I/O

Serial Port

1 x RS-232, 1 xRS-485

Ethernet

2 x RJ-45

HDMI

1 x HDMI

Audio Port

1 x Line-out

USB

1 x USB 3.0, 1 x USB 2.0 (Optional Extra 2 x USB 2.0)

Speaker

2 x 1W

Display

Chipset

Intel Bay Trail SoC Integrated Graphics

Resolution

HDMI 1.4a resolutions up to 1920x1200@ 60 24bpp

Dual Display

LVDS + HDMI

LPC-1909

6 LPC-1909 Quick Reference Guide

Audio

AC97 Codec

Realtek ALC892 supports 5.1-CH Audio

Audio Interface

Connector: Line out

Ethernet

LAN Chip

Dual Intel I210IT PCI-E Gigabit LAN

Ethernet Interface

10/100/1000 Base-Tx Fast Ethernet compatible

Mechanical & Environment

Color

Front Silver & Rear panel Black

Mounting

Wall/Stand/VESA 100 mm x 100 mm/ 75 mm x 75 mm

System Power

Requirement

+12 V ~ +26 V

Power Adapter

Input: 100~240 Vac/ 50~60 Hz

Output: +12 Vdc / 5 A (60W)

Power Type

AT/ATX

Operating Temp.

-20°C ~ 60°C (-4°F ~ 140°F)

Storage Temp.

-30 to 70°C

Operating

Humidity

0% ~ 90% Relative Humidity, Non-condensing

Dimensions

428.6mm x 350.6mm x 59.7mm

Weight

5.7 Kgs

Note: Specificationsare subject to change without notice.

Quick Reference Guide

LPC-1909 Quick Reference Guide

1.4 System Overview

1.4.1 Front View

1.4.2 Rear View

Connectors

Label

Function

Note

POWER

Power on button

Compact

Flash/COM2

CF Type I/II Socket with Ejector

Optional for 2nd COM port

COM1

Serial port 1 connector

DB-9 male connector

LINE OUT

Line-out audio jack

USB

1 x USB 2.0 connector

1 x USB 3.0 connector

Dock USB

LAN1

RJ-45 Ethernet connector 1

KB/MS/LAN2

2nd LAN

Optional PS/2 connector

HDD

HDD indicator

PWR

System power indicator

HDMI

HDMI connector

RESET

Reset button

DC-IN

DC Power-in connector

LPC-1909

8 LPC-1909 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)

Quick Reference Guide

LPC-1909 Quick Reference Guide

2.Hardware

Configuration

For advanced information, please refer to:

1- EBM-BYT User’s Manual

Note: If youneed more information, please visit our website:

http://www.avalue.com.tw

LPC-1909

10 LPC-1909 Quick Reference Guide

2.1 LPC-1909 connector mapping

2.1.1 Serial port 1 connector (COM1)

Signal

NDCDA#_485TXN

NDSRA#

NRXDA_485TXP

NRTSA#

NTXDA_485RXP

NCTSA#

NDTRA#_485RXN

NRIA#

GND
